Power steering and a hydraulic lift provide effortless, automotive-like control. These systems reduce operator fatigue, enhance productivity, and enable a tight turning radius, which is perfect for easy maneuverability.
Image shows an X584 Lawn Tractor with Power Steering
The 48-in. Accel Deep Mower Deck offers a stamped-steel, deep flat-top design that ensures excellent cut quality, productivity, and versatility. With the optional one-touch technology MulchControl system, quickly transition from mulching performance, side discharge, or bagging modes. This system creates a beautiful lawn, reduces fertilizer needs, and prevents clippings from blowing onto operators or driveways.
Electronic fuel injection and electronic throttle provide quick, reliable starts and smooth, responsive power without the need for a choke. The system automatically adjusts engine performance to maintain consistent speed and cut quality, even in thick grass, making mowing easier, more efficient, and more enjoyable.
Answer text goes here
Engine | |||||||
| Engine Power | 19 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 25.5 hp 19 kW |
| Engine Power | 25.5 hp | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 24 hp 17.9 kW | 25.5 hp 19 kW |
| Displacement | 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc |
| Displacement | 44.3 cu in. | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc | 44.3 cu in. 726 cc |
| Engine Manufacturer/Model | FS730 EFI | ||||||
| Engine Type | Electronic fuel injection (EFI), overhead valve, full-pressure lube, oil filter | Overhead valve, full-pressure lube, oil filter | Overhead valve, full-pressure lube, oil filter | Overhead valve, full-pressure lube, oil filter | Overhead valve, full-pressure lube, oil filter | Overhead valve, full-pressure lube, oil filter | Electronic fuel injection (EFI), overhead valve, full-pressure lube, oil filter |
| Cylinders | V-twin, cast-iron liners | V-twin, cast-iron liners | V-twin, cast-iron liners | V-twin, cast-iron liners | V-twin, cast-iron liners | V-twin, cast-iron liners | V-twin, cast-iron liners |
| Governor | Constant-speed electronic throttle control | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Constant-speed electronic throttle control |
| Choke/Speed Control | No choke required | ||||||
| Cooling Method | Air | Air | Air | Air | Air | Air | Air |
| Air Cleaner | Dry, replaceable with foam precleaner | Dry, replaceable | Dry, replaceable | Dry, replaceable | Dry, replaceable | Dry, replaceable | Dry, replaceable with foam precleaner |
| Oil Change | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter | No-tools oil drain with replaceable filter |
Fuel System | |||||||
| Type | Gasoline | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Fuel Delivery | Open-loop electronic fuel injection (EFI) | Pulse pump and carburetor | Pulse pump and carburetor | Pulse pump and carburetor | Pulse pump and carburetor | Pulse pump and carburetor | Open-loop electronic fuel injection (EFI) |
| Fuel Gauge | Gauge on dash | Gauge on dash | Gauge on dash | Gauge on dash | Gauge on dash | Gauge on dash | Gauge on dash |
| Fuel Tank Location | Rear | Rear | Rear | Rear | Rear | Rear | Rear |
| Fuel Fill Opening | On left fender | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm |
| Fuel Fill Opening | 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm |
| Fuel Fill Opening | 3 in. | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm | On left fender, 3 in. 7.6 cm |
| Fuel Tank Capacity | 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L |
| Fuel Tank Capacity | 4.4 U.S. gal. | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L | 4.4 U.S. gal. 16.7 L |
Electrical System | |||||||
| Battery Voltage | 12 V | ||||||
| Battery Cold Crank Amps | 340 CCA | ||||||
| Charging System | Flywheel alternator, regulated | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 24 amp |
| Charging System | 24 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 12 amp | Flywheel alternator, regulated, 24 amp |
| Engine Starter | Solenoid shift | Bendix | Bendix | Bendix | Bendix | Bendix | Solenoid shift |
| Hour Meter | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Headlights | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W | Two standard, incandescent, 27 W |
| Taillights Or Reflector | Reflectors | Reflectors | Reflectors | Reflectors | Reflectors | Reflectors | Reflectors |
| Backup Lights | No | No | No | No | No | No | No |
| Rear Work Lights | No | No | No | No | No | No | No |
| 12-V Outlet | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Transaxle | |||||||
| Transaxle Type | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Transaxle Control | Twin Touch™ pedals | Twin Touch™ pedals | Twin Touch™ pedals | Twin Touch™ pedals | Twin Touch™ pedals | Twin Touch™ pedals | Twin Touch™ pedals |
| Cruise Control | Yes, button on dash | Yes, button on dash | Yes, button on dash | Yes, button on dash | Yes, button on dash | Yes, button on dash | Yes, button on dash |
| Oil Cooler | Fins and fan on transaxle | Fins and fan on transaxle | Fins and fan on transaxle | Fins and fan on transaxle | Fins and fan on transaxle | Fins and fan on transaxle | Fins and fan on transaxle |
| Oil Filter | Yes, replaceable | Yes | Yes | Yes, internal, not replaceable | Yes, replaceable | Yes, replaceable | Yes, replaceable |
| Differential Lock | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Forward Speed | 11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h |
| Forward Speed | 7.2 mph | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h | 0-7.2 mph 0-11.6 km/h |
| Reverse Speed | 8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h |
| Reverse Speed | 5.2 mph | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h | 0-5.2 mph 0-8.4 km/h |
| Brakes | Internal wet disc | Internal wet disc | Internal wet disc | Internal wet disc | Internal wet disc | Internal wet disc | Internal wet disc |
Chassis | |||||||
| Frame | Welded heavy-duty | Welded heavy-duty | Welded heavy-duty | Welded heavy-duty | Welded heavy-duty | Welded heavy-duty | Welded heavy-duty |
| Primer/Paint | E-coat/powder | ||||||
| Weight Bracket | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb / 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and optional rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg |
| Receiver Hitch | No | No | No | No | No | No | No |
| Front Axle | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings | Cast iron front axle, front wheel ball bearings |
| Spindle Bushings | Metal, replaceable | Metal, replaceable | Metal, replaceable | Metal, replaceable | Metal, replaceable | Metal, replaceable | Metal, replaceable |
| Front Tires | 16x6.5-8 turf | 15x6.5-8 | 15x6.5-8 | 15x6.5-8 | 16x6.5-8 turf | 16x6.5-8 turf | 16x6.5-8 turf |
| Rear Tires | 24x12-12 turf | 24x12-12 turf | 24x12-12 turf | 24x12-12 turf | 24x12-12 HDAP | 24x9.5-12 turf | 24x12-12 HDAP |
| Hood Material | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent | Fully enclosed, molded-in color material reduces sound, will not rust or dent |
| Fender Deck Material | Stamped steel | Stamped steel | Stamped steel | Stamped steel | Stamped steel | Stamped steel | Stamped steel |
| Floor Mats | Sure-grip rubber | Sure-grip rubber | Sure-grip rubber | Sure-grip rubber | Sure-grip rubber | Sure-grip rubber | Sure-grip rubber |
| Storage | Yes, covered toolbox | Yes, under seat and covered toolbox | Yes, under seat and covered toolbox | Yes, under seat and covered toolbox | Yes, covered toolbox | Yes, covered toolbox | Yes, covered toolbox |
| Service Interval Decal | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Fender Handles/Grips | Handles | ||||||
| Cup Holder | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Equipment Mounting | Yes, heavy duty | Yes, heavy duty | Yes, heavy duty | Yes, heavy duty | Yes, heavy duty | Yes, heavy duty | Yes, heavy duty |
| Maximum Towing Capacity | 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg |
| Maximum Towing Capacity | 800 lb. | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg | 800 lb 363 kg |
Steering | |||||||
| Type | Power, hydraulic | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Four-Wheel Steer | Not available on this model | Not available on this model | Not available on this model | Not available on this model | Not available on this model | Yes | Not available on this model |
| Steering Wheel | 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm |
| Steering Wheel | 14 in. | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm | 14 in. 35.6 cm |
| Tilt Steering Wheel | Standard, five position | No | No | No | No | Standard, five position | Standard, five position |
| Turning Radius | 55.9 cm | 16 in. 40.6 cm | 16 in. 40.6 cm | 16 in. 40.6 cm | 22 in. 55.9 cm | 19 in. 48.3 cm | 22 in. 55.9 cm |
| Turning Radius | 22 in. | 16 in. 40.6 cm | 16 in. 40.6 cm | 16 in. 40.6 cm | 22 in. 55.9 cm | 19 in. 48.3 cm | 22 in. 55.9 cm |
| Uncut Circle Radius | 68.6 cm | 23 in. 58 cm | 20 in. 51 cm | 48A, 23 in. 58 cm 54A, 20 in. 51 cm | 24 in. 61 cm | 48A, 15 in. 38 cm 54A, 12 in. 30 cm | 24 in. 61 cm |
| Uncut Circle Radius | 27 in. | 23 in. 58 cm | 20 in. 51 cm | 48A, 23 in. 58 cm 54A, 20 in. 51 cm | 24 in. 61 cm | 48A, 15 in. 38 cm 54A, 12 in. 30 cm | 24 in. 61 cm |
Seat | |||||||
| Type | Cut-and-sewn high-back | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Seat Back Height | 53 cm | 15 in. 38 cm | 15 in. 38 cm | 15 in. 38 cm | 21 in. 53 cm | 21 in. 53 cm | 21 in. 53 cm |
| Seat Back Height | 21 in. | 15 in. 38 cm | 15 in. 38 cm | 15 in. 38 cm | 21 in. 53 cm | 21 in. 53 cm | 21 in. 53 cm |
| Armrests | Optional | No | No | No | Optional | Optional | Optional |
| Fore-Aft Adjustment | 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm |
| Fore-Aft Adjustment | 6.6 in. | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm | While seated, ball bearing slide rail, 15-position, 6.6 in. 17 cm |
| Seat Suspension | Six-position parallel arm | Tilt, two coil springs, three-position no-tools adjustment for operator weight | Tilt, two coil springs, three-position no-tools adjustment for operator weight | Tilt, two coil springs, three-position no-tools adjustment for operator weight | Six-position parallel arm | Six-position parallel arm | Six-position parallel arm |
Lift System | |||||||
| Lift System Type | Hydraulic | Foot pedal with adjustable spring assist | Foot pedal with adjustable spring assist | Foot pedal with adjustable spring assist | Hydraulic | Hydraulic | Hydraulic |
| Hydraulic Outlets | No | No | No | No | No | No | No |
| Mower Cut Height - Minimum | 2.5 cm | ||||||
| Mower Cut Height - Minimum | 1 in. | ||||||
| Mower Cut Height - Maximum | 10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm |
| Mower Cut Height - Maximum | 4 in. | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm | 13 positions, 1-4 in. 2.5-10.2 cm |
| Cut Height Increments | 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm |
| Cut Height Increments | 0.25 in. | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm | 0.25 in. 0.64 cm |
| Preset Cut Height | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Mower Deck | |||||||
| Type | Side discharge | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Cutting Width | 122 cm | Accel Deep™ mower deck, 48 in. 122 cm | Accel Deep™ mower deck, 54 in. 137 cm | Accel Deep™ mower deck, 48 in. 122 cm Accel Deep, 54 in. 137 cm | Accel Deep™ mower deck, 54 in. 137 cm | Accel Deep™ mower deck, 48, 54 in. 122, 137 cm | Accel Deep™ mower deck, 54 in. 137 cm |
| Cutting Width | 48 in. | Accel Deep™ mower deck, 48 in. 122 cm | Accel Deep™ mower deck, 54 in. 137 cm | Accel Deep™ mower deck, 48 in. 122 cm Accel Deep, 54 in. 137 cm | Accel Deep™ mower deck, 54 in. 137 cm | Accel Deep™ mower deck, 48, 54 in. 122, 137 cm | Accel Deep™ mower deck, 54 in. 137 cm |
| Construction | Forged steel deck shell | Forged steel deck shell | Forged steel deck shell | Forged steel deck shell | Forged steel deck shell | Forged steel deck shell | Forged steel deck shell |
| Mower Deck Material | 10 gauge | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm |
| Mower Deck Material | 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm |
| Mower Deck Material | 0.135 in. | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm | 10 gauge 0.135 in. 3.4 mm |
| Mower Wash Port | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Mower Drive System | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt |
| Mower Wheels | Four | Four | Four | Four | Four | Four | Four |
| Mower Wheel Adjustment | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin | Seven-position, spring-loaded pin |
| Mower Level Adjustment | Exact Adjust ports and onboard deck-leveling gauge | Exact Adjust ports and onboard deck-leveling gauge | Exact Adjust ports and onboard deck-leveling gauge | Exact Adjust ports and onboard deck-leveling gauge | Exact Adjust ports and deck-leveling gauge | Exact Adjust ports and deck-leveling gauge | Exact Adjust ports and deck-leveling gauge |
Mower Attachability | |||||||
| Type | Roll under tractor | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle | K72 hydrostatic integrated with transaxle |
| Front Draft Arms | Attached with spring pins at two points | Attached with spring pins at two points | Attached with spring pins at two points | Attached with spring pins at two points | Attached with spring pins at two points | Attached with spring pins at two points | Attached with spring pins at two points |
| Rear Draft Arms | Quick-pull pins | Quick-pull pins | Quick-pull pins | Quick-pull pins | Quick-pull pins | Quick-pull pins | Quick-pull pins |
| Mower Wheels Rotate | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal | Yes, 90 degrees for easy mower removal |
| Drive System | Dual belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt | Electric power take-off (PTO) clutch, in-line belt |
Safety | |||||||
| Meets ANSI Standard | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Meets OPEI Standard | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Backup Protection | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) | Reverse Implement Option (RIO) |
| Safety Video | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Buyer's Notes | |||||||
| Notes | Heavy-duty garden tractor transaxle Convenient power steering and hydraulic lift Built-in front and rear weight brackets | Heavy-duty garden tractor transaxle Steering spindle bushings for long life Built-in rear weight bracket | Heavy-duty garden tractor transaxle Steering spindle bushings for long life Built-in rear weight bracket | Heavy-duty garden tractor transaxle Steering spindle bushings for long life Built-in rear weight bracket | Heavy-duty garden tractor transaxle Convenient power steering and hydraulic lift Built-in front and rear weight bracket | Heavy-duty garden tractor transaxle Convenient power steering and hydraulic lift Standard four-wheel steering for exceptional maneuverability and trimming Built-in front weight bracket | Heavy-duty garden tractor transaxle Convenient power steering and hydraulic lift Built-in front and rear weight brackets |
| Warranty | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | 4 year/500 hour bumper-to-bumper** (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) |
Optional Equipment | |||||||
| Mowers | 48X option | 48A (standard) | 54A (standard) | 48A 54A | 54XA (standard) | 48A option, 54A option | 54A (standard) |
| Rear Bagger | 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L |
| Rear Bagger | 19 bu | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L | 7, 14, 19 bu 247, 493, 670 L |
| Powered Material Collection | Power Flow™ blower | Power Flow™ blower | Power Flow™ blower | Power Flow™ blower | Power Flow™ blower | Power Flow™ blower | Power Flow™ blower |
| Mulching System | Yes, MulchControl™ | Yes, MulchControl™ | Yes, MulchControl™ | Yes, MulchControl™ | Yes, MulchControl™ | Yes, MulchControl™ | Yes, MulchControl™ |
| Front Thatcher | 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm |
| Front Thatcher | 54 in. | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm | 38, 46, 54 in. 96.5, 116.8, 137.2 cm |
| Front Blade | 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm |
| Front Blade | 48 in. | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm | 48 in. 121.9 cm |
| Snow Blower | 119.4 cm | Two-stage, 44 in. 111.8 cm | Two-stage, 44 in. 111.8 cm | Two-stage, 44 in. 111.8 cm | Two-stage, 47 in. 119.4 cm | Two-stage, 47 in. 119.4 cm | Two-stage, 47 in. 119.4 cm |
| Snow Blower | 47 in. | Two-stage, 44 in. 111.8 cm | Two-stage, 44 in. 111.8 cm | Two-stage, 44 in. 111.8 cm | Two-stage, 47 in. 119.4 cm | Two-stage, 47 in. 119.4 cm | Two-stage, 47 in. 119.4 cm |
| Rotary Tiller | 106.7 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm Hydraulic, 42 in. 106.7 cm | |
| Rotary Tiller | 42 in. | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm | Mechanical, 30 in. 76.2 cm Hydraulic, 42 in. 106.7 cm | |
| Sleeve Hitch | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator | Yes, implements include box scraper, rear blade, plow, disk, and cultivator |
| Sprayer - Tow-Behind | 170.3 L | ||||||
| Sprayer - Tow-Behind | 45 U.S. gal. | ||||||
| Sprayer - Mounted | 94.6 L | ||||||
| Sprayer - Mounted | 25 U.S. gal. | ||||||
| Spreader - Tow-Behind | 79.4 kg | ||||||
| Spreader - Tow-Behind | 175 lb. | ||||||
| Spreader - Mounted | 57.7 kg | ||||||
| Spreader - Mounted | 125 lb. | ||||||
| Front Bumper | Standard front bumper/weight bracket | Styled bumper option | Styled bumper option | Styled bumper option | Standard front bumper/weight bracket | Standard front bumper/weight bracket | Standard front bumper/weight bracket |
| Brush Guard | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Weather Protection | Weather enclosure | Weather enclosure | Weather enclosure | Weather enclosure | Weather enclosure | Weather enclosure | Weather enclosure |
| Sun Canopy | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Bucket Holder | Yes, double bucket | Yes, double bucket | Yes, double bucket | Yes, double bucket | Yes, double bucket | Yes, double bucket | Yes, double bucket |
| Grass Striping | Lawn striping kit | Lawn striping kit | Lawn striping kit | Lawn striping kit | Lawn striping kit | Lawn striping kit | Lawn striping kit |
| Tractor Shovel | 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm |
| Tractor Shovel | 40 in. | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm | 40 in. 101.6 cm |
| Tow-Behind Tools | 19 | 19 | 19 | 19 | 19 | 19 | 19 |
Dimensions | |||||||
| Height | 1338 mm | 15 in. 38 cm | 15 in. 38 cm | 15 in. 38 cm | 21 in. 53 cm | 21 in. 53 cm | 21 in. 53 cm |
| Height | 52.7 in. | 15 in. 38 cm | 15 in. 38 cm | 15 in. 38 cm | 21 in. 53 cm | 21 in. 53 cm | 21 in. 53 cm |
| Overall Length | 1966 mm | 74.6 in. 1894 mm | 74.6 in. 1894 mm | 74.6 in. 1894 mm | 77.4 in. 1966 mm | 77.6 in. 1972 mm | 77.4 in. 1966 mm |
| Overall Length | 77.4 in. | 74.6 in. 1894 mm | 74.6 in. 1894 mm | 74.6 in. 1894 mm | 77.4 in. 1966 mm | 77.6 in. 1972 mm | 77.4 in. 1966 mm |
| Wheelbase | 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm |
| Wheelbase | 51.2 in. | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm | 51.2 in. 1300 mm |
| Width With Mower | 1590 mm | 62.6 in. 1590 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm |
| Width With Mower | 62.6 in. | 62.6 in. 1590 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm |
| Width With Mower (Deflector Raised For Storage) | 1335 mm | 62.6 in. 1590 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm |
| Width With Mower (Deflector Raised For Storage) | 52.6 in. | 62.6 in. 1590 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm | 48A: 62.6 in. 1590 mm 54A: 68.4 in. 1737 mm | 68.4 in. 1737 mm |
| Width Without Mower | 1034 mm | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 45 in. 1143 mm | 40.7 in. 1034 mm |
| Width Without Mower | 40.7 in. | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 40.7 in. 1034 mm | 45 in. 1143 mm | 40.7 in. 1034 mm |
| Weight | 352 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and optional rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg |
| Weight | 776 lb. | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard rear, optional front - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and optional rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg | Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb 19 kg |
Additional Information | |||||||
| Manufacturing Location | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA | Horicon, Wisconsin, USA |
| Date Collected | 2022-10-03T00:00:00 | 3-Oct-22 | 3-Oct-22 | 3-Oct-22 | 3-Oct-22 | 3-Oct-22 | 3-Oct-22 |
