The heavy-duty drive system includes a telescopic universal joint with a lock-back collar. The enclosed chain drive, reducing maintenance and enhancing durability, optimizes the use of engine power for excellent performance.

The two-stage design features a low-speed auger that gathers snow and channels it toward a high-speed rotor, propelling it out of the discharge chute. This is especially effective in deep or drifted snow, making it more efficient than single-stage snow throwers in such conditions.

The hydraulic cylinder allows for 200-degree spout rotation from the tractor seat, enabling precise control over snow placement. The discharge spout's adjustable deflector cap permits control of snow-throw height and distance, with optional remote kits for on-the-go spout angle adjustments.

Answer text goes here
Dimensions | ||
| Width - Overall | 139.9 cm | |
| Width - Overall | 55.1 in. | |
| Width - Clearing | 137.2 cm | |
| Width - Clearing | 54 in. | |
| Height Of Opening | 508 mm | |
| Height Of Opening | 20 in. | |
| Height To Top Of Chute Deflector | 108 cm | |
| Height To Top Of Chute Deflector | 42.5 in. | |
| Housing Depth | 42.7 cm | |
| Housing Depth | 16.8 in. | |
| Housing Thickness | 1.9 mm | |
| Housing Thickness | 0.075 in. | |
| Side Panel Thickness | 4.94 mm | |
| Side Panel Thickness | 0.194 in. | |
Auger | ||
| Diameter | 40.6 cm | 21 in. 53.3 cm |
| Diameter | 16 in. | 21 in. 53.3 cm |
| Speed | 172 rpm | 220 rpm |
| Drive | Splined-coupler PTO shaft to enclosed roller chain | Front power take-off (PTO) |
| Auger Drive Gearbox | Cast-iron bevel gearcase with 1-in. (25-mm) output shafts | |
| Protection | Shear bolt for each auger half, four shell-mounted extra shear bolts | |
| Drift Knife | One in base, optional second | |
Blower | ||
| Speed | 929 rpm | 220 rpm |
| Blower Fan Material | Ultra-high molecular weight (UHMW) polyethylene | |
| Blower Fan Size | 11.9x38.1 cm | |
| Blower Fan Size | 4.67x15 in. | |
Scraper Blade | ||
| Type | Reversible and replaceable | |
Lift System | ||
| Type | Hydraulic with down pressure | |
| Lift Height | 279 mm | |
| Lift Height | 11 in. | |
Spout | ||
| Diameter | 15.2 cm | 21 in. 53.3 cm |
| Diameter | 6 in. | 21 in. 53.3 cm |
| Rotation | 200 degree (angle) | |
| Rotation Control | Hydraulic remote control | |
Weight | ||
| Approximate Weight | 120 kg | |
| Approximate Weight | 260 lb. | |
Setup Time | ||
| Attaching Time | No tools required; 5 minutes | |
Additional Information | ||
| Date Collected | 2021-11-03 | |
