100 Series

John Deere S160

Name: John Deere S160 Riding Mowers
Brand: John Deere

Starting at

3,299.00

3,399.00

Key Features

Powerful 24 hp (17.9 kW) V-Twin Engine
48-in. (122-cm) Edge™ Cutting System
Heavy-Duty Hydrostatic Transaxle With Wide Tires
Two-Year or 120-Hour Bumper-to-Bumper Warranty

Comfortable and Simple to Operate

A 15-in. (38 cm) open-back seat is comfortable and cool for all-day comfort. The Easy-read digital fuel gauge shows fuel level on the dashboard so you can keep an eye on fuel levels while mowing.

Close-up of the MowerPlus Fuel Gauge on S100 series lawn tractors

Hydrostatic Transmission With Side-by-Side Pedals

Use the side-by-side pedals to maneuver with precision without shifting or lifting your foot off the platform, enhancing operator comfort and ease of use.

Top right studio view of an S100 series lawn tractor's two-pedal speed/direction controls

Change the Oil in 30 Seconds

The John Deere Easy Change™ oil change system makes changing the engine oil as easy as twisting on a new oil-filled filter. It's simple, quick, and clean.

Engine

Engine Power	17.9 kW
Engine Power	24 hp
Displacement	724 cc
Displacement	44.2 cu in.
Engine Manufacturer/Model	44U877 (M44)
Engine Type	Overhead valve, full-pressure lube, oil filter
Cylinders	V-twin - extended life series (ELS)
Governor	Mechanical
Choke/Speed Control	Single lever with spring-return on choke
Cooling Method	Air
Air Cleaner	Cartridge with prefilter
Oil Change	John Deere Easy Change 30-second oil change system

Fuel System

Type	Gasoline
Fuel Delivery	Pulse pump and carburetor
Fuel Gauge	Easy-read on dash
Fuel Tank Location	Rear
Fuel Fill Opening	Center
Fuel Fill Opening	4.45 cm
Fuel Fill Opening	1.75 in.
Fuel Tank Capacity	9.1 L
Fuel Tank Capacity	2.4 U.S. gal.

Electrical System

Battery Voltage	12 V
Battery Cold Crank Amps	300 CCA
Charging System	Regulated
Charging System	14 amp
Engine Starter	Bendix type
Hour Meter	Yes
Headlights	Two standard, LED
Taillights Or Reflector	Reflectors
Backup Lights	No
Rear Work Lights	No
12-V Outlet	No

Transaxle

Transaxle Type	Hydrostatic, 2-wheel drive
Transaxle Control	Side-by-side pedals
Cruise Control	Standard
Oil Cooler	Fins and fan on transaxle
Oil Filter	Yes, not serviceable
Differential Lock	No
Forward Speed	8.9 km/h
Forward Speed	5.5 mph
Reverse Speed	5.2 km/h
Reverse Speed	3.2 mph
Brakes	Internal wet disk

Chassis

Frame	Full-length welded steel
Primer/Paint	E-coat/powder
Weight Bracket	Optional rear
Receiver Hitch	No
Front Axle	Cast-iron front axle, front wheel sealed ball bearings
Spindle Bushings	No
Front Tires	15x6-8
Rear Tires	20x10-10
Hood Material	Molded-in color material reduces sound, will not rust or dent
Fender Deck Material	Stamped steel
Floor Mats	Yes, with debris removing channels
Storage	Storage tray with cover
Service Interval Decal	Yes
Fender Handles/Grips	Handgrips
Cup Holder	Yes
Equipment Mounting	CargO Mount™ system
Maximum Towing Capacity	227 kg
Maximum Towing Capacity	500 lb.

Steering

Type	Sector and pinion with single drag link and tie rod
Four-Wheel Steer	Not available on this model
Steering Wheel	30.5 cm
Steering Wheel	12 in.
Tilt Steering Wheel	No
Turning Radius	45.7 cm
Turning Radius	18 in.
Uncut Circle Radius	50.8 cm
Uncut Circle Radius	20 in.

Seat

Type	Two-piece with open-back
Seat Back Height	38 cm
Seat Back Height	15 in.
Armrests	No
Fore-Aft Adjustment	14 cm
Fore-Aft Adjustment	5.5 in.
Seat Suspension	Tilt, two coil springs

Lift System

Lift System Type	Spring-assisted hand-grip lever
Hydraulic Outlets	No
Mower Cut Height - Minimum	2.5 cm
Mower Cut Height - Minimum	1 in.
Mower Cut Height - Maximum	10.2 cm
Mower Cut Height - Maximum	4 in.
Cut Height Increments	0.64 cm
Cut Height Increments	0.25 in.
Preset Cut Height	No

Mower Deck

Type	Side discharge
Cutting Width	122 cm
Cutting Width	48 in.
Construction	Stamped steel deck shell
Mower Deck Material	12 gauge
Mower Deck Material	2.7 mm
Mower Deck Material	0.105 in.
Mower Wash Port	Yes
Mower Drive System	Electric power take-off (PTO) clutch
Mower Wheels	Four
Mower Wheel Adjustment	One bolt
Mower Level Adjustment	Easy-level deck

Mower Attachability

Type	Slide under tractor
Front Draft Arms	One spring clip
Rear Draft Arms	Two spring clips
Mower Wheels Rotate	No
Drive System	Single belt

Safety

Meets ANSI Standard	Yes
Meets OPEI Standard	Yes
Backup Protection	Reverse Implement Option (RIO)
Safety Video	Yes

Buyer's Notes

Notes	Molded-in color material reduces sound, will not rust or dent; Wide 20x10-8 rear tires; John Deere Easy Change 30-second oil change system
Warranty	2 year/120 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.)

Optional Equipment

Rear Bagger	229 L
Rear Bagger	6.5 bu
Mulching System	Mulch cover
Front Blade	116.8 cm
Front Blade	46 in.
Snow Blower	111.8 cm
Snow Blower	44 in.
Sprayer - Tow-Behind	56.8 L
Sprayer - Tow-Behind	15 U.S. gal.
Sprayer - Mounted	56.8 L
Sprayer - Mounted	15 U.S. gal.
Spreader - Tow-Behind	80 kg
Spreader - Tow-Behind	175 lb.
Front Bumper	Included
Weather Protection	Weather enclosure
Sun Canopy	Sun canopy
Bucket Holder	Yes, single bucket
Grass Striping	Lawn striping kit
Tow-Behind Tools	16

Dimensions

Height	1151 mm
Height	45.3 in.
Overall Length	1903 mm
Overall Length	74.9 in.
Wheelbase	1242 mm
Wheelbase	48.9 in.
Width With Mower	1544 mm
Width With Mower	60.8 in.
Width With Mower (Deflector Raised For Storage)	1313 mm
Width With Mower (Deflector Raised For Storage)	51.7 in.
Width Without Mower	1015 mm
Width Without Mower	40 in.
Weight	218 kg
Weight	481 lb.

Additional Information

Manufacturing Location	Greeneville, Tennessee, USA
