new
John Deere
S110
100 Series

John Deere S110

Starting at

2,599.00

2,699.00

Easy Speed and Direction Control

The Kanzaki® Tuff Torq® hydrostatic transmission offers an infinite choice of speeds, making direction changes seamless. Side-by-side foot pedals control speed and direction, enhancing operator comfort and ease of use, ensuring reliability across varied conditions.

Top right studio view of an S100 series lawn tractor's two-pedal speed/direction controls
Do More Than Mow

A 100-Series Lawn Tractor is the perfect companion for property care tasks. Use a bagger to collect clippings and leaves. Transport mulch using a cart. A snow blower removes snow while a weather enclosure protects you from the elements. All John Deere attachments are tested to ensure compatibility.

Front left view of an S140 Lawn Tractor with black weather enclosure parked on a snowy driveway in front of a closed garage.
Convenient and Comfortable

A 15-in. (38 cm) cut-and-sewn seat looks as good as it feels with 5-1/2-in. of fore and aft travel adjusting for multiple operators. Controls are positioned where they are easy to reach, and the standard LED headlights look great and provide natural light quality.

Front right studio view of the seat and operator station of an S140 Lawn Tractor
Question text goes here

Answer text goes here

Engine
Engine Power

14.2 kW

Engine Power

19 hp

Displacement

540 cc

Displacement

33 cu in.

Engine Manufacturer/Model

33R877 (M33)

Engine Type

Overhead valve, full-pressure lube, oil filter

Cylinders

One

Governor

Mechanical

Choke/Speed Control

Single lever with spring-return on choke

Cooling Method

Air

Air Cleaner

Cartridge

Oil Change

No-tools oil drain with replaceable filter

Fuel System
Type

Gasoline

Fuel Delivery

Pulse pump and carburetor

Fuel Gauge

Mechanical, viewable from seat

Fuel Tank Location

Rear

Fuel Fill Opening

Center

Fuel Fill Opening

4.45 cm

Fuel Fill Opening

1.75 in.

Fuel Tank Capacity

9.1 L

Fuel Tank Capacity

2.4 U.S. gal.

Electrical System
Battery Voltage

12 V

Battery Cold Crank Amps

300 CCA

Charging System

Regulated

Charging System

8 amp

Engine Starter

Bendix type

Hour Meter

Yes

Headlights

Two standard, incandescent

Taillights Or Reflector

No

Backup Lights

No

Rear Work Lights

No

12-V Outlet

No

Transaxle
Transaxle Type

Hydrostatic, 2-wheel drive

Transaxle Control

Side-by-side pedals

Cruise Control

No

Oil Cooler

Fins and fan on transaxle

Oil Filter

Yes, not serviceable

Differential Lock

No

Forward Speed

8.9 km/h

Forward Speed

5.5 mph

Reverse Speed

5.2 km/h

Reverse Speed

3.2 mph

Brakes

Internal wet disk

Chassis
Frame

Full-length welded steel

Primer/Paint

E-coat/powder

Weight Bracket

Optional rear

Receiver Hitch

No

Front Axle

Cast-iron front axle, powdered-metal front wheel bushings

Spindle Bushings

No

Front Tires

15x6-6

Rear Tires

20x8-8

Hood Material

Molded-in color material reduces sound, will not rust or dent

Fender Deck Material

Stamped steel

Floor Mats

Yes, with debris removing channels

Storage

Storage tray with optional cover

Service Interval Decal

Yes

Fender Handles/Grips

No

Cup Holder

Yes

Equipment Mounting

CargO Mount™ system

Maximum Towing Capacity

227 kg

Maximum Towing Capacity

500 lb.

Steering
Type

Sector and pinion with single drag link and tie rod

Four-Wheel Steer

Not available on this model

Steering Wheel

30.5 cm

Steering Wheel

12 in.

Tilt Steering Wheel

No

Turning Radius

45.7 cm

Turning Radius

18 in.

Uncut Circle Radius

63.5 cm

Uncut Circle Radius

25 in.

Seat
Type

Two piece with open-back

Seat Back Height

38 cm

Seat Back Height

15 in.

Armrests

No

Fore-Aft Adjustment

14 cm

Fore-Aft Adjustment

5.5 in.

Seat Suspension

Tilt, two coil springs

Lift System
Lift System Type

Spring-assisted hand-grip lever

Hydraulic Outlets

No

Mower Cut Height - Minimum

2.5 cm

Mower Cut Height - Minimum

1 in.

Mower Cut Height - Maximum

10.2 cm

Mower Cut Height - Maximum

4 in.

Cut Height Increments

0.64 cm

Cut Height Increments

0.25 in.

Preset Cut Height

No

Mower Deck
Type

Side discharge

Cutting Width

107 cm

Cutting Width

42 in.

Construction

Stamped steel deck shell

Mower Deck Material

13 gauge

Mower Deck Material

2.3 mm

Mower Deck Material

0.09 in.

Mower Wash Port

Yes

Mower Drive System

Manual power take-off (PTO)

Mower Wheels

Two

Mower Wheel Adjustment

One bolt

Mower Level Adjustment

Easy-level deck

Mower Attachability
Type

Slide under tractor

Front Draft Arms

One spring clip

Rear Draft Arms

Two spring clips

Mower Wheels Rotate

No

Drive System

Single belt

Safety
Meets ANSI Standard

Yes

Meets OPEI Standard

Yes

Backup Protection

Reverse Implement Option (RIO)

Safety Video

Yes

Buyer's Notes
Notes

Molded-in color material reduces sound, will not rust or dent Durable primer and powder paint finish Full-length welded steel frame

Warranty

2 year/120 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.)

Optional Equipment
Rear Bagger

229 L

Rear Bagger

6.5 bu

Mulching System

Mulch cover or high-performance plug

Front Blade

116.8 cm

Front Blade

46 in.

Snow Blower

111.8 cm

Snow Blower

44 in.

Sprayer - Tow-Behind

94.6 L

Sprayer - Tow-Behind

25 U.S. gal.

Sprayer - Mounted

56.8 L

Sprayer - Mounted

15 U.S. gal.

Spreader - Tow-Behind

80 kg

Spreader - Tow-Behind

175 lb.

Front Bumper

Styled front bumper

Weather Protection

Weather enclosure

Sun Canopy

Sun canopy

Bucket Holder

Yes, single bucket

Grass Striping

Lawn striping kit

Tow-Behind Tools

16

Dimensions
Height

1120 mm

Height

44 in.

Overall Length

1770 mm

Overall Length

69.7 in.

Wheelbase

1242 mm

Wheelbase

48.9 in.

Width With Mower

1402 mm

Width With Mower

55.2 in.

Width With Mower (Deflector Raised For Storage)

1181 mm

Width With Mower (Deflector Raised For Storage)

46.5 in.

Weight

188 kg

Weight

414 lb.

Additional Information
Manufacturing Location

Greeneville, Tennessee, USA

Date Collected

2022-03-26T00:00:00
