Engineered for performance, technology features include an integrated precision ag platform with AutoTrac™ guidance readiness, JDLink™ connectivity, and access to John Deere Operations Center™. Advanced automation and data tools can help improve efficiency, uptime, and in-field productivity.
JDLink™ hardware comes standard with the machine. You can turn on JDLink connected service in your John Deere Operations Center™ account for free. JDLink requires a cellular connection to transfer information from machine to Operations Center. Consult your John Deere Dealer for coverage availability.

Enjoy a spacious cab that provides all-day comfort with ergonomic controls, excellent visibility, and a sealed environment. The CommandARM™ console provides a thoroughly intuitive operating interface. All the controls you need for daily work are available at your fingertips.

The transmissions are built to meet the demands of your day with the standard Infinitely Variable Transmission (IVT) or optional AutoQuad™, and Direct Drive transmissions. These help provide operators with the ability to match shifting control, automation, and efficiency to their tasks.

Answer text goes here
Wheel or Track Configuration | Wheel |
Drive Type | MFWD |
Engine Make | John Deere |
Engine Model | PowerTech™ PVS |
Engine Family | VJDXL06.8309 |
Emissions Certifications | Final Tier 4 |
Displacement | 418 cu in. |
Displacement | 6.8 L |
Aspiration | Turbocharged, variable geometry turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation |
Number of Cylinders | 6 |
Cylinder Liners | Wet-sleeve |
Aftertreatment Type | Cooled exhaust gas recirculation (EGR) Diesel Particle Filter (DPF) with Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) using DEF |
Intelligent Power Management (IPM) | 40 |
Rated Engine Speed | 2100 rpm |
Rated Engine Power | 182 hp |
Rated Engine Power | 136 kW |
Rated Engine Power | 185 PS |
Rated Engine Power with IPM | 222 hp |
Rated Engine Power with IPM | 225 PS |
Engine Torque at Rated Speed | 866 Nm |
Maximum Engine Speed | 1900 rpm |
Maximum Engine Power | 201 hp |
Maximum Engine Power | 150 kW |
Maximum Engine Power | 204 PS |
Maximum Engine Power with IPM | 231 hp |
Maximum Engine Power with IPM | 234 PS |
Maximum Engine Torque | 639 lb-ft |
Constant Power Range | 1,500 - 2,100 rpm |
Power Bulge | 10 % |
Bore and Stroke | 4.2 x 5.0 in. |
Compression Ratio | 16.7:1 |
Lubrication | Pressure lubrication |
Cooling System Type | Liquid |
Fuel Type | Ultra-low sulfur diesel |
Air Cleaner Type | PowerCore ® G2 Air Filter with pre-cleaning |
Torque Rise | 40 % |
Transmission Type | Standard: John Deere AutoPowr™/IVT™ 40 km/h; Optional: John Deere AutoPowr™/IVT™ 50 km/h |
Maximum Speed Forward | 31 mph |
Minimum Speed Forward | 0.02 mph |
Reverser | Left-hand electrical reverser |
Cruise Control | Yes |
Rated PTO Power | 147 hp |
Rated PTO Power | 110 kW |
Rated PTO Power | 149 PS |
Rated PTO Power with IPM | 183 hp |
Rated PTO Power with IPM | 186 PS |
Economy PTO Speeds | 540 rpm / 1,000 rpm |
Engagement Method | Electrohydraulic switch |
PTO Clutch | Multi-disk |
Number of Splines | 6 and 21 |
PTO Speed | 1000 |
Front PTO Rotation | Clockwise rotation (viewed in direction of travel) |
Engine rpm (at Rated PTO Speeds) | 1969 rpm |
Maximum PTO Power | 107 hp |
Maximum PTO Power | 109 PS |
Front Number of Splines | 21 |
Front Hitch Category | Category 3N |
Lift Capacity Through Full Lift Range at Coupling Points | 7275 lb. |
Maximum Lift Capacity at Coupling Points | 9700 lb. |
Maximum Lift Capacity at Coupling Points | 4000 kg |
Number of Front Selective Control Valves (SCVs) | Two |
Electric Power | ISOBUS Connector |
Rear Hitch Category (SAE Designation) | Category 3/3N |
Maximum Lift Capacity Directly at Coupling Points | 16865 lb |
Lift Capacity Through Full Lift Range Directly at Coupling Points | 9921 lb |
Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point | 8708 lb |
Sensing Type | Electrohydraulic sensing |
Draft Control Sensing | Yes |
Drawbar Category | Category 3 |
Maximum Vertical Load | 6612 lb |
Hydraulic System Type | Closed-center, pressure/flow compensated system |
Pump Rated Output | Standard: 114 L/min 30 gpm; Optional: 155 L/min 41 gpm |
Maximum Operating Pressure | 2970 psi |
Number of Rear Selective Control Valves (SCVs) | 6 |
Number of Mid Selective Control Valves (SCVs) | 3 |
SCV Control | Electrohydraulic |
Auxiliary Hydraulic Features | Yes |
Front Axle Type | Standard: Mechanical Front Wheel Drive axle; Optional: Triple Link Suspension (TLS™) |
Front Axle Differential Lock | Yes |
Rear Axle Type | Inboard planetary three pinion |
Rear Differential Lock | Yes |
Differential Controls | Yes |
Final Drive | Three planetary gear reduction |
Steering Type | Dynamic Load Sensing, Hydrostatic, Flow Metering |
Primary Brakes | Oil-cooled, self-equalizing, self-adjusting, hydraulically actuated |
Trailer Brakes | Optional: Air and/or hydraulic |
Parking Brake | Intergrated parking brake |
Gearshift Location | CommandArm™ |
Db(A) Rating | 71 dBA |
Seat Suspension | Mechanic / Pneumatic |
Degree of Seat Swivel, Left Hand | 15 degree (angle) |
Degree of Seat Swivel, Right Hand | 15 degree (angle) |
Cab Suspension | Yes |
Instructional Seat | Yes |
Primary Display | Cornerpost Display |
Radio | Standard |
Inner Cab Volume | 116.5 cu ft |
Inner Cab Volume | 3.3 m³ |
Cab Glass Area | 65.7 sq ft |
Cab Glass Area | 6.11 m² |
Guidance | SF-RTK |
Secondary Display | 10,1 / 12.8 inch Command Center Display |
Receiver | Universal StarFire™ 7500 |
Connectivity | JDLink™ Modem |
Remote Diagnostics | Yes |
ISOBUS Ready | Yes |
Fuel Tank Capacity | 74 gal. |
Fuel Tank Capacity | 322 L |
Diesel Exhaust Fluid (DEF) Tank Capacity | 4.2 gal. |
Diesel Exhaust Fluid (DEF) Tank Capacity | 16 L |
Cooling System Capacity | 7.2 gal. |
Cooling System Capacity | 27.4 L |
Transmission - Hydraulic System | 16.4 gal. |
Transmission - Hydraulic System | 62 L |
Crankcase Oil Volume | 6.2 gal. |
Crankcase Oil Volume | 23.5 L |
Wheelbase | 108.8 in. |
Wheelbase | 2765 mm |
Base Machine Weight | 17990 lb. |
Base Machine Weight | 8120 kg |
Overall Height | 119.3 in. |
Overall Height | 2950 mm |
Transport Height | 119.3 in. |
Overall Width | 65.5 in. |
Overall Length | 194.8 in. |
Overall Length | 4930 mm |
Maximum Permissible Weight | 25900 lb. |
Maximum Permissible Weight | 11750 kg |
Country of Manufacture | Germany |
Date Collected | 8-Jun-26 |
