Utility Tractors

John Deere 6M 250

Starting at

Key Features

Engine hp: 275 Max / 250 Rated
John Deere PowerTech™ PSS Engine
Transmission Options: IVT™ 25 mph (40 km/h) or 31 mph (50 km/h)
Up to 20 hp Boost With IPM in Non-Stationary Power Take-Off (PTO) and Transport Applications

Precision Technology to Help Improve Efficiency

Precision ag technology availability includes AutoTrac™ guidance readiness, JDLink™ connectivity, and an intuitive corner post display to help operators improve accuracy, efficiency, and uptime.

Activation required. JDLink hardware comes standard with the machine. You can turn on JDLink Connected service in your John Deere Operations Center™ account for free. JDLink requires a cellular connection to transfer information from machine to a JDLink website. Consult your John Deere dealer for coverage availability.

Interior of a John Deere tractor cab showing steering wheel, CommandPRO joystick, and multiple touchscreen displays with guidance and machine data, while operating over a grassy field.

Efficient, More Comfortable 6M Cab

Your time in the cab can be comfortable and efficient with the 6M interior environment. Built with the operator in mind, we offer three cab customizations, allowing you to select the package that best meets your needs.

Operator’s view inside John Deere tractor cab showing fabric operator seat, steering wheel, armrest controls, touchscreen displays, and wide windshield overlooking a harvested field.

Transmission Choices That Are Up To The Task

Choose from a versatile lineup of transmission options, including PowrQuad™, AutoQuad™, CommandQuad™, and available Infinitely Variable Transmission (IVT™). This broad selection allows operators to match shifting control, automation, and efficiency to the demands of their day.

Machine Configuration

Wheel or Track Configuration	Wheel
Drive Type	MFWD

Engine

Engine Make	John Deere
Engine Model	John Deere PowerTech™ PSS
Engine Family	VJDXL06.8322
Emissions Certifications	Final Tier 4
Displacement	418 cu in.
Displacement	6.8 L
Aspiration	Turbocharged, variable geometry turbo with fixed geometry turbo in series, air-to-air aftercooling and cooled exhaust gas recirculation
Number of Cylinders	6
Cylinder Liners	Wet-sleeve
Aftertreatment Type	Diesel particle filter (DPF) with diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF)
Intelligent Power Management (IPM)	20
Rated Engine Speed	2100 rpm
Rated Engine Power	247 hp
Rated Engine Power	184 kW
Rated Engine Power	250 PS
Rated Engine Power with IPM	271 hp
Rated Engine Power with IPM	202 kW
Rated Engine Power with IPM	275 PS
Maximum Engine Speed	1900 rpm
Maximum Engine Power	271 hp
Maximum Engine Power	202 kW
Maximum Engine Power	275 PS
Maximum Engine Power with IPM	277 hp
Maximum Engine Power with IPM	206 kW
Maximum Engine Power with IPM	281 PS
Maximum Engine Torque	814 lb-ft (1,117 Nm)
Constant Power Range	1,550 - 2,100 rpm
Power Bulge	10 %
Bore and Stroke	4.2 x 5.0 in.
Bore and Stroke	106.5 x 127 mm
Compression Ratio	16.7:1
Lubrication	Pressure lubrication
Cooling System Type	Liquid
Fuel Type	Ultra-low sulfur diesel
Air Cleaner Type	Dry-filter type air filter with pre-cleaning
Torque Rise	40 %

Transmission

Transmission Type	Standard: John Deere AutoPowr™/IVT™ 40 km/h; Optional: John Deere AutoPowr™/IVT™ 50 km/h, John Deere e19™ PowerShift™ 40 km/h & 50 km/h
Maximum Speed Forward	31 mph (50 km/h)
Minimum Speed Forward	0.02 mph (0.03 km/h)
Reverser	Electronic left-hand reverser
Cruise Control	Yes

Rear Power Take-Off (PTO)

Rated PTO Power	195 hp
Rated PTO Power	145 kW
Rated PTO Power	198 PS
Rated PTO Power with IPM	212 hp
Rated PTO Power with IPM	158 kW
Rated PTO Power with IPM	215 PS
Economy PTO Speeds	540 rpm
Engagement Method	Electrohydraulic switch
PTO Clutch	Multi-disk
Number of Splines	6 and 21

Front PTO

PTO Speed	1000
Front PTO Rotation	Clockwise rotation (viewed in direction of travel)
Engine rpm (at Rated PTO Speeds)	1966 rpm
Maximum PTO Power	154 hp
Maximum PTO Power	115 kW
Maximum PTO Power	156 PS

Front Hitch

Front Hitch Category	Category 3N
Lift Capacity Through Full Lift Range at Coupling Points	9700 lb.
Lift Capacity Through Full Lift Range at Coupling Points	4400 kg
Maximum Lift Capacity at Coupling Points	13007 lb.
Maximum Lift Capacity at Coupling Points	5900 kg
Number of Front Selective Control Valves (SCVs)	One
Electric Power	ISOBUS Connector

Rear Hitch

Rear Hitch Category (SAE Designation)	Category 3/3N
Maximum Lift Capacity Directly at Coupling Points	Standard: 19,400 lb. (8,800 kg ); Optional: 21,820 lb. (9,900 kg)
Lift Capacity Through Full Lift Range Directly at Coupling Points	Standard: 13,880 lb. (6,300 kg); Optional: 15,430 lb. (7,000 kg)
Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point	Standard: 13,000 lb. (5,900 kg); Optional: 14,770 lb. (6,700 kg)
Sensing Type	Electrohydraulic sensing
Draft Control Sensing	Electronic Stepper Motor

Drawbar

Drawbar Category	Category 3
Maximum Vertical Load	3000

Hydraulics

Hydraulic System Type	Closed-Center System with Low Stand-By Pressure and Load-Sensing Control
Pump Rated Output	Standard: 155 L/min (41 gpm); Optional: 210 L/min (55 gpm)
Maximum Operating Pressure	2973 psi
Maximum Operating Pressure	205 bar
Number of Rear Selective Control Valves (SCVs)	Four
Number of Mid Selective Control Valves (SCVs)	3
SCV Control	Electrohydraulic

Front Axle

Front Axle Type	Standard: Mechanical Front Wheel Drive axle; Optional: Triple Link Suspension (TLS™)
Front Axle Differential Lock	Yes

Rear Axle

Rear Axle Type	Inboard planetary three pinion
Rear Differential Lock	Yes
Differential Controls	Yes
Final Drive	Three planetary gear reduction

Steering & Brakes

Steering Type	Dynamic Load Sensing, Hydrostatic, Flow Metering
Primary Brakes	Oil-cooled, self-equalizing, self-adjusting, hydraulically actuated
Secondary Brake	Lever right hand side at console, hydraulically actuated, integrated into rear axle service brake
Trailer Brakes	Optional: Air and/or hydraulic
Parking Brake	Integrated parking brake

Tires

Front Tires Size	420/85R30
Rear Tires Size	520/85R42

Electrical System

Battery Voltage	12 V
Electrical System Voltage	12 V
Battery Cold Cranking Amps	1800 CCA
Battery Capacity	2x 95 Ah
Alternator Capacity	250 A
Working Lights	Yes
Driving Lights	No

Operator Station

Gearshift Location	CommandArm™
Db(A) Rating	70 dBA
Seat Suspension	Suspension with automatic weight adjustment
Degree of Seat Swivel, Left Hand	7 degree (angle)
Degree of Seat Swivel, Right Hand	15 degree (angle)
Cab Suspension	Yes
Instructional Seat	Yes
Primary Display	Cornerpost Display
Radio	Standard
Inner Cab Volume	106 cu ft
Inner Cab Volume	3 m³
Cab Glass Area	52.2 sq ft
Cab Glass Area	4.85 m²

Technology Integration

Guidance	SF-RTK
Secondary Display	10,1 / 12.8 inch Command Center Display
Receiver	Universal StarFire™ 7500
Connectivity	JDLink™ Modem
Remote Diagnostics	Yes
ISOBUS Ready	Yes

Capacities

Fuel Tank Capacity	108.3 gal.
Fuel Tank Capacity	410 L
Diesel Exhaust Fluid (DEF) Tank Capacity	6.6 gal.
Diesel Exhaust Fluid (DEF) Tank Capacity	25 L
Cooling System Capacity	9 gal.
Cooling System Capacity	34 L
Transmission - Hydraulic System	21.1 gal.
Transmission - Hydraulic System	80 L
Crankcase Oil Volume	6.2 gal.
Crankcase Oil Volume	23.5 L

Dimensions & Weights

Wheelbase	114 in.
Wheelbase	2900 mm
Base Machine Weight	21164 lb.
Base Machine Weight	9600 kg
Overall Height	126 in.
Overall Height	3200 mm
Transport Height	126 in.
Transport Height	3200 mm
Overall Width	100.3 in.
Overall Width	2550 mm
Overall Length	200.2 in.
Overall Length	5084 mm
Front Axle Ground Clearance	21.4 in.
Front Axle Ground Clearance	545 mm
Maximum Permissible Weight	31306 lb.
Maximum Permissible Weight	14200 kg

Additional Information

Country of Manufacture	Germany
Date Collected	8-Jun-26
