John Deere 6M 145 Open Operator Station

No items found.

Utility Tractors

John Deere 6M 145 Open Operator Station

Starting at

Key Features

Multiple Transmission Choices With Creeper Available
Factory-Installed JDLink™ Modem
Closed Center Hydraulics
Rear Hitch Lift Capacity - Standard: 7,048 lb. (3,200 kg); Optional: 7,930 lb. (3,600 kg)

Precision Technology to Help Improve Efficiency

Precision ag technology availability includes AutoTrac™ guidance readiness, JDLink™ connectivity, and an intuitive corner post display to help operators improve accuracy, efficiency, and uptime.

Activation required. JDLink hardware comes standard with the machine. You can turn on JDLink Connected service in your John Deere Operations Center™ account for free. JDLink requires a cellular connection to transfer information from machine to a JDLink website. Consult your John Deere dealer for coverage availability.

Operator seated on an open‑station John Deere tractor, viewed from above, holding a smartphone near the steering wheel; green hood, control levers, warning decals, and dirt roadway visible in an outdoor work setting.

PowrQuad™ Transmission

PowrQuad™ transmissions feature a partial PowerShift™ technology. An operator selects a desired range using the range lever on the right-hand console and the gears using the gear lever right beside the range lever. For specialty uses like vegetable, orchard and other operations that need extremely slow speeds, creeper speeds are available with the PowrQuad™ transmission.

Operator seated on an open‑station John Deere tractor, holding the steering wheel and control levers; green hood with John Deere branding, instrument panel, and yellow seat visible while working on a dirt field.

6M Open Operator Station

Open station tractors offer great visibility, which can be crucial for tasks that require precise maneuvering, such as working in tight spaces or around obstacles.

Machine Configuration

Wheel or Track Configuration	Wheel
Drive Type	MFWD

Engine

Engine Make	John Deere
Engine Model	John Deere PowerTech™ PVS
Engine Family	VJDXL06.8312
Emissions Certifications	Final Tier 4
Displacement	418 cu in.
Displacement	6.8 L
Aspiration	Turbocharged, variable geometry turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation
Number of Cylinders	6
Cylinder Liners	Wet-sleeve
Aftertreatment Type	Diesel Particle Filter (DPF) with Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) using DEF
Rated Engine Speed	2100 rpm
Rated Engine Power	143 hp
Rated Engine Power	107 kW
Rated Engine Power	145 PS
Maximum Engine Speed	1900 rpm
Maximum Engine Power	157 hp
Maximum Engine Power	117 kW
Maximum Engine Power	160 PS
Maximum Engine Torque	679 Nm 501 lb-ft
Constant Power Range	1,550 - 2,100 rpm
Power Bulge	10 %
Bore and Stroke	4.2 x 5.0 in.
Bore and Stroke	106.5 x 127 mm
Compression Ratio	16.7:1
Lubrication	Pressure lubrication
Cooling System Type	Liquid
Fuel Type	Ultra-low sulfur diesel
Air Cleaner Type	PowerCore® G2 Air Filter with pre-cleaning
Torque Rise	40 %

Transmission

Transmission Type	Standard: John Deere 16-speed PowrQuadTM 19 mph (30 km/h)
Maximum Speed Forward	30 km/h 19 mph
Minimum Speed Forward	2.5 km/h 1.6 mph
Cruise Control	Yes

Rear Power Take-Off (PTO)

Rated PTO Power	115 hp
Rated PTO Power	86 kW
Rated PTO Power	117 PS
Engine rpm at Rated PTO Speeds (540/1.000)	2010/1997
Number of Splines	1000: 21 / 540: 6

Rear Hitch

Rear Hitch Category (SAE Designation)	Category 3/3N
Maximum Lift Capacity Directly at Coupling Points	Standard: 6,800 kg 14,990 lb Optional: 7,650 kg 16,860 lb
Lift Capacity Through Full Lift Range Directly at Coupling Points	Standard: 4,000 kg 8,810 lb Optional: 4,500 kg 9,920 lb
Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point	Standard: 3,500 kg 7,710 lb Optional: 3,950 kg 8,700 lb
Sensing Type	Electronic at lower link
Draft Control Sensing	Yes

Drawbar

Drawbar Category	Category 2
Maximum Vertical Load	1200-2000 kg (2646-4409 lb)

Hydraulics

Hydraulic System Type	Closed-Center System with variable displacement hydraulic pump and Load-Sensing Control
Pump Rated Output	114 L/min 30 gpm
Maximum Operating Pressure	2970 psi
Maximum Operating Pressure	205 bar
Number of Rear Selective Control Valves (SCVs)	Three
SCV Control	Mechanical

Front Axle

Front Axle Type	Standard: Mechanical front wheel drive (MFWD) Optional: Triple Link Suspension (TLS™)
Front Axle Differential Lock	Yes

Rear Axle

Rear Axle Type	Standard: flange-type rear axle Optional: Rack-and-pinion rear axle - 92-mm (3.62 in.) shaft (2550-mm/104.0 in.)
Rear Differential Lock	Yes
Differential Controls	Yes
Final Drive	Three planetary gear reduction

Steering & Brakes

Steering Type	Dynamic Load Sensing, Hydrostatic, Flow Metering
Primary Brakes	Oil-cooled, self-adjusting, hydraulically actuated
Parking Brake	Manual Transmission Park Lock

Tires

Front Tires Size	9.5-16 in. BIAS
Rear Tires Size	14.9-24 in. 8PR R1 Bias

Electrical System

Battery Voltage	12 V
Electrical System Voltage	12 V
Working Lights	Yes
Driving Lights	No

Operator Station

Gearshift Location	Right hand console
Seat Suspension	Mechanical suspension with operator presence switch
Primary Display	Integrated into dashboard

Technology Integration

Guidance	SF-RTK
Connectivity	JDLink™ Modem

Capacities

Fuel Tank Capacity	75.3 gal.
Fuel Tank Capacity	285 L
Diesel Exhaust Fluid (DEF) Tank Capacity	5.3 gal.
Diesel Exhaust Fluid (DEF) Tank Capacity	20 L
Cooling System Capacity	7.2 gal.
Cooling System Capacity	27.4 L
Transmission - Hydraulic System	16.6 gal.
Transmission - Hydraulic System	63 L
Crankcase Oil Volume	6.2 gal.
Crankcase Oil Volume	23.5 L

Dimensions & Weights

Wheelbase	108.9 in.
Wheelbase	2765 mm
Base Machine Weight	16645 lb.
Base Machine Weight	7550 kg
Overall Height	121 in.
Overall Height	3061 mm
Transport Height	121 in.
Transport Height	3061 mm
Overall Width	100.4 in.
Overall Width	2550 mm
Overall Length	186.3 in.
Overall Length	4733 mm
Front Axle Ground Clearance	21.1 in.
Front Axle Ground Clearance	535 mm
Drawbar Ground Clearance	19.4 in.
Drawbar Ground Clearance	493 mm
Maximum Permissible Weight	22900 lb.
Maximum Permissible Weight	10400 kg

Additional Information

Country of Manufacture	Germany
Date Collected	8-Jun-26
