Operators can easily find the right working speed using push-button gear shifting, while PowrQuad™ PLUS and Powr8™ transmissions boost productivity with clutchless hydraulic shifting between forward and reverse. The ergonomically placed control lever and fingertip directional switch streamline gear changes and direction shifts, reducing clutch wear and enhancing efficiency in tight spaces.
Enjoy an 80% improvement in upward visibility with clear sightlines for easier operation when lifting bales or doing loader work above the cab with the Panorama roof on the premium cab.
Compared to previous models.
Whether it’s added on or available from the factory, an abundance of technology options are available. From AutoTrac™ to JDLink™ to GreenStar™/ISOBUS ready, your John Deere Dealer can help you decide what technology options are available to bring more efficiency to your operation.
Answer text goes here
Machine Configuration | ||||||||||||||||||||||
| Wheel or Track Configuration | Wheel | |||||||||||||||||||||
Engine | ||||||||||||||||||||||
| Engine Make | John Deere PowerTech™ 4045 PWS | |||||||||||||||||||||
| Emissions Certifications | Final Tier 4 | |||||||||||||||||||||
| Aspiration | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Wastegate Turbocharger with intercooler and eventually cooled Exhaust Gas | Turbocharged | Turbocharged and air-to-air aftercooled | Turbocharged and Aftercooled | Turbocharged and Aftercooled | Turbocharged | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged and Aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged/Air-to-Air Aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged | Turbocharged |
| Cylinder Liners | Wet sleeved | |||||||||||||||||||||
| Aftertreatment Type | EGR/DOC/DPF/SCR | |||||||||||||||||||||
| Rated Engine Power | 130 hp | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | At 2100 rpm: 55 kW 75 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | At 2400 rpm: 67.1 kW 90 hp | At 2400 rpm: 67.1 kW 90 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | At 2400 rpm: 74.6 kW 100 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 99.7 kW 130 hp |
| Rated Engine Power | 96 kW | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | At 2100 rpm: 55 kW 75 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | At 2400 rpm: 67.1 kW 90 hp | At 2400 rpm: 67.1 kW 90 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | At 2400 rpm: 74.6 kW 100 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 99.7 kW 130 hp |
| Rated Engine Power | 131 PS | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | At 2100 rpm: 55 kW 75 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | At 2400 rpm: 67.1 kW 90 hp | At 2400 rpm: 67.1 kW 90 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | At 2400 rpm: 74.6 kW 100 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 99.7 kW 130 hp |
| Maximum Engine Power | 134 hp | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 55 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | 68.6 kW 92 hp | 68.6 kW 92 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | 76.0 kW 102 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.7 kW 135.5 hp |
| Maximum Engine Power | 100 kW | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 55 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | 68.6 kW 92 hp | 68.6 kW 92 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | 76.0 kW 102 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.7 kW 135.5 hp |
| Maximum Engine Power | 136 PS | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 55 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | 68.6 kW 92 hp | 68.6 kW 92 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | 76.0 kW 102 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.7 kW 135.5 hp |
| Maximum Engine Torque | 437 Nm / 322 lb-ft | |||||||||||||||||||||
Transmission | ||||||||||||||||||||||
| Transmission Type | PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | SyncShuttle™ 9F/3R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser Hi-Lo 32F/16R | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | OOS: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper |
| Creeper | Powr8™ 32F/16R with creeper | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Yes | Yes | Yes | Not available | Not available | Not available | Yes | Yes | Powr8™ 32F/16R with creeper | Not available | Yes | Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper |
| Reverser | Yes | No | SyncShuttle™: No PowrReverser™: Yes | SyncShuttle™: No PowrReverser™: Yes | SyncShuttle™: No PowrReverser™: Yes | Yes | Yes | Yes | Left hand, electrohydraulic | Yes | Yes | Yes | Yes | Left hand, electrohydraulic | Yes | Yes | Left hand, electrohydraulic | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Yes | Yes |
| Clutch | Wet | Dry | SyncShuttle™: Dry PowrReverser™: Wet | SyncShuttle™: Dry PowrReverser™: Wet | SyncShuttle™: Dry PowrReverser™: Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet |
Rear Power Take-Off (PTO) | ||||||||||||||||||||||
| PTO Category | Standard: 540/540E/1000 | |||||||||||||||||||||
| Optional PTO Category | 540/540E/1000 | |||||||||||||||||||||
| Engagement Method | Electrohydraulic | |||||||||||||||||||||
Front Hitch | ||||||||||||||||||||||
| Front Hitch Category | Category 2 | Category 2 | Category 2 | Cab: Category 2 | Category 2 | Cab: Category 2 | Cab: Category 2 | |||||||||||||||
Rear Hitch | ||||||||||||||||||||||
| Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 1/Category 2 | Category 1/Category 2 | Category 1/Category 1N | Category 2; convertible to 1 | Category 2 | Category 2 | Category 1/Category 2 | Category 1/Category 1N | Category 2; convertible to 1 | Category 2 | Category 1/Category 2 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2 | Category 2; convertible to 1 | Category 2 | Category 2 |
| Sensing Type | Top link | Top link | Top link | Top link | Top link | Top Link Draft Sensing | Top Link Draft Sensing | Top Link Draft Sensing | Lower link | Top link | Top link | Top Link Draft Sensing | Top Link Draft Sensing | Lower link | Top link | Top Link Draft Sensing | Lower link | Lower Link | Top link | Lower link | Top link | Top link |
| Draft Control Sensing | Electrohydraulic | |||||||||||||||||||||
Drawbar | ||||||||||||||||||||||
| Drawbar Category | Category 2 | Optional Extendable Category 1 and 2 | Extendable | Extendable | Category 2 | Category 2 | Category 2 | Extendable | Extendable | Category 2 | Category 2 | Extendable | Category 2 | Category 2 | Category 2 | Category 2 | Category 2 | Category 2 | ||||
| Maximum Vertical Load | Road/field use (250-mm extended): 1450 kg / 3197 lb; Field use (350-mm extended): 1200 kg / 2646 lb; Field use (400-mm extended): 1200 kg / 2646 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | ||||||
Hydraulics | ||||||||||||||||||||||
| Hydraulic System Type | Pressure-and-flow compensated (PFC) system | Open center | Open Center | Open center | Open center | Open Center | Open Center | Open Center | Open center | Open center | Open center | Open Center | Open Center | Open center | Open center | Open Center | Open center | Open Center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Open center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Pressure-and-flow compensated (PFC) system |
| Pump Rated Output | 117 L/min / 31 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | 94 L/min 24.7 gpm | 85.1 L/min 22.5 gpm | 85.1 L/min 22.5 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | 85.1 L/min 22.5 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | 94 L/min 24.7 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | 117 L/min 31 gpm |
| Available Flow at a Single Rear SCV | 100 L/min / 26.4 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 41.6 L/min 11 gpm | 66.2 L/min 17.6 gpm | 41.6 L/min 11 gpm | 70 L/min 18.4 gpm | 60.1 L/min 15.9 gpm | 60.1 L/min 15.9 gpm | 41.6 L/min 11 gpm | 41.6 L/min 11 gpm | 70 L/min 18.4 gpm | 60.1 L/min 15.9 gpm | 41.6 L/min 11 gpm | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | 70 L/min 18.4 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 L/min | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 gpm | 100 L/min 26.4 gpm |
| SCV Control | Rear SCVs: Mechanical, Mid-SCVs: Electrohydraulic | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic |
Front Axle | ||||||||||||||||||||||
| Front Axle Type | Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Carraro Drivetech | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) Optional: Two-Wheel Drive (2WD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) Optional: Two-Wheel Drive (2WD) | Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) Optional: Two-Wheel Drive (2WD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) |
Rear Axle | ||||||||||||||||||||||
| Rear Axle Type | Flange | Flange | Flange | Flange | Flange | Carraro Drivetech | Carraro Drivetech | Carraro Drivetech | Flange | Flange | Flange | Carraro Drivetech | Carraro Drivetech | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange | Carraro Drivetech | Standard: Flange Optional: Rack-and-pinion (Bar) | High-Crop Flange Drop Axle | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange | Flange |
| Rear Differential Lock | Electrohydraulic | |||||||||||||||||||||
| Differential Controls | Electrohydraulic | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Multi disk oil cooled design | Multi disk oil cooled design | Multi disk oil cooled design | Electrohydraulic | Mechanical (pedal) | Mechanical (pedal) | Multi disk oil cooled design | Multi disk oil cooled design | Electrohydraulic | Mechanical (pedal) | Multi disk oil cooled design | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic |
| Final Drive | Inboard planetary | Planetary | Planetary | Planetary | Planetary | Three point inboard planetary drives | Three point inboard planetary drives | Three point inboard planetary drives | Inboard planetary | Inboard planetary | Inboard planetary | Three point inboard planetary drives | Three point inboard planetary drives | Inboard planetary | Inboard planetary | Three point inboard planetary drives | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary |
Steering & Brakes | ||||||||||||||||||||||
| Primary Brakes | Hydraulic wet disc | |||||||||||||||||||||
| Secondary Brake | Yes, when equipped with Hydraulic trailer brakes | Cab: Yes, when equipped with Hydraulic trailer brakes | Cab: Yes, when equipped with Hydraulic trailer brakes | Cab: Yes, when equipped with Hydraulic trailer brakes | ||||||||||||||||||
| Trailer Brakes | Optional | Cab: Optional | Cab: Optional | Cab: Optional | ||||||||||||||||||
Tires | ||||||||||||||||||||||
| Rear Tires Size | 19.5L–24 in. 10PR R4 Bias | |||||||||||||||||||||
| Wheel Tread Range | Front: 1299–1997 mm / 51.1–78.6 in | 2WD: front: 1520-2020 mm 59.8-79.5 in. rear: 1349-2055 mm 53.1-80.9 in. MFWD: front: 1299-1997 mm 51.1-78.6 in. | MFWD: front: 1340-1904 mm 52.8-75.0 in. | Front: 1705-1834 mm 67.1-72.2 in. | 2WD: front: 1520-2020 mm 59.8-79.5 in. MFWD: front: 1299-1997 mm 51.1-78.6 in. rear: 1350-2286 mm 53.1-90 in. | MFWD: front: 1340-1904 mm 52.8-75.0 in. | 2WD: front: 1520-2020 mm 59.8-79.5 in. MFWD: front: 1299-1997 mm 51.1-78.6 in. rear: 1350-2286 mm 53.1-90 in. | MFWD: 1340-1904 mm 52.8-75.0 in. | Front: 1299-1997 mm 51.1-78.6 in. | MFWD: front: 1299-1997 mm 51.1-78.6 in. rear: 1350-2286 mm 53.1-90 in. | Front: 1299-1997 mm 51.1-78.6 in. | Front: 1299-1997 mm 51.1-78.6 in. | ||||||||||
Electrical System | ||||||||||||||||||||||
| Alternator Capacity | 120 amp; ISOBUS/GreenStar™ Ready: 200 amp | |||||||||||||||||||||
| Working Lights | Standard: Halogen; Optional: LED | Halogen | Standard: Halogen Premium Cab: LED | Standard: Halogen Premium Cab: LED | Standard: Halogen Premium Cab: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Halogen | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Halogen | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED |
| Driving Lights | Standard: Halogen; Optional: LED | |||||||||||||||||||||
Operator Station | ||||||||||||||||||||||
| ROPS Type | Foldable, two-post | |||||||||||||||||||||
| Gearshift Location | Floor | |||||||||||||||||||||
| Seat Suspension | Air Ride | |||||||||||||||||||||
| Instructional Seat | Not Available | Not Available | Optional | Optional | Optional | Optional | Kit available for Cab | Optional | Kit available for Cab | Optional | Optional | Not Available | Optional | Not Available | Not Available | |||||||
| Primary Display | Digital Dash Display with three liquid crystal displays (LCDs) | |||||||||||||||||||||
| Radio | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | ||||||||||
Technology Integration | ||||||||||||||||||||||
| Guidance | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | |||||||||||||||
| Connectivity | JDLink™ Modem | |||||||||||||||||||||
| Remote Diagnostics | Yes | Yes | Yes | Yes | ||||||||||||||||||
| ISOBUS Ready | Optional for cab models | No | No | No | No | No | No | No | No | No | No | No | No | Optional with PowrQuad™ PLUS/Powr8™ models | No | No | Optional with PowrQuad™ PLUS/Powr8™ models | No | Optional for cab models | Optional with PowrQuad™ PLUS/Powr8™ models | Optional for cab models | Optional for cab models |
Capacities | ||||||||||||||||||||||
| Fuel Tank Capacity | 29.6 (PowrReverser™) / 38.0 (PowrQuad™ PLUS/Powr8™) gal. | |||||||||||||||||||||
| Fuel Tank Capacity | 112 (PowrReverser™) / 144 (PowrQuad™ PLUS/Powr8™) L | |||||||||||||||||||||
Additional Information | ||||||||||||||||||||||
| Country of Manufacture | Pune, India | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Rovigo, Italy | Rovigo, Italy | Rovigo, Italy | Pune, India | Saltillo, Mexico | Saltillo, Mexico | Rovigo, Italy | Rovigo, Italy | Pune, India | Saltillo, Mexico | Rovigo, Italy | Pune, India | Pune, India | Saltillo, Mexico | Pune, India | Saltillo, Mexico | Saltillo, Mexico |
| Date Collected | 2023_01_06T00:00:00.0000000 | 6-Jan-2023 | 6-Jan-2023 | 31-May-2022 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 |
