This model incorporates an advanced Electronic Quick Raise-Lower (EQRL) hitch control system, which simplifies headland turns. EQRL enables effortless adjustments of rear implements, making fieldwork more efficient and less time-consuming.

Hydrostatic power steering ensures smooth and steady maneuvering, even under load. Ideal for loader operations, it enhances operator control, maximizing efficiency and performance in all conditions.

Experience year-round comfort with a climate-controlled cab, featuring an air suspension seat and ergonomic control layout. Enhanced visibility is provided through LCD displays with LED lights, offering clear and crisp information at a glance.

Answer text goes here
Wheel or Track Configuration | Wheel |
Engine Make | John Deere PowerTech™ 3029 EWX |
Engine Model | John Deere PowerTech™ 3029 EWR |
Engine Family | NJDXL02.9339 |
Emissions Certifications | Final Tier 4 |
Displacement | 179 cu in. |
Displacement | 2.9 L |
Aspiration | Turbocharged |
Number of Cylinders | 3 |
Cylinder Liners | Wet sleeved |
Aftertreatment Type | DOC/EGR |
Rated Engine Speed | 2100 rpm |
Rated Engine Power | 75 hp |
Rated Engine Power | 55 kW |
Rated Engine Power | 75 PS |
Maximum Engine Power | 74 hp |
Maximum Engine Power | 55 kW |
Maximum Engine Power | 75 PS |
Fuel Type | Diesel |
Torque Rise | 22 % |
Transmission Type | Standard: SyncShuttle 9F/9R; Optional: PowrReverser 12F/12R; Optional: eHydro™ |
Creeper | Kit Available |
Clutch | SyncShuttle™: Dry; PowrReverser™: Wet |
PTO Category | SyncShuttle™ : Independent 540; PowrReverser™/eHydro™ : Independent 540/540E |
Maximum PTO Power | 61.3 hp |
Maximum PTO Power | 45.7 kW |
Engine rpm (at Maximum PTO Speeds) | 1650 rpm |
Economy PTO Speeds | 540/540E |
Engine rpm at Rated PTO Speeds (540/1.000) | 2100 |
Engine rpm at Rated PTO Speeds (540/540E/1.000) | 1588 |
Engagement Method | SyncShuttle™: Mechanical (lever); PowrReverser™: Electrohydraulic |
Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 |
Maximum Lift Capacity at 610-mm Behind Hitch Point | 3,192 lb. (1,448 kg) |
Sensing Type | Top link |
Draft Control Sensing | Mechanical |
Drawbar Category | Basic Drawbar |
Maximum Vertical Load | Road/field use (short position): 1120 kg 2470 lb; Field use (fully extended): 760 kg 1675 lb |
Hydraulic System Type | Open center |
Pump Rated Output | 18.2 gpm (68.6 L/min) - PR/TSS (2 Pumps Engine Mouted); 29.6 gpm (112 L/min) - HST (3 Pumpes (2 Engine mounted and 1 Drive Train Mounted) |
Number of Rear Selective Control Valves (SCVs) | Standard: one; Optional: two |
Available Flow at a Single Rear SCV | 43.1 L/min 11.4 gpm |
SCV Control | Mechanical |
Front Axle Type | Standard: Two-Wheel Drive (2WD); Optional: Mechanical Front Wheel Drive (MFWD) |
Rear Axle Type | Flange |
Rear Differential Lock | Yes |
Differential Controls | Mechanical (pedal) |
Final Drive | Planetary |
Steering Type | TSS: Fixed; PR/eHydro™ : Tilt or Tilt/Telescoping |
Primary Brakes | Hydraulic wet disc |
Parking Brake | Park pawl brake |
Front Tires Size | Front 11L-15 in. 8PR F2-M Bias / Rear 14.9-28 In. 6PR R1 Bias |
Battery Voltage | 12 V |
Battery Capacity | 800 CCA** with 145 Minute Reserve Capacity |
Alternator Capacity | Open Station - 60 Amp Alternator; Cab - 110 Amp Alternator |
Working Lights | LED |
Driving Lights | LED |
ROPS Type | Rollover protective structure, OOS |
Gearshift Location | Floor on floor |
Seat Suspension | Standard: Mechanical; Optional: Air Suspension; Air Suspension with Swivel |
Degree of Seat Swivel, Left Hand | 7 degree (angle) |
Degree of Seat Swivel, Right Hand | 15 degree (angle) |
Instructional Seat | Kit Available |
Primary Display | NGPD |
Radio | Bluetooth Optional |
Connectivity | JDLink™ Modem |
Fuel Tank Capacity | 19 U.S. gal. |
Fuel Tank Capacity | 72.5 L |
Wheelbase | 80.7 in. |
Wheelbase | 2050 mm |
Base Machine Weight | 5445 lb. |
Base Machine Weight | 2470 kg |
Country of Manufacture | India |
Date Collected | 5/8/2026 |
