All Frontier™ Wood Chipper models are compatible with the iMatch™ ASAE Category 1 quick-attach hitch system. iMatch converts your tractor’s 3-point hitch to fixed hooks and attaching points for quick and easy connection. (iMatch hitch sold separately.)

The hydraulic feed roll handles a variety of wood sizes. Adjustable spring tension lets you choose the setting needed in your operation, so you can tackle big jobs faster.

This chipper includes a 360-degree rotating discharge chute that provides fast and easy positioning. The adjustable deflector accurately directs wood chips to the desired location, enhancing user convenience and operational efficiency.

Answer text goes here
Dimensions | ||||||||
| Chip Opening | 5.5x8 in. | 160 mm 6.31 in. | 152 mm 6 in. | 254x432 mm 10x17 in. | 178x381 mm 7x12 in. | 254x381 mm 10x15 in. | 203 mm 8 in. | 229 mm 9 in. |
| Chip Opening | 140x203 mm | 160 mm 6.31 in. | 152 mm 6 in. | 254x432 mm 10x17 in. | 178x381 mm 7x12 in. | 254x381 mm 10x15 in. | 203 mm 8 in. | 229 mm 9 in. |
| Hopper Opening | 28x28 in. | 762x1066 mm 30x42 in. | 660x889 mm 26x35 in. | 635x635 mm 25x25 in. | ||||
| Hopper Opening | 711x711 mm | 762x1066 mm 30x42 in. | 660x889 mm 26x35 in. | 635x635 mm 25x25 in. | ||||
Feed Options | ||||||||
| Feed Options - System | Hydraulic | Hydraulic | Power feed | Hydraulic feed | Hydraulic feed | Self feed | Manual (gravity) | Hydraulic |
| Feed Options - Hopper Height | 21 in. | |||||||
| Feed Options - Hopper Height | 53 cm | |||||||
Chip Chute | ||||||||
| Adjustable Chip Chute | Rotation: 360 degree (angle) | |||||||
Weights | ||||||||
| Unit | 775 lb. | 535 kg 1433 lb | 336 kg 900 lb | 746 kg 2000 lb | 485 kg 1300 lb | 373 kg 1000 lb | 330 kg 885 lb | 485 kg 1300 lb |
| Unit | 352 kg | 535 kg 1433 lb | 336 kg 900 lb | 746 kg 2000 lb | 485 kg 1300 lb | 373 kg 1000 lb | 330 kg 885 lb | 485 kg 1300 lb |
| Rotor Style | Disc | Drum | Drum | Disc | Disc | Disc | Disc | Disc |
| Rotor Weights | 165 lb. | |||||||
| Rotor Weights | 75 kg | |||||||
Tractor Compatibility | ||||||||
| PTO rpm | 540 rpm | 540 rpm | 540 rpm | 540-1000 rpm | 540-1000 rpm | 540-1000 rpm | 540 rpm | 540 rpm |
| HP Range (Tractor PTO hp) | 35-95 hp | 30-60 hp | 30-50 hp | 65-150 hp | 40-100 hp | 65-150 hp | 25-60 hp | 25-60 hp |
| HP Range (Tractor PTO hp) | 26-70.8 kW | 30-60 hp | 30-50 hp | 65-150 hp | 40-100 hp | 65-150 hp | 25-60 hp | 25-60 hp |
3-Point Hitch | ||||||||
| 3-Point Hitch Category | Category 1, Category 2 | Cat. 1 or pull type | Cat. 1 | 3 point | 3 point | 3 point | Cat. 1 and Cat. 2 | Cat. 1 and Cat. 2 |
Hydraulics | ||||||||
| Hydraulics Requirements | 22.7 L/min 6 gpm | 4-8 gpm | 3-6 gpm | |||||
| Self-Contained Hydraulics System | Optional | |||||||
Chipping | ||||||||
| Knife Quantity | Four | Two | Two | Four | Four | Four | Four | Four |
| Knife Size | 2.5x3.25x0.3125 in. | 19x7.6x0.953 mm 7.5x3x0.375 in. | 19x7.6x0.953 mm 7.5x3x0.375 in. | |||||
| Knife Size | 63.5x82.6x7.9 mm | 19x7.6x0.953 mm 7.5x3x0.375 in. | 19x7.6x0.953 mm 7.5x3x0.375 in. | |||||
| Knife Bolt | Hardened and recessed bolts: 9.5 mm 0.375 in. | |||||||
| Shear Bar | Adjustable hardened anvil | A8 tool steel | Hardened tool steel | Hardened tool steel | Hardened tool steel | |||
| Chipping Rotor rpm | 1380 rpm | 1512 rpm | 1450 rpm | |||||
Belt Drive System | ||||||||
| Belt Drive System - Number | Three | Six | Six | Direct Drive | Direct Drive | Direct Drive | Three | Three |
Setup Time | ||||||||
| Set-Up Time Labor Hours | 0.5 hr | |||||||
Warranty | ||||||||
| Warranty Time Period | 1 year | |||||||
