new
John Deere
TM5129
Compact Tractors Attachments

John Deere TM5129

Starting at

Dual wheels provide consistent disking depth

The TM51 Series Tandem Disk Harrow comes standard equipped with dual wheels for consistent disking depth. The dual wheels provide additional stability for even weight distribution during transport.

Close-up side view of the TM51 series tandem disk harrow's line of dual wheels resting on a golden field
End washers and wrenches keep gang shaft end nut tight

End washers help keep the gang shaft end nut tightened during operation, increasing gang wear life. Two gang nut wrenches are supplied with each unit and securely attached to the unit, ready to use when the gangs need tightening.

Close-up of an offset disk's end washer and nut, keeping gang tightened
Hydraulic wing control

Hydraulic wing control on Frontier™ TM51 Series Tandem Disk Harrows shifts weight to the wings for better soil penetration and uses adjustable pressure to prevent gouging, while a relief feature protects the cylinders from damage.

Close-up of tandem disk harrow with multiple hydraulic hoses connected to fittings and a pressure gauge mounted on the frame
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
TM5129
Tandem Disk Harrow
Rome
265-60
ADD MODEL

Transport

Transport - Width19.25 ft4.9 m
16.33 ft, in.
Transport - Width5.9 m4.9 m
16.33 ft, in.
Ground Clearance With Base Blades12 in.22.9 cm
9 in.
with disk blades: 66.0 cm
26 in.
Ground Clearance With Base Blades30.5 cm22.9 cm
9 in.
with disk blades: 66.0 cm
26 in.
Wheel Hub BearingsDual tapered roller bearingsTwo tapered roller bearings
Height14.5 ft4.3 m
14 in.
Height4.4 m4.3 m
14 in.
Length29.75 ft
Length9.1 m

Working Adjustments

Approximate Working Width29 ft7.6 m
25 in.
Approximate Working Width8.8 m7.6 m
25 in.
Maximum Penetration0.75 ft22.9 cm
9 in.
Maximum Penetration0.229 m22.9 cm
9 in.

Weight

Net22000 lb.22.9 cm
9 in.
Net9979 kg22.9 cm
9 in.
Weight Per Disk Blade314 lb.123.4 kg
272 lb
Weight Per Disk Blade142.4 kg123.4 kg
272 lb

Tractor Requirements

Recommended Drawbar HP Range260 + hp163.3-182.7 kW
219-245 hp
Recommended Drawbar HP Range193.9+ kW163.3-182.7 kW
219-245 hp

Frame

TypeTandem double offsetTandem
DutyGeneral purpose
Tube Size6x4x0.375 (15.2x10.2x0.95)
Main Frame Tube6x4x0.375 (15.2x10.2x0.95)

Hitch

Front Hitch TypeSpade

Disks

Spacing10.5 in.27.9 cm
11 in.
Spacing26.7 cm27.9 cm
11 in.
Quantity7460
Notched (Front) Notched (Rear)Standard
Smooth (Front) Smooth (Rear)Optional
Notched (Front) Smooth (Rear)Optional
Blade ConcavityStandard: high; Optional: lowOptional

Available blade sizes

Blade Option One26x0.312 in.660x7.9 mm
26x0.312 in.
Blade Option One660x7.9 mm660x7.9 mm
26x0.312 in.
Blade Option Two28x0.312 in.711x7.9 mm
28x0.312 in.
Blade Option Two711x7.9 mm711x7.9 mm
28x0.312 in.

Disk Gangs

Front Angle3 Positions degree (angle)Fixed angle
Rear Angle3 Positions degree (angle)Fixed angle
Axle Size1.625, 2.125 in.4.1 cm
1.625 in.
Axle Size4.1, 5.4 cm4.1 cm
1.625 in.
Axle MaterialRound heat treated alloy steel, threaded on both endsRound axle
Bearing TypeOil bath tapered rollerDual tapered roller bearings
Bearing Wear PlatesStandardStandard
Bearing StandardsWelded, reinforced
ScrapersAdjustableAdjustable

Lighting and Safety

MarkingsSMVSMV
Safety Tow ChainYes
LightsYes

Tires

TypeTwelve implementTandem
Size11L x 15 in. 8 ply
Wheel Hub Type8 Bolt

Setup Time

Labor HoursFor two people: 6-8 hours

Warranty

Time Period1 year
