John Deere
TM1048L
Compact Tractors Attachments

John Deere TM1048L

Starting at

Versatile Rear Hitch

The rear hitch was designed specifically with increased versatility in mind. The rear hitch enables a chain harrow to be attached. Attaching a chain harrow offers a fewer pass solution that helps improve soil finish, reducing time spent in the field.

Close‑up of a green agricultural frame showing a flat metal mounting plate with bolt holes and fasteners.
Disk Blades for a Variety of Conditions

Notched front and rear disk blades provide more aggressive soil penetration and versatility to create a finer soil finish. Individual gang angle adjustments enable notched front and rear disk blades to be easily adjusted for a finer soil finish than is typically seen with smooth disk blades.

Close-up of a disc harrow being pulled through soil, with angled metal discs cutting into the ground and kicking up dirt in a grassy field
Gang Angle Adjustments Made Easy

Each disk gang can be adjusted individually from outside of the frame, improving operator ease. This adjustment eliminates the need to reach into the frame, allowing precise disk angle settings for different soil types and finishes. Front and rear angles enable straighter tracking for a smoother finish.

Close-up of an L-shaped pin being adjusted on a green agricultural implement frame, with metal brackets, fasteners, and a tractor tire.
Question text goes here

Answer text goes here

Dimensions
Working Width

48 in.

Working Width

121.92 cm

Overall Width

50 in.

Overall Width

127 cm

Overall Height

34 in.

Overall Height

86.4 cm

Overall Length

52 in.

Overall Length

132 cm

Weight Per Disk

36 lb.

Weight Per Disk

16.3 kg

Shipping Weight

452 lb.

Shipping Weight

205 kg

Operating Weight

437 lb.

Operating Weight

198.2 kg

Disk Hillers
Disk Spacing

7.5 in.

Disk Spacing

19 cm

Disk Thickness

0.118 in.

Disk Thickness

3 mm

Disk Diameter

16 in.

Disk Diameter

40.6 cm

Number Of Disks

12

Front Gang Blade Type

Notched

Rear Gang Blade Type

Notched

Weight
Operating Weight

437 lb.

Operating Weight

198.2 kg

Shipping Weight

452 lb.

Shipping Weight

205 kg

Weight Per Disc

36 lb.

Weight Per Disc

16.3 kg

Tractor Requirements
Engine HP Range

11.2-18.6 (15-25) kW

Hitch
Category

Limited Category 1

iMatch / Quick Hitch

Yes

Type

Clevis with Pin

Height To Hitch Pins

14 in.

Height To Hitch Pins

35.6 cm

Disks
Spacing

7.5 in.

Spacing

19.05 cm

Quantity

12

Notched (Front) Notched (Rear)

Yes

Gang axle
Diameter

1 in.

Diameter

2.54 cm

Type

Square

Gang angles
Front Gang Angles

0,7,14,21 degree (angle)

Rear Gang Angles

0,5,12,19 degree (angle)

Adjustment

Tool-less

Tubing
Gang / Frame Tubing

2x3 rectangle with end caps
