new
John Deere
RB2309
Compact Tractors Attachments

John Deere RB2309

Starting at

Quickly and Efficiently Attach to Hitch

The Frontier™ RB23 and RB24 Series Rear Blades are Quik-Coupler compatible with Category 2 hitches, allowing a quick, efficient hookup.

Front view of an RB2308 rear blade grading grassy dirt on the back of a 5100R tractor
Manually adjustable angle, tilt, and offset

The turntable on the Frontier™ RB22, RB23 and RB24 Series Rear Blades allows a complete 360-degree turning radius for leveling perfection. Manually adjusting the offset, angle, and tilt allows the blade to adapt to a variety of conditions and provides added protection and leveling perfection.

Rear view of adjustable turntable on Frontier rear blade hooked up to a tractor in a field
Frame's tubular steel is crafted for tough jobs

The tough, tubular steel frame on Frontier™ RB Series Rear Blades is perfect for grading and its full-radius moldboard more than handles landscaping needs.

3038E Tractor with rear blade and front loader on dirt drive
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
RB2309
Rear Blade
Rhino
1540 - 10 foot working width
ADD MODEL

Dimensions

Width In Working Position9 ft3.0 m
10 ft
Width In Working Position2.7 m3.0 m
10 ft
Moldboard Length108 in.304.8 cm
120 in.
Moldboard Length274.3 cm304.8 cm
120 in.
Moldboard Height19 in.45.7 cm
18 in.
Moldboard Height48.3 cm45.7 cm
18 in.
Moldboard Thickness0.3125 in.1.27 cm
0.5 in.
Moldboard Thickness0.8 cm1.27 cm
0.5 in.

Weight

Machine1240 lb.639.1 kg
1,409 lb
Machine562.5 kg639.1 kg
1,409 lb
Shipping Per Unit1297 lb.
Shipping Per Unit588.3 kg

Tractor Requirements

PTO2WD: 120; 4WD: 110 hpMaximum: 141.7 kW
190 hp
PTO2WD: 89.5; 4WD: 82 kWMaximum: 141.7 kW
190 hp
Hydraulic Offset Kit (Hoses And Fittings Included)Up to three hydraulic remotes required

Angle, Tilt, Offset, Pivot

Pivot Angle Degrees360 degree (angle)360 degree (angle)
Angle Forward, Number Of PositionsThree positions each side, up to 45 degree (angle)
Angle Reverse, Number Of PositionsThree positions each side, up to 45 degree (angle)
Tilt Positions/DegreesThree positions, up and down, up to 23 degree (angle)
Offset Position Left or Right0-19 in.93.9 cm
37 in.
Offset Position Left or Right0-48.26 cm93.9 cm
37 in.

Hitch

TypeCategory 2Category 2 and Category 3
Quick Hitch CompatibilityASAE Category 2 quick coupler

Reversible Cutting Edge

Thickness0.5 in.1.27 cm
0.5 in.
Thickness1.3 cm1.27 cm
0.5 in.
Height6 in.45.7 cm
18 in.
Height15.2 cm45.7 cm
18 in.

Duty

TypeHeavyCategory 2 and Category 3

Parking Stand

Standard With MachineStandardStandard

Warranty

Time Period1 year
