new
John Deere
RB2307
Compact Tractors Attachments

John Deere RB2307

Starting at

Quickly and Efficiently Attach to Hitch

The Frontier™ RB23 and RB24 Series Rear Blades are Quik-Coupler compatible with Category 2 hitches, allowing a quick, efficient hookup.

Front view of an RB2308 rear blade grading grassy dirt on the back of a 5100R tractor
Manually adjustable angle, tilt, and offset

The turntable on the Frontier™ RB22, RB23 and RB24 Series Rear Blades allows a complete 360-degree turning radius for leveling perfection. Manually adjusting the offset, angle, and tilt allows the blade to adapt to a variety of conditions and provides added protection and leveling perfection.

Rear view of adjustable turntable on Frontier rear blade hooked up to a tractor in a field
Crafted for Tough Jobs

The tough, tubular steel frame on Frontier™ RB Series Rear Blades is perfect for grading. Its full-radius moldboard more than handles landscaping needs.

Front view of an RB21 rear blade grading a dirt road on the back of a tractor
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
RB2307
Rear Blade
Rhino
1540 - 10 foot working width
ADD MODEL

Dimensions

Width In Working Position7 ft3.0 m
10 ft
Width In Working Position2.1 m3.0 m
10 ft
Moldboard Length84 in.304.8 cm
120 in.
Moldboard Length213.4 cm304.8 cm
120 in.
Moldboard Height19 in.45.7 cm
18 in.
Moldboard Height213.4 cm45.7 cm
18 in.
Moldboard Thickness0.3125 in.1.27 cm
0.5 in.
Moldboard Thickness0.8 cm1.27 cm
0.5 in.

Weight

Machine1060 lb.639.1 kg
1,409 lb
Machine480.8 kg639.1 kg
1,409 lb
Shipping Per Unit1117 lb.
Shipping Per Unit506.7 kg

Tractor Requirements

PTO2WD: 120; 4WD: 110 hpMaximum: 141.7 kW
190 hp
PTO2WD: 89.5; 4WD: 82 kWMaximum: 141.7 kW
190 hp
Hydraulic Offset Kit (Hoses And Fittings Included)Up to 3 hydraulic remotes required

Angle, Tilt, Offset, Pivot

Pivot Angle Degrees360 degree (angle)360 degree (angle)
Angle Forward, Number Of PositionsThree positions each side, up to 45 degree (angle)
Angle Reverse, Number Of PositionsThree positions each side, up to 45 degree (angle)
Tilt Positions/DegreesThree positions, up and down, up to 23 degree (angle)
Offset Position Left or Right9-18 in.93.9 cm
37 in.
Offset Position Left or Right22.86-45.72 cm93.9 cm
37 in.

Hitch

TypeCategory 2Category 2 and Category 3
Quick Hitch CompatibilityASAE Category 2 quick coupler

Reversible Cutting Edge

Thickness0.5 in.1.27 cm
0.5 in.
Thickness1.3 cm1.27 cm
0.5 in.
Height6 in.45.7 cm
18 in.
Height15.2 cm45.7 cm
18 in.

Duty

TypeHeavyCategory 2 and Category 3

Parking Stand

Standard With MachineStandardStandard

Warranty

Time Period1 year
