The rear blade is compatible with iMatch™ quick-hitch systems, allowing for quick and efficient hookups with Limited Category 1 hitches. This feature enhances the ease of use and speeds up the setup process, making it an optimal choice for efficiency.

The turntable allows a 360-degree turning radius for optimal leveling. With three forward and three reverse angle positions, the manually adjustable blade angle and offset enable the user to adapt to various soil conditions for precise results.

The rear blade features a heavy, welded mast and a 4x4 steel frame, delivering strength and rigidity. This robust construction allows the full-radius moldboard to handle substantial loads, ensuring durability and reliability in demanding tasks.

Answer text goes here
Dimensions | ||||
| Width In Working Position | 5 ft | 1.8 m 5 ft | 1.8 m 5 ft | 1.8 m 5 ft |
| Width In Working Position | 1.8 m | 1.8 m 5 ft | 1.8 m 5 ft | 1.8 m 5 ft |
| Moldboard Length | 60 in. | 152.4 cm 60 in. | 152.4 cm 60 in. | 152.4 cm 60 in. |
| Moldboard Length | 152.4 cm | 152.4 cm 60 in. | 152.4 cm 60 in. | 152.4 cm 60 in. |
| Moldboard Height | 11 in. | 30.5 cm 12 in. | 34.3 cm 13.5 in. | |
| Moldboard Height | 27.9 cm | 30.5 cm 12 in. | 34.3 cm 13.5 in. | |
| Moldboard Thickness | 0.1875 in. | 0.64 cm 0.25 in. | 0.64 cm 0.25 in. | 0.79 cm 0.3125 in. |
| Moldboard Thickness | 0.5 cm | 0.64 cm 0.25 in. | 0.64 cm 0.25 in. | 0.79 cm 0.3125 in. |
Weight | ||||
| Machine | 155 lb. | 68 kg 150 lb | 64.9 kg 143 lb | 82.6 kg 182 lb |
| Machine | 70.3 kg | 68 kg 150 lb | 64.9 kg 143 lb | 82.6 kg 182 lb |
| Shipping Per Unit | 201 lb. | |||
| Shipping Per Unit | 91.2 kg | |||
Tractor Requirements | ||||
| PTO | 25 hp | Max: 18.6 kW 25 hp | 12.7-18.6 kW 17-25 hp | Max: 18.6 kW 25 hp |
| PTO | 18.6 kW | Max: 18.6 kW 25 hp | 12.7-18.6 kW 17-25 hp | Max: 18.6 kW 25 hp |
Angle, Tilt, Offset, Pivot | ||||
| Pivot Angle Degrees | 360 degree (angle) | 360 degree (angle) | 360 degree (angle) | 360 degree (angle) |
| Angle Forward, Number Of Positions | Each side: 0, 15, 30 degree | |||
| Angle Reverse, Number Of Positions | Each side: 0, 15 degree | |||
Hitch | ||||
| Type | Limited Category 1 (aftermarket Category 0 lift pins available) | Cat 1 | Cat 0 with Cat 1 Pins | Cat 0/Lim Cat 1 |
| Quick Hitch Compatibility | iMatch | |||
Reversible Cutting Edge | ||||
| Thickness | 0.5 in. | 0.64 cm 0.25 in. | 0.64 cm 0.25 in. | 0.79 cm 0.3125 in. |
| Thickness | 1.3 cm | 0.64 cm 0.25 in. | 0.64 cm 0.25 in. | 0.79 cm 0.3125 in. |
| Height | 6 in. | 30.5 cm 12 in. | 34.3 cm 13.5 in. | |
| Height | 15.2 cm | 30.5 cm 12 in. | 34.3 cm 13.5 in. | |
Duty | ||||
| Type | Economy | Cat 1 | Cat 0 with Cat 1 Pins | Cat 0/Lim Cat 1 |
Parking Stand | ||||
| Standard With Machine | Standard | Standard | Standard | |
Warranty | ||||
| Time Period | 1 year | |||
