All Frontier™ RB Series Rear Blade cutting edges are reversible, featuring bevels on both edges to give the blade twice the work life.

The Frontier™ RB20 and RB21 Series Rear Blades are all iMatch™ quick-hitch compatible and compatible with Category 1 hitches. Both systems provide a quick, efficient hookup.

The tough, tubular steel frame on Frontier™ RB Series Rear Blades is perfect for grading and its full-radius moldboard more than handles landscaping needs.

Answer text goes here
Dimensions | ||||
| Width In Working Position | 5 ft | 1.8 m 6 ft | 1.8 m 6 ft | 1.8 m 6 ft |
| Width In Working Position | 1.5 m | 1.8 m 6 ft | 1.8 m 6 ft | 1.8 m 6 ft |
| Moldboard Length | 60 in. | 182.9 cm 72 in. | 182.9 cm 72 in. | 182.9 cm 72 in. |
| Moldboard Length | 152.4 cm | 182.9 cm 72 in. | 182.9 cm 72 in. | 182.9 cm 72 in. |
| Moldboard Height | 14 in. | 36.8 cm 14.5 in. | 35.6 cm 14 in. | 35.6 cm 14 in. |
| Moldboard Height | 35.6 cm | 36.8 cm 14.5 in. | 35.6 cm 14 in. | 35.6 cm 14 in. |
| Moldboard Thickness | 0.3125 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. |
| Moldboard Thickness | 0.8 cm | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. |
Weight | ||||
| Machine | 249 lb. | 131.5 kg 290 lb | 122 kg 269 lb | 128.4 kg 283 lb |
| Machine | 112.9 kg | 131.5 kg 290 lb | 122 kg 269 lb | 128.4 kg 283 lb |
| Shipping Per Unit | 294 lb. | |||
| Shipping Per Unit | 133.4 kg | |||
Tractor Requirements | ||||
| PTO | 19-45 hp | Maximum: 26.1 kW 35 hp | 12.7-29.8 kW 17-40 hp | 8.9-29.8 kW 12-40 hp |
| PTO | 14.2-33.6 kW | Maximum: 26.1 kW 35 hp | 12.7-29.8 kW 17-40 hp | 8.9-29.8 kW 12-40 hp |
Angle, Tilt, Offset, Pivot | ||||
| Pivot Angle Degrees | 360 degree (angle) | 0, 15, 30 each side | 360 degree (angle) | 360 degree (angle) |
| Angle Forward, Number Of Positions | Each side: 0, 15, 30 degree | |||
| Angle Reverse, Number Of Positions | Each side: 0, 15 degree | |||
| Tilt Positions/Degrees | Three | |||
Hitch | ||||
| Type | Category 1 | Category 1 | Category 1 | Category 1 |
| Quick Hitch Compatibility | iMatch compatible (quick-attach system) | |||
Reversible Cutting Edge | ||||
| Thickness | 0.5 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. |
| Thickness | 1.3 cm | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. | 0.6 cm 0.25 in. |
| Height | 6 in. | 36.8 cm 14.5 in. | 35.6 cm 14 in. | 35.6 cm 14 in. |
| Height | 15.2 cm | 36.8 cm 14.5 in. | 35.6 cm 14 in. | 35.6 cm 14 in. |
Duty | ||||
| Type | Standard | Category 1 | Category 1 | Category 1 |
Parking Stand | ||||
| Standard With Machine | Yes | Yes | Yes | Yes |
Warranty | ||||
| Time Period | 1 year | |||
