John Deere
MS1102G
Compact Tractors Attachments

John Deere MS1102G

Starting at

Heavy-duty paddle beater assemblies

The heavy-duty paddle beater assemblies on the MS11 Series Small Manure Spreaders ensure aggressive shredding action, while the large-diameter beaters deliver greater tip speed for wide, even, and chunk-free spread patterns.

Front view of an MS11 manure spreader's black paddle beaters within the open, green container
Poly-Bonded Floor

All models come with a poly-bonded floor to reduce apron drag.

Top, rear view of an MS11 manure spreader and its poly-bonded floor beneath paddle beaters
Years of Trouble-Free Service

The manure spreaders sides are constructed of durable powder-coated steel.

MS1112 Manure Spreader on 5 series Tractor in field
Question text goes here

Answer text goes here

Capacity
Heaped

25 bu

Heaped

0.881 m³

Struck Level

13.6 cu ft

Struck Level

0.38 m³

Dimensions
Top Of Flare Width

28.5 in.

Top Of Flare Width

73 cm

Inside Width

22 in.

Inside Width

56 cm

Inside Length

72 in.

Inside Length

1.83 m

Inside Depth

17 in.

Inside Depth

43 cm

Horizontal Beater Configuration

9.1 ft

Horizontal Beater Configuration

2.77 m

Overall Width With Standard Tires

42 in.

Overall Width With Standard Tires

107 cm

Overall Loading Height - Top Of Flare

30 in.

Overall Loading Height - Top Of Flare

76 cm

Weight
Implement With Base Tire

350 lb.

Implement With Base Tire

159 kg

Towing Unit Minimum Weight

961 lb.

Towing Unit Minimum Weight

436 kg

Drive System
Chain Type

55

Ground Drive

Yes

Beaters
Lower

Yes

Lower

20 in.

Lower

51 cm

Paddles
Horizontal

8

Replaceable

No

Wheels And Tires
Tire Size

5x12

Spindle Size

1.25 in.

Spindle Size

3 cm

Hub Style

Greaseable

Axle

Single

Rear pan
Standard

No

Optional

Yes

Construction
Floor

Bonded poly

Box

Corrosion resistant galvanized steel

Setup Time
Labor Hours

0.5

Warranty
Time Period

1 year
