John Deere
LR2172
Compact Tractors Attachments

John Deere LR2172

Starting at

Strong 4x4 Steel Frame

A strong 4x4 steel frame supports an angled tine beam for superior performance.

Right side view of steel frame on LR21 Landscape Rake raking gravel around the outside of a baseball field
Steel Tines and Waffle Plates

Heat-treated steel tines are mounted with bolts and held secure with a steel waffle plate on the Frontier™ LR21 Series Medium-Duty Landscape Rake. This mounting ensures positive spacing and alignment, while providing increased strength and durability. These waffle plates also make replacement fast and easy, saving time and money.

Close-up view of a green metal attachment edge with several black vertical tines bolted along the top using silver hex bolts, shown against a blue sky
Quick Hookup With Category 1 and iMatch™ Hitches

The Frontier™ Medium-Duty Landscape Rake is 3-point hitch compatible with Category 1 and iMatch™ hitches, which ensures quick, efficient hookup.

Front view of the LR2184 landscape rake's frame and hitch connection to a tractor
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
LR2172
Landscape Rake
Bush Hog
MLR72-16
Woods
LR106-2
ADD MODEL

Dimensions

Working Width72 in.182.9 cm
72 in.
182.9 cm
72 in.
Working Width182.9 cm182.9 cm
72 in.
182.9 cm
72 in.

Weight

Operating282 lb.147.4 kg
325 lb
138.3 kg
305 lb
Operating138.3 kg147.4 kg
325 lb
138.3 kg
305 lb
Shipping400 lb.
Shipping181.4 kg

Tractor Compatibility

PTO Horsepower23-55 hpMax: 37.3 kW
50 hp
8.9-29.8 kW
12-40 hp
PTO Horsepower8.9-29.8 kWMax: 37.3 kW
50 hp
8.9-29.8 kW
12-40 hp

Hitch

CompatibilityCategory 1Max: 37.3 kW
50 hp
8.9-29.8 kW
12-40 hp

Tines

Quantity363636
Dimensions0.3125x1 in.182.9 cm
72 in.
182.9 cm
72 in.
Dimensions0.8x2.5 cm182.9 cm
72 in.
182.9 cm
72 in.
Spacing1 in.2.5 cm
1 in.
2.5 cm
1 in.
Spacing2.5 cm2.5 cm
1 in.
2.5 cm
1 in.

Raking angle

PositionsForward: 5; Reverse: 35 Forward, 3 Reverse5 forward, 5 reverse
Degrees0, 15, 30 degree (angle)0, 15, 300, 15, 30, 45 degree (angle)

Pivot

Degrees360 degree (angle)0, 15, 300, 15, 30, 45 degree (angle)

Parking Stands

StandardYesYesYes

Duty

TypeMedium

Warranty

Time Period1 year
