The scarifier shanks can be easily adjusted for depth control, helping to rip up hard ground and aggressively grade.

Frontier landplanes also offer reversible and replaceable cutting edges.

Skid shoes increase the life of the cutting edges on the land planes while avoiding damage to the working surface. The skid shoes are adjustable up and down on each side plate to allow for the creation of a crown on a road for water runoff. By replacing the skid shoes when needed, it will extend the life of the land plane.

Answer text goes here
Working Width | 72 in. |
Working Width | 182.9 cm |
Overall Width | 76 in. |
Overall Width | 193 cm |
Overall Height | 35 in. |
Overall Height | 88.9 cm |
Overall Length | 48 in. |
Overall Length | 121.9 cm |
Height To Hitch Pins | 16 in. |
Height To Hitch Pins | 40.6 cm |
Operating | 528 lb. |
Operating | 239.5 kg |
Shipping | 553 lb. |
Shipping | 250.9 kg |
Required PTO Horsepower | 25-50 hp |
Required PTO Horsepower | 18.6-37.3 kW |
Side Panel Thickness | 1/4 with Formed Edges |
Adjustable Skid Shoe Thickness | 0.38 in., 0.97 cm |
Adjustable Blade Depth | 0 to -2.5 via skid shoes |
Duty | Standard Duty |
Scarifiers Shank | Heat Treated; 4 Positions |
Number Of Scarifiers | 5 |
Depth Range | -2, 0, -2, -4 |
3-Point Compatibility | Cat 1 |
iMatch™ Compatible (Cat. 1) | Yes |
Hitch Type | Clevis with Pin |
Hitch Category | Cat 1 |
Reversible | Yes |
Replaceable | Yes |
Cutting Edge Material | High Carbon Heat Treated Blades |
Cutting Edge Dimensions | 3/8 X 6 |
Number Of Cutting Edges | 2 |
Thickness | 0.375 in. |
Thickness | 0.95 cm |
Time Period | 1 year |
Adjustable | 4 Position |
Heat Treated | Yes |
Quantity | 5 |
Scarifier Depth Range | 2, 0, -2, -4 in. |
Scarifier Depth Range | 5.08, 0, -5.08, -10.16 cm |
