John Deere
GS4048L
Compact Tractors Attachments

John Deere GS4048L

Starting at

Front Gangs

The GS40L Series equips users with a choice between front notched disc blades for cutting seed openings or aggressive tillage, and front spiked rollers that form seed pockets and can uproot existing vegetation when angled sharply, making it adaptable across diverse field conditions.

Tractor pulling a rear‑mounted tillage or soil‑preparation attachment across a field, with the implement churning dry soil and residue.
Spiked Drive Roller

Standard equipment on the GS40L, the spiked drive roller will crush clods, push down seeds, and dimple soil to trap moisture.

Side close-up of the notched disks, green frame, and spiked drive roller of a Frontier GS40L ground seeder
Nylon Cultipacker for Improved Germination

To increase germination, the in-base rear nylon cultipacker levels and breaks up soil clods, pressing the seed into the soil for improved seed-to-soil contact, firms the seed bed, and creates furrows to trap and channel water.

Rear view of tractor pulling a mounted seed drill across a field showing the metal hopper, warning triangle reflectors, and rotating soil-conditioning rollers working the ground.
Question text goes here

Answer text goes here

Dimensions
Working Width

48 in.

Working Width

121.9 cm

Overall Width

56.75 in.

Overall Width

144.2 cm

Weight
Spiked Roller And Primary Box

427 lb.

Spiked Roller And Primary Box

194 kg

Operational Weight

713 lb.

Operational Weight

323 kg

Tractor Compatibility
Horsepower

15-35 hp

Horsepower

11-26 kW

Capacity
Hopper Capacity

1 bu

Hopper Capacity

35.2 m³

Seedcups
Picker Wheels

6

Spike Roller
Front Roller Positions

Four positions

Front Roller Positions - Angle

0-21 degree (angle)

Number Of Roller Pins (Front And Rear)

144

Roller Diameter (Front And Rear)

6.6 in.

Roller Diameter (Front And Rear)

16.8 cm

Front Disc
Front Disc Angle

0 / 5 / 10 / 15 degree (angle)

Disc Type

Notched

Number Of Discs

6

Disc Diameter

16 in.

Disc Diameter

40.6 cm

Disc Spacing

7.5 in.

Disc Spacing

19 cm

Hitch
Category

Limited Category 1

3-Point Type

Limited Category 1

Quick Hitch Compatible

Yes

Cultipacker
Number

20

Diameter

9.5 in.

Diameter

24.1 cm

Setup Time
Labor Hours

1 hr

Warranty
Time Period

1 year
