End washers help keep the gang shaft end nut tightened during operation, increasing gang wear life. Two gang nut wrenches are supplied with each unit and securely attached to the unit, ready to use when the gangs need tightening.

Adjustable disk blade scrapers keep disk blades clean and performing in wet and sticky soils for increased productivity.

The clevis hitch has a durable design and is designed for ease of use, long life, and tough working conditions.

Answer text goes here
Transport | ||
| Transport - Width | 9 ft | |
| Transport - Width | 2.7 m | |
| Ground Clearance With Base Blades | 9 in. | |
| Ground Clearance With Base Blades | 22.9 cm | |
| Wheel Hub Bearings | Dual tapered roller bearings | Greasable Dual Tapered Bearings |
Working Adjustments | ||
| Approximate Working Width | 8 ft | 3.2 m 10.5 ft, in. |
| Approximate Working Width | 2.4 m | 3.2 m 10.5 ft, in. |
| Maximum Penetration | 0.75 ft | |
| Maximum Penetration | 0.229 m | |
Dimensions | ||
| Weight Per Disk | 533 lb. | 203.2 kg 448 lb |
| Weight Per Disk | 241.8 kg | 203.2 kg 448 lb |
Weight | ||
| Net | 8000 lb. | |
| Net | 3628.7 kg | |
| Weight Per Disk Blade | 533 lb. | 203.2 kg 448 lb |
| Weight Per Disk Blade | 241.8 kg | 203.2 kg 448 lb |
Tractor Requirements | ||
| Recommended PTO HP Range | 118-153 hp | 140.9-164.1 kW 189-220 hp |
| Recommended PTO HP Range | 88-114 kW | 140.9-164.1 kW 189-220 hp |
| Recommended Drawbar HP Range | 100-130 hp | 122.3-142.4 kW 164-191 hp |
| Recommended Drawbar HP Range | 74.6-96.9 kW | 122.3-142.4 kW 164-191 hp |
Frame | ||
| Type | Single Offset Rigid | |
| Duty | Heavy | |
| Tube Size | 6x6x0.375 in., 15.2x15.2x0.95 cm | |
| Main Frame Tube | 6x6x0.375 in., 15.2x15.2x0.95 cm | |
Hitch | ||
| Front Hitch Type | Spade | |
Disks | ||
| Spacing | 12 in. | 35.6 cm 14 in. |
| Spacing | 30.5 cm | 35.6 cm 14 in. |
| Quantity | 17 | 20 |
| Notched (Front) Notched (Rear) | Standard | |
| Blade Concavity | Standard: high, Optional: low | Standard |
Available blade sizes | ||
| Blade Option One | 28x0.375 in. | 813x9.5 mm 32x0.375 in. |
| Blade Option One | 711x9.5 mm | 813x9.5 mm 32x0.375 in. |
| Blade Option Two | 30x0.375 in. | |
| Blade Option Two | 762x9.5 mm | |
| Blade Option Three | 32x0.375 in. | |
| Blade Option Three | 813x9.5 mm | |
Disk Gangs | ||
| Front Angle | 2 Positions degree (angle) | Hydraulic gang angle adjustment |
| Rear Angle | 2 Positions degree (angle) | |
| Axle Size | 2.5 in. | 5.4 cm 2.125 in. |
| Axle Size | 6.4 cm | 5.4 cm 2.125 in. |
| Axle Material | Round heat treated alloy steel threaded on both ends | |
| Bearing Type | Oil bath tapered roller | Greasable Dual Tapered Bearings |
| Bearing Wear Plates | Standard | Standard |
| Bearing Standards | Welded, Reinforced | |
| Scrapers | Adjustable | Adjustable |
Lighting and Safety | ||
| Markings | SMV | SMV |
| Safety Tow Chain | Yes | |
| Lights | Yes | Optional |
Tires | ||
| Type | Implement- Quantity of 4 | |
| Size | 12.5L x 15 10 ply | |
| Wheel Hub Type | 8 Bolt | |
Setup Time | ||
| Labor Hours | 2-3 for two people | |
Warranty | ||
| Time Period | 1 year | |
