John Deere
CS1384
Compact Tractors Attachments

John Deere CS1384

Starting at

Rear cultipacker ensures good seed-to-soil contact

The rear cultipacker compresses and levels the seedbed, ensuring optimal seed-to-soil contact. With options of corrugated reinforced nylon and cast iron, and a torque arm for constant pressure, it enhances seedbed preparation.

Rear right studio view of the rear cultipacker on CS13 Conservation Seeder
Multiple Seedbox Configurations

CS Series seeders offer multiple seedbox configurations, including standard large-grain, native grass, small-seed legume, and fertilizer boxes, supporting diverse seeding needs and even enabling soil aeration and dethatching by disengaging boxes.

Left side studio view of CS Conservation Seeder showing the seedbox, spiked rollers, and rear cultipacker
Control the Ground Speed with Ground-Driven Spiked Rollers

The CS Series Seeders feature ground-driven spiked rollers allowing accurate ground speed control by turning the rear roller 40% faster. This enables precise seeding in both new and existing grass or pasture beds.

Side view of a green seeding machine showing an exposed chain‑and‑sprocket drive system with gears, idler wheels, and tensioners, above spiked ground‑engaging wheels
Question text goes here

Answer text goes here

Dimensions
Working Width

84 in.

Working Width

213 cm

Overall Width

98 in.

Overall Width

249 cm

Unit Length

76 in.

Unit Length

193 cm

Unit Height

54 in.

Unit Height

137 cm

Weight
Base Machine Weight

2090 lb.

Base Machine Weight

948 kg

Small Seed Box Weight

86 lb.

Small Seed Box Weight

39 kg

Stainless Steel Fertilizer Box Weight

231 lb.

Stainless Steel Fertilizer Box Weight

104.8 kg

Native Grass Box Weight

321 lb.

Native Grass Box Weight

145.6 kg

Second Large Seed Box Weight

231 lb.

Second Large Seed Box Weight

104.8 kg

Cast Iron Wheels Weight

245 lb.

Cast Iron Wheels Weight

111.1 kg

Tractor Compatibility
Minimum Power

50 hp

Minimum Power

37 kW

Hitch
3-Point Type Hitch

Category 1, Category 2

Quik-Coupler

Category 2

Box Capacity
Large Seed Box Capacity

8.25 bu

Large Seed Box Capacity

0.2907 m³

Fertilizer Box Capacity

8.25 bu

Fertilizer Box Capacity

0.2907 m³

Native Grass Seed Box Capacity

8.25 bu

Native Grass Seed Box Capacity

0.2907 m³

Legume, Small Seed Box Capacity

2.12 bu

Legume, Small Seed Box Capacity

0.0747 m³

Roller
Front Spike Outside Diameter

19.75 in.

Front Spike Outside Diameter

50 cm

Front Spike (Quantity)

132

Rear Spike Outside Diameter

19.75 in.

Rear Spike Outside Diameter

50 cm

Rear Spike (Quantity)

150

Nylon Rear Cultipacker

Standard

Cast Iron Rear Cultipacker

Optional

Spike Material

AR-500 steel

Drive ratio
Spike Roller Drive Ratio

15:20

Seed Box Drive Ratio

17:28

Setup Time
Setup Time Labor Hour

1 hr

Warranty
Warranty Time Period

1 year
