John Deere
BB5172
Compact Tractors Attachments

John Deere BB5172

Starting at

Replaceable and Adjustable Scarifiers

Replaceable heavy-duty scarifiers have multiple adjustment holes for quick and easy changes to shank penetration level. The scarifiers work great for the purposes of chipping or deep digging.

Side view of BB5072 Frontier Box Blade in field
Quick-Hitch System Attaches Easily

iMatch™ quick-hitch compatibility provides quick, efficient hookup. The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.

BB5048 Box Blade on Utility tractor on gravel road
Replaceable and Reversible Blade for Longevity

Rear replaceable steel cutting edge ensures precise leveling and a fine finish. The rear blade is reversible for longer life.

BB5072 Box Blade on utility tractor on gravel
Question text goes here

Answer text goes here

Dimensions
Working Width

72 in.

Working Width

183 cm

Unit Height

36 in.

Unit Height

91.4 cm

Unit Depth

32 in.

Unit Depth

81.3 cm

Endplate Thickness

0.5 in.

Endplate Thickness

1.27 cm

Moldboard Thickness

0.25 in.

Moldboard Thickness

0.64 cm

Weight
Operating Weight

720 lb.

Operating Weight

317.5 kg

Shipping Weight

745 lb.

Shipping Weight

337.9 kg

Tractor Compatibility
PTO Power

120 hp

PTO Power

86.48 kW

Hitch
Hitch Compatibility

Category 1 and 2

iMatch™ Compatible (Category 1)

Yes

Box
Box Capacity

28.42 cu ft

Box Capacity

0.8 m³

Box Design

High back box

Cutting Edge
Cutting Edge Reversible

Yes

Cutting Edge Quantity

Two

Cutting Edge Size

0.375 x 6 in.

Cutting Edge Size

0.95 x 15.24 cm

Scarifier Shank and Beam
Shank Type

Four position with holes

Point Type

Replaceable, heat treated

Point Quantity

Six

Scarifier Tube

5 x 5 x 0.25 in.

Scarifier Tube

12.7 x 12.7 x 0.64 cm

Tailgate
Tailgate Type

Fixed

Mast
Mast Type

Welded

Paint
Paint Color

John Deere Green

Shipping
Shipping Configuration

One per

Setup Time
Set-Up Time Labor Hours

0.5 hr

Warranty
Warranty Time Period

One year
