John Deere
BB5072
Compact Tractors Attachments

John Deere BB5072

Starting at

Replaceable and Adjustable Ripper Shanks

Replaceable heavy-duty ripper shanks have multiple adjustment holes for quick and easy changes to shank penetration level. The ripper shanks work great for the purposes of chipping or deep digging.

BB5072 Box Blade on back of tractor in grass
Quick-Hitch System Attaches Easily

iMatch™ quick-hitch compatibility provides quick, efficient hookup. The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.

BB5048 Box Blade on Utility tractor on gravel road
Replaceable and Reversible Blade for Longevity

Rear replaceable steel cutting edge ensures precise leveling and a fine finish. The rear blade is reversible for longer life.

BB5072 Box Blade on utility tractor on gravel
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
BB5072
Box Blade
Landpride
BB2596
ADD MODEL

Dimensions

Working Width72 in.243.8 cm
96 in.
Working Width182.9 cm243.8 cm
96 in.
Unit Height33.5 in.86.7 cm
34.125 in.
Unit Height85.1 cm86.7 cm
34.125 in.
Unit Depth31 in.79.1 cm
31.125 in.
Unit Depth78.7 cm79.1 cm
31.125 in.
Endplate Thickness0.375 in.
Endplate Thickness1 cm
Moldboard Thickness0.188 in.
Moldboard Thickness0.5 cm

Weight

Operating Weight474 lb.298.5 kg
658 lb
Operating Weight215 kg298.5 kg
658 lb
Shipping Weight509 lb.
Shipping Weight230.9 kg

Tractor Compatibility

PTO Power19-56 hp
PTO Power14.2-41.8 kW

Hitch

Hitch CompatibilityCategory 1Cat. 1
iMatch™ Compatible (Category 1)Yes

Box

Box Capacity15.97 cu ft0.55 m3
19.6 cu ft
Box Capacity0.45 m³0.55 m3
19.6 cu ft
Box DesignBox

Cutting Edge

Cutting Edge ReversibleYesYes
Cutting Edge Quantity2Two
Cutting Edge Size0.375x6 in.1.27x15.24 cm
0.5x6 in.
Cutting Edge Size0.95x15.24 cm1.27x15.24 cm
0.5x6 in.

Scarifier Shank and Beam

Shank TypeFour position with holes4 Position with holes
Point TypeHardened, crimped
Point Quantity6
Tubular Scarifier Beam Size4x4x0.25 in.10.16x10.16x0.79 cm
4x4x0.3125 in.
Tubular Scarifier Beam Size10.16x10.16x0.64 cm10.16x10.16x0.79 cm
4x4x0.3125 in.
Beam Reinforcement Bar Size0.5x0.5 in.
Beam Reinforcement Bar Size1.27x1.27 cm

Tailgate

Tailgate TypeFixedFixed

Mast

Mast TypeWeldedWelded

Paint

Paint ColorJD Green

Shipping

Shipping ConfigurationTwo per crate

Setup Time

Set-Up Time Labor Hours0.5 hr

Warranty

Warranty Time PeriodOne year
