John Deere
BB5048L
Compact Tractors Attachments

John Deere BB5048L

Starting at

Adjustable and Replaceable Ripper Shanks

Heavy-duty ripper shanks with multiple adjustment holes provide versatility for various ground conditions. They can be easily adjusted for different penetration levels, making them ideal for chipping or deep digging.

Studio view of BB5060L Box Blade
iMatch™ Quick-Hitch Compatible for Quick, Efficient Hookup

The iMatch™ Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.

iMatch™ Quick Hitch on rear of tractor with box blade attached
Cutting edge is strategically positioned for a fine finish

The BB50L Series Box Blade cutting edge ensures precise leveling and a fine finish. The reversible blade provides twice the wear life.

Close-up of agricultural implement showing adjustable mounting brackets with locking pins and clips beneath a black wear strip.
Question text goes here

Answer text goes here

Dimensions
Working Width

50 in.

Working Width

127 cm

Unit Height

33 in.

Unit Height

83.8 cm

Unit Depth

31 in.

Unit Depth

78.7 cm

Endplate Thickness

0.313 in.

Endplate Thickness

0.8 cm

Moldboard Thickness

0.188 in.

Moldboard Thickness

0.48 cm

Weight
Operating Weight

360 lb.

Operating Weight

163.3 kg

Shipping Weight

797 lb.

Shipping Weight

362 kg

Tractor Compatibility
PTO Power

26 hp

PTO Power

19 kW

Hitch
Hitch Compatibility

Category 1

iMatch™ Compatible (Category 1)

Yes

Box
Box Capacity

10.65 cu ft

Box Capacity

0.3 m³

Box Design

Box

Cutting Edge
Cutting Edge Reversible

Yes

Cutting Edge Quantity

2

Cutting Edge Size

0.375x6 in.

Cutting Edge Size

0.95x15.24 cm

Scarifier Shank and Beam
Shank Type

Four position with holes

Point Type

Hardened, crimped

Point Quantity

4

Tubular Scarifier Beam Size

4x4x0.25 in.

Tubular Scarifier Beam Size

10.16x10.16x0.64 cm

Tailgate
Tailgate Type

Fixed

Mast
Mast Type

Bolt on

Paint
Paint Color

John Deere green

Shipping
Shipping Configuration

Two per crate

Setup Time
Set-Up Time Labor Hours

0.25 hr

Warranty
Warranty Time Period

One year
