BB21 Series Box Blades Field Image
No items found.
new
John Deere
BB2184
Compact Tractors Attachments

John Deere BB2184

Starting at

Key Features

  • Cutting Edge is Strategically Positioned
  • Floating Tailgate Helps in Rough Conditions
  • iMatch™ Compatible for Quick, Efficient Hookup
  • Scarifier has Three Depth Adjustments
Request a Quote
Order Now
Apply for financing
Apply for financing
Print Page
Loan Calculator
Product Brochure
Features
Specifications
Strategically Positioned Cutting Edge

The BB Series Box Blade cutting edge ensures precise leveling and a fine finish. It is also reversible for twice the wear life.

Close-up of the lower edge of a box blade attachment, showing a black steel wear blade secured with bolts, resting on sandy ground
iMatch™ Quick Hitch Compatible for Efficient Hookup

The iMatch™ Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.

Green Frontier box blade attachment featuring multiple curved scarifier shanks, sitting behing a tractor hitch assembly ready to be hooked up
Floating tailgate helps in rough conditions

The tailgate floats, allowing material to flow through the blade during heavy grading conditions.

Rear view of Frontier BB1172 Box Blade attached to a tractor, showing the green frame, steel cutting edge, and floating tailgate resting on a dirt surface
Question text goes here

Answer text goes here

Specs & Compare
Select up to 4 models to compare specifications
John Deere
BB2184
Box Blade
Bush Hog
MBX84
Woods
BSM84
ADD MODEL

Dimensions

Working Width84 in.213.4 cm
84 in.		213.4 cm
84 in.
Working Width213.4 cm213.4 cm
84 in.		213.4 cm
84 in.
Unit Height33.5 in.86.4 cm
35 in.		86.4 cm
34 in.
Unit Height85.1 cm86.4 cm
35 in.		86.4 cm
34 in.
Unit Depth31 in.69.9 cm
27.5 in.		75.2 cm
29.6 in.
Unit Depth78.7 cm69.9 cm
27.5 in.		75.2 cm
29.6 in.
Endplate Thickness0.375 in.1 cm
0.375 in.		1.27 cm
0.5 in.
Endplate Thickness1 cm1 cm
0.375 in.		1.27 cm
0.5 in.
Moldboard Thickness0.1875 in.0.64 cm
0.25 in.
Moldboard Thickness0.5 cm0.64 cm
0.25 in.

Weight

Operating Weight667 lb.322.1 kg
710 lb		340.2 kg
750 lb
Operating Weight213.4 kg322.1 kg
710 lb		340.2 kg
750 lb
Shipping Weight575 lb.
Shipping Weight343.4 kg

Tractor Compatibility

PTO Power70 hp
PTO Power52.5 kW

Hitch

Hitch CompatibilityCategory 1Cat. 1

Box

Box Capacity22.3 cu ft0.43 m3
15.1 cu ft
Box Capacity0.63 m³0.43 m3
15.1 cu ft
Box DesignReinforced with formed edge end plates

Cutting Edge

Cutting Edge ReversibleYesYesYes
Cutting Edge Quantity2TwoTwo
Cutting Edge Size0.5x6 in.1.27x15.24 cm
0.5x6 in.		1.27x15.24 cm
0.5x6 in.
Cutting Edge Size1.27x15.24 cm1.27x15.24 cm
0.5x6 in.		1.27x15.24 cm
0.5x6 in.

Scarifier Shank and Beam

Shank TypeThree position with holes3 position with holes
Point TypeReplaceable
Point Quantity7
Tubular Scarifier Beam Size4x4x0.25 in.
Tubular Scarifier Beam Size10.16x10.16x0.64 cm
Beam Reinforcement Bar Size0.375x1 in.
Beam Reinforcement Bar Size0.95x2.54 cm

Tailgate

Tailgate TypeFloatingFloatingFixed

Mast

Mast TypeBolt onBolt on

Paint

Paint ColorJD Green

Shipping

Shipping ConfigurationOne unit

Setup Time

Set-Up Time Labor Hours0.5 hr

Warranty

Warranty Time Period1 year
