new
John Deere
AF12G-10
Compact Tractors Attachments

John Deere AF12G-10

Starting at

Heavy-Duty Frame for Long, Dependable Implement Life

The loader-mounted front blade is made of heavy-duty steel to resist bending and provide longer wear capability on the Frontier™ AF11 and AF12 Series Front Blades.

Green hydraulic-powered front blade with a curved blade, mounting brackets, and two hydraulic hoses extending from the frame
Twice the durability and work life with reversible cutting edges

The heat-treated steel cutting edge on the Frontier™ AF11 and AF12 Series Front Blades are reversible for twice the durability and work life.

Close-up of a green curved metal blade featuring a black reinforced cutting edge secured with bolts
Hydraulic angle adjustment for hard-to-reach places

The hydraulically controlled angle can be adjusted 30 degrees to each side to overcome the toughest spots. This feature saves time and creates professional-grade results. A loader third-function hydraulic line is required.

Rear right studio view of AF Series Front Blade highlighting the hydraulic connections
Question text goes here

Answer text goes here

Dimensions
Width

120 in.

Width

304.8 cm

Height

32 in.

Height

81.3 cm

Depth

56 in.

Depth

142.2 cm

Cutting Width

120 in.

Cutting Width

304.8 cm

Weight, Shipping

1360 lb.

Weight, Shipping

616.9 kg

Weight, Operating

1310 lb.

Weight, Operating

594.2 kg

Attachment Carrier
Current Series Style

Global

Weight
Operational Weight

1310 lb.

Operational Weight

594.2 kg

Shipping Weight

1360 lb.

Shipping Weight

616.9 kg

Moldboard
Moldboard Thickness

0.13 in.

Moldboard Thickness

3.4 mm

Moldboard Thickness

10 gauge

Moldboard Height

31.8 in.

Moldboard Height

808 mm

Angle/Pivot
Angle/Pivot Standard Adjustment

Hydraulic

Angle/Pivot Degrees (Each Side)

30

Hydraulic Cylinders
Hydraulic Cylinder Type

Two double-acting

Skid Shoes
Skid Shoes Standard

Yes

Setup Time
Setup Time Labor Hours

0.5 hr

Warranty
Warranty Time Period

One year
