John Deere
AF11E-84
Compact Tractors Attachments

John Deere AF11E-84

Starting at

Hydraulic angle adjustment for hard-to-reach places

The hydraulically controlled angle can be adjusted 30 degrees to each side to overcome the toughest spots. This feature saves time and creates professional-grade results. A loader third-function hydraulic line is required.

Rear right studio view of AF Series Front Blade highlighting the hydraulic connections
Heavy-Duty Frame for Long, Dependable Implement Life

The loader-mounted front blade is made of heavy-duty steel to resist bending and provide longer wear capability on the Frontier™ AF11 and AF12 Series Front Blades.

Green hydraulic-powered front blade with a curved blade, mounting brackets, and two hydraulic hoses extending from the frame
Twice the durability and work life with reversible cutting edges

The heat-treated steel cutting edge on the Frontier™ AF11 and AF12 Series Front Blades are reversible for twice the durability and work life.

Close-up of a green curved metal blade featuring a black reinforced cutting edge secured with bolts
Question text goes here

Answer text goes here

Dimensions
Width

84 in.

Width

213.4 cm

Height

23 in.

Height

58.4 cm

Depth

34 in.

Depth

86.4 cm

Cutting Width

84 in.

Cutting Width

213.4 cm

Weight, Shipping

480 lb.

Weight, Shipping

217.7 kg

Weight, Operating

450 lb.

Weight, Operating

204.1 kg

Attachment Carrier
Current Series Style

300, 400, 500

Weight
Operational Weight

450 lb.

Operational Weight

204.1 kg

Shipping Weight

480 lb.

Shipping Weight

217.7 kg

Moldboard
Moldboard Thickness

0.13 in.

Moldboard Thickness

3.4 mm

Moldboard Thickness

10 gauge

Moldboard Height

23.2 in.

Moldboard Height

589 mm

Angle/Pivot
Angle/Pivot Standard Adjustment

Manual

Angle/Pivot Degrees (Each Side)

30

Skid Shoes
Skid Shoes Standard

Yes

Setup Time
Setup Time Labor Hours

0.5 hr

Warranty
Warranty Time Period

One year
