3 Series Compact Tractors

John Deere 3033R

Starting at

Key Features

AutoConnect™ Deck Compatible for Deck Attach/Detach in Seconds
Advanced Visibility Design
eHydro™ Transmission With Twin Touch™ Pedals
Ergonomic Operator Station

Easy-to-Use eHydro™ Transmission

The eHydro™ transmission provides seamless, gradual speed shifts, requiring no clutching. Its Twin Touch™ foot controls allow for quick, precise direction and speed changes, ideal for loader or mower applications, enhancing overall productivity.

More Time Working, Less Time Switching Implements

John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.

John Deere compact tractor with front loader and rear rotary cutter mowing a grassy field, operator seated under ROPS, yellow wheels and green body visible, with a barn and open farmland in the background.

Comfortable, Easy Operation

Step in and get to work with a 3R Tractor designed to keep you comfortable and in control. A spacious, easy-to-navigate operator station gives you plenty of room, intuitive controls, and smooth entry and exit for long days on the job. For added comfort in any season, an optional ComfortGard™ cab surrounds you with a quiet, climate-controlled environment with excellent visibility.

Operator’s view of a John Deere lawn tractor showing yellow seat, steering wheel with instrument cluster, hydrostatic control lever, cup holder, and large rear tires on a clean studio background.

Specs & Compare

Select up to 4 models to compare specifications

John Deere

3033R

Compact Tractor

John Deere

3025D (Model year 2024)

John Deere

3025E (Model year 2024)

John Deere

3032E (Model year 2024)

John Deere

3035D (Model year 2024)

John Deere

3038E (Model year 2024)

John Deere

3039R (Model year 2024)

John Deere

3043D (Model Year 2024)

John Deere

3046R (Model year 2024)

Kubota®

L3560 DT, GST, HST, HSTC

New Holland

New Holland Boomer 37

ADD MODEL


Machine Configuration
Wheel or Track Configuration	Wheel
Drive Type	4WD	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear
Engine
Engine Model	3TNV88C-MJTV	3TNV88F-EPJPT	3TNV88F-EPJT2	3TNV88C-NJT2	3TNV88C-KJPT	3TNV86CT-NJT2	3TNV86CT-MJT	3TNV86CT-KJPT	3TNV86CHT-MJTV	D1803-CR-E4	N843T-F-27
Emissions Certifications	Final Tier 4
Displacement	100 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.57 L 3 / 95.7 cu in.	Three cylinders: 1.57 L 95.7 cu in.	3 / 1.57 L 3 / 95.8 cu in.	Three cylinders: 1.57 L 95.7 cu in.	3 / 1.826 L 3 / 111.4 cu in.	3 / 1.5 L 3 / 92 cu in.
Aspiration	Natural	Natural	Natural	Natural	Natural	Turbocharged	Turbocharged	Turbocharged	Turbocharged and intercooled	Natural	Turbocharged
Number of Cylinders	3	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three
Cylinder Liners	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block
Rated Engine Speed	2600 rpm	2400 rpm	2400 rpm	2500 rpm	2800 rpm	2500 rpm	2600 rpm	2800 rpm	2600 rpm	2700 rpm	2600 rpm
Rated Engine Power	32 hp (SAE J1995)	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm	SAE J1995 rated power: 25.5 kW 34.2 hp 34.7 PS at 2800 rpm	SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm	SAE J1995 rated power: 28.5 kW 38.2 hp 38.7 PS at 2600 rpm	SAE J1995 rated power: 31 kW 41.6 hp 42.2 PS at 2800 rpm	SAE J1995 rated power: 33.3 kW 44.7 hp 45.3 PS at 2600 rpm	27.6 kW 37 hp
Rated Engine Power	24 kW	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm	SAE J1995 rated power: 25.5 kW 34.2 hp 34.7 PS at 2800 rpm	SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm	SAE J1995 rated power: 28.5 kW 38.2 hp 38.7 PS at 2600 rpm	SAE J1995 rated power: 31 kW 41.6 hp 42.2 PS at 2800 rpm	SAE J1995 rated power: 33.3 kW 44.7 hp 45.3 PS at 2600 rpm	27.6 kW 37 hp
Rated Engine Power	32 PS	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm	SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm	SAE J1995 rated power: 25.5 kW 34.2 hp 34.7 PS at 2800 rpm	SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm	SAE J1995 rated power: 28.5 kW 38.2 hp 38.7 PS at 2600 rpm	SAE J1995 rated power: 31 kW 41.6 hp 42.2 PS at 2800 rpm	SAE J1995 rated power: 33.3 kW 44.7 hp 45.3 PS at 2600 rpm	27.6 kW 37 hp
Compression Ratio	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1
Lubrication	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized
Cooling System Type	Liquid
Fuel Type	Diesel
Air Cleaner Type	Dual element
Transmission
Clutch	eHydro™ transmission: Standard						PowrReverser transmission: Wet disk			Dry-type, single-stage
Cruise Control	eHydro™ transmission: Standard	No	Optional	Optional	No	Optional	PowrReverser transmission: Not applicable eHydro transmission: Standard	No	Standard	Standard on HST/HSTC 4WD only
Rear Power Take-Off (PTO)
PTO Category	Independent rear: 540 rpm
Optional PTO Category	eHydro™ transmission: Mid - 2100 rpm
PTO Clutch	Wet disk
Brake (For Mid and Rear PTO)	Wet disk	Wet disk	Wet disk	Wet disk	Wet disk	Wet disk	Wet disk	Wet disk	Wet disk	Multi-plate wet disc	Wet disc
Rear Hitch
Draft Control Sensing	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Optional
Hydraulics
Hydraulic System Type	Open center
Pump Rated Output	Steering: 23.5 L/min (6.2 gpm); Implement: 34.28 - 57.8 L/min (9.1 - 15.3 gpm)	Steering 14.4 L/min 3.8 gpm Implement 19.2 L/min 5.1 gpm 33.6 L/min 8.9 gpm	Steering 15 L/min 4 gpm Implement 20.2 L/min 5.3 gpm 35.2 L/min 9.3 gpm	Steering 15 L/min 4 gpm Implement 20.2 L/min 5.3 gpm 35.2 L/min 9.3 gpm	Steering 16.8 L/min 4.4 gpm Implement 22.4 L/min 5.9 gpm 39.2 L/min 10.3 gpm	Steering 15.0 L/min 4.0 gpm Implement 20.2 L/min 5.3 gpm 35.2 L/min 9.3 gpm	Steering 23.5 L/min 6.2 gpm Implement 34.3 L/min 9.1 gpm 57.8 L/min 15.3 gpm	Steering 16.8 L/min 4.4 gpm Implement 22.4 L/min 5.9 gpm 39.2 L/min 10.3 gpm	Steering 23.5 L/min 6.2 gpm Implement 34.3 L/min 9.1 gpm 57.8 L/min 15.3 gpm	Steering DT/GST - 18.6 L/min 4.9 L/min HST - 17.9 L/min 4.7 gpm Implement DT/GST - 31.5 L/min 8.3 gpm HST/HSTC - 30.4 L/min L/min 8.0 gpm DT/GST - 50.1 L/min 13.2 gpm HST/HSTC - 48.3 L/min 12.7 gpm	Steering GST - 15.9 L/min 4.2 gpm HST - 20.1 L/min 5.3 gpm Implement 31 L/min 8.2 gpm Glide shift transmission (GST) - 47.7 L/min 12.6 gpm HST - 51.1 L/min 13.5 gpm
Rear Axle
Final Drive	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear	Spur gear
Steering & Brakes
Steering Type	Hydrostatic power steering
Primary Brakes	Wet disk
Tires
Front Tires Size	R1 Bar: 7-14; R3 Turf: 27x8.50-15; R3 Turf Special: 25/10.5LLx15; R4 Industrial: 25x8.5-14 or 27x8.5-15
Rear Tires Size	R1 Bar: 11.2-24; R3 Turf: 41x14-20; R3 Turf Special: 41x18LLx-16.1; R4 Industrial: 15x19.5 or 43x16-20
Rear Tread Spacing	41 in.						1031 mm 40.6 in.		1031 mm 40.6 in.	112.0, 130.0, 138.5, or 148.0 cm 47.2, 51.2, 54.5, or 58.3 in.	128.3 cm 50.5 in.
Rear Tread Spacing	1031 mm						1031 mm 40.6 in.		1031 mm 40.6 in.	112.0, 130.0, 138.5, or 148.0 cm 47.2, 51.2, 54.5, or 58.3 in.	128.3 cm 50.5 in.
Electrical System
Alternator Capacity	75 amp
Operator Station
ROPS Type	Foldable
Gearshift Location	PowrReverser transmission: Right-hand side
