3 Series Compact Tractors

John Deere 3032E

Starting at

Key Features

4WD for Maximum Traction
Hydrostatic Transmission With TwinTouch™ Pedals
Versatile Category 1 3-Point Hitch
Independent Rear PTO Function

Easy-to-Use Hydrostatic Transmission

The 3E Tractors feature a hydrostatic transmission (HST) for superior performance. It provides infinite ground speeds that let operators easily match their speed to the task at hand. The Twin Touch™ foot pedals make forward and reverse motion effortless, enhancing operator comfort and control.

Studio close-up of a 3E tractor's Twin Touch foot controls

Comfortable Operator Station

Operators will appreciate the uncluttered design of the operator station, promoting comfort with color-coded controls and a contoured seat that adjusts for an optimal fit. The flat platform ensures easy entry and exit.

Top view of a 3E tractor's operator's station with optional selective control valve (SCV) levers

More Time Working, Less Time Switching Implements

John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.

John Deere compact tractor with front loader and rear rotary cutter mowing a grassy field, operator seated under ROPS, yellow wheels and green body visible, with a barn and open farmland in the background.

Specs & Compare

Select up to 4 models to compare specifications

John Deere

3032E

Compact Tractor

John Deere

2032R (Model year 2017)

John Deere

2038R (Model year 2017)

John Deere

3025D (Model year 2019)

John Deere

3025E (Model year 2017)

John Deere

3025E (Model year 2019)

John Deere

3033R (Model year 2017)

John Deere

3033R (Model year 2019)

John Deere

3035D (Model year 2019)

John Deere

3038E (Model year 2019)

John Deere

3039R (Model year 2019)

John Deere

3043D (Model Year 2019)

John Deere

3046R (Model year 2019)

Kubota

Kubota L3301 HST 4WD, L3301 GST 2WD & 4WD

Kubota

Kubota L3901 HST 4WD, L3301 GST 2WD & 4WD

New Holland

New Holland Workmaster 35

New Holland

New Holland Workmaster 40

ADD MODEL


Machine Configuration
Wheel or Track Configuration	Wheel
Drive Type	4WD	Spur Gear	Spur Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Bevel Gear	Bevel Gear
Engine
Engine Make	John Deere
Engine Model	3TNV88C-NJT2	3TNV88C-NJT	3TNV88C-NJT	3TNV88F-EPJPT	3TNV88F-EPJT1	3TNV88F-EPJT2	3TNV88C-MJT	3TNV88C-MJT	3TNV88C-KJPT	3TNV86CT-NJT	3TNV86CT-MJT	3TNV86CT-KJPT	3TNV86CHT-MJT	D1803-CR-E4	D1803-CR-E4
Engine Family	EYDXL1.64NDA, FYDXL1.64NDA, GYDXL1.64NDA	GYDXL1.64NDA	GYDXL1.57TDA		EYDXL1.64NDA FYDXL1.64NDA GYDXL1.64NDA	EYDXL1.64NDA FYDXL1.64NDA GYDXL1.64NDA	EYDXL1.64NDA FYDXL1.64NDA GYDXL1.64NDA	EYDXL1.64NDA FYDXL1.64NDA GYDXL1.64NDA		FYDXL1.57TDA EYDXL1.57TDA GYDXL1.57TDA	FYDXL1.57TDA EYDXL1.57TDA GYDXL1.57TDA		EYDXL1.57HDA FYDXL1.57HDA GYDXL1.57HDA
Emissions Certifications	Final Tier 4
Displacement	100 cu in.	3 / 1.642 L 3 / 100.2 cu in.	3 / 1.568 L 3 / 95.8 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.64 L 3 / 100 cu in.	3 / 1.64 L 3 / 100 cu in.	3 / 1.64 L 3 / 100.2 cu in.	3 / 1.57 L 3 / 95.7 cu in.	3 / 1.57 L 3 / 95.7 cu in.	3 / 1.57 L 3 / 95.8 cu in.	3 / 1.57 L 3 / 95.7 cu in.	3 / 1.826 L 3 / 111.4 cu in.	3 / 1.826 L 3 / 111.4 cu in.	3 / 1.9 L 3 / 116 cu in.	3 / 2.0 L 3 / 122 cu in.
Aspiration	Natural	Natural	Turbocharged	Natural	Natural	Natural	Natural	Natural	Natural	Turbocharged	Turbocharged	Turbocharged	Turbocharged and charge air cooled	Natural	Natural
Number of Cylinders	3	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three
Cylinder Liners	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block	Cast-in-block
Rated Engine Speed	2500 rpm	2500 rpm	2500 rpm	2400 rpm	2400 rpm	2400 rpm	2600 rpm	2600 rpm	2400 rpm	2500 rpm	2600 rpm	2400 rpm	2600 rpm	2700 rpm	2700 rpm	2600 rpm	2600 rpm
Rated Engine Power	31 hp (SAE J1995)	23.3 kW 31.2 hp SAE J1995 rated power	27.4 kW 37.3 hp SAE J1995 rated power	18.2 kW 24.7 hp	18.4 kW 24.7 hp	18.2 kW 24.7 hp	23.7 kW 32.2 hp	23.7 kW 32.2 hp PS at 2600 rpm SAE J1995 rated power	25.5 kW 34.7 hp	27.4 kW 37.2 hp	28.5 kW 38.7 hp PS at 2600 rpm SAE J1995 rated power	31 kW 42.2 hp	33.3 kW 45.3 hp PS at 2600 rpm SAE J1995 rated power	24.6 kW 33 hp		28.3 kW 38 hp
Rated Engine Power	23 kW	23.3 kW 31.2 hp SAE J1995 rated power	27.4 kW 37.3 hp SAE J1995 rated power	18.2 kW 24.7 hp	18.4 kW 24.7 hp	18.2 kW 24.7 hp	23.7 kW 32.2 hp	23.7 kW 32.2 hp PS at 2600 rpm SAE J1995 rated power	25.5 kW 34.7 hp	27.4 kW 37.2 hp	28.5 kW 38.7 hp PS at 2600 rpm SAE J1995 rated power	31 kW 42.2 hp	33.3 kW 45.3 hp PS at 2600 rpm SAE J1995 rated power	24.6 kW 33 hp		28.3 kW 38 hp
Rated Engine Power	31 PS	23.3 kW 31.2 hp SAE J1995 rated power	27.4 kW 37.3 hp SAE J1995 rated power	18.2 kW 24.7 hp	18.4 kW 24.7 hp	18.2 kW 24.7 hp	23.7 kW 32.2 hp	23.7 kW 32.2 hp PS at 2600 rpm SAE J1995 rated power	25.5 kW 34.7 hp	27.4 kW 37.2 hp	28.5 kW 38.7 hp PS at 2600 rpm SAE J1995 rated power	31 kW 42.2 hp	33.3 kW 45.3 hp PS at 2600 rpm SAE J1995 rated power	24.6 kW 33 hp		28.3 kW 38 hp
Compression Ratio	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1	19.1:1
Lubrication	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized	Pressurized
Cooling System Type	Water pump
Fuel Type	Diesel
Air Cleaner Type	Dual element
Transmission
Creeper	No	No	No	No	No	No	SpeedMatch optional	SpeedMatch optional	No		SpeedMatch optional	No	SpeedMatch standard	No	No
Cruise Control	Optional	Standard	Standard	No	Optional	Optional	Standard	Standard	No	Optional	Standard	No	Standard	Optional		Standard on HST only
Rear Power Take-Off (PTO)
PTO Category	540 rpm
Engine rpm at Rated PTO Speeds (540/1.000)	2500
Engagement Method	Independent
PTO Clutch	Wet disk
Brake (For Mid and Rear PTO)	Wet disk	Wet disc	Wet disc	Wet disc	Wet disc	Wet disc	Multi-plate wet disc	Multi-plate wet disc	Wet disc	Wet disc	Multi-plate wet disc	Wet disc	Multi-plate wet disc	Multiple wet disc	Multiple wet disc	Multiple wet disc	Multiple wet disc
Rear Hitch
Draft Control Sensing	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control	Position control
Hydraulics
Hydraulic System Type	Open center
Number of Rear Selective Control Valves (SCVs)	2
Rear Axle
Final Drive	Spur gear	Bull Gear	Bull Gear	Spur Gear	Bull Gear	Bull Gear	Bull Gear	Bull Gear	Spur Gear	Bull Gear	Bull Gear	Spur Gear	Bull Gear	Bevel Gear	Bevel Gear
Steering & Brakes
Primary Brakes	Wet disk
Tires
Front Tires Size	R1 Bar: 7-14; R3 Turf: 27x8.5-15; R4 Industrial: 25x8.5-14 / 27x8.5-15
Electrical System
Alternator Capacity	55 amp
Operator Station
Gearshift Location	Left-hand side
