Equipped with a standard HST transmission featuring Twin Touch™ foot pedals, this compact utility tractor offers increased performance and convenience. The hydrostatic drive allows for infinite ground speeds even at full throttle, providing smooth and precise operation, particularly useful for loader and mower applications.

The design of the operator's station focuses on comfort and visibility with a sloped hood, high-back seat, and easy step-through access. The controls are color-coded for ease of use, enhancing the overall operator experience and making control and visibility clear during operation.

John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.

Answer text goes here
Machine Configuration | ||||||
| Wheel or Track Configuration | Wheel | |||||
Engine | ||||||
| Engine Model | 3TNV80F-NCJT | 3TNV88C-NJT2 | 3TNV88C-NJT | 3A165LWM-U | D1105 | D1305-E4-D26-R |
| Emissions Certifications | Final Tier 4 | |||||
| Displacement | 77 cu in. | Three cylinders: 1.642 L 100.2 cu in. | Three cylinders: 1.568 L 95.8 cu in. | Three cylinders: 1.647 L 100.5 cu in. | Three cylinders: 1.123 L 68.5 cu in. | Three cylinders: 1.261 L 77.0 cu in. |
| Aspiration | Natural | Natural | Turbocharged | Natural | ||
| Number of Cylinders | 3 | Three | Three | Three | Three | Three |
| Cylinder Liners | Cast-in-block | Cast-in-block | Cast-in-block | |||
| Rated Engine Speed | 3200 rpm | 2500 rpm | 2500 rpm | 2600 rpm | 2800 rpm | 2500 rpm |
| Rated Engine Power | 24 hp (SAE J1995) | SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm | SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm | 18.2 kW 24.5 hp | Per SAE J1995: 18.1 kW 24.3 hp | Per SAE J1995: 18.5 kW 24.8 hp |
| Rated Engine Power | 18 kW | SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm | SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm | 18.2 kW 24.5 hp | Per SAE J1995: 18.1 kW 24.3 hp | Per SAE J1995: 18.5 kW 24.8 hp |
| Rated Engine Power | 24 PS | SAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm | SAE J1995 rated power: 27.4 kW 36.7 hp 37.2 PS at 2500 rpm | 18.2 kW 24.5 hp | Per SAE J1995: 18.1 kW 24.3 hp | Per SAE J1995: 18.5 kW 24.8 hp |
| Compression Ratio | 23.1:01 | 19.1:1 | 19.1:1 | |||
| Lubrication | Pressurized | Pressurized | Pressurized | Forced lubrication | Forced lubrication | |
| Cooling System Type | Water pump | |||||
| Fuel Type | Diesel | |||||
| Air Cleaner Type | Dual element | |||||
Transmission | ||||||
| Creeper | No | No | No | No | ||
| Cruise Control | Standard | Standard | Standard | |||
Rear Power Take-Off (PTO) | ||||||
| Economy PTO Speeds | Rear: 540 rpm; Mid: 2100 rpm | |||||
| Engagement Method | Independent | |||||
| PTO Clutch | Wet disk | |||||
| Brake (For Mid and Rear PTO) | Wet disk | Wet disc | Wet disc | Wet multi disc | Dry single plate | Multi-plate wet disc |
Rear Hitch | ||||||
| Draft Control Sensing | Position control | Position control | Position control | Position control | Position control | Position control |
Drawbar | ||||||
| Drawbar Category | Position control | |||||
Hydraulics | ||||||
| Hydraulic System Type | Open center | |||||
| Number of Rear Selective Control Valves (SCVs) | 2 | |||||
Rear Axle | ||||||
| Final Drive | Spur gear | Spur gear | Spur gear | Spur gear | ||
Steering & Brakes | ||||||
| Primary Brakes | Wet disc | |||||
Tires | ||||||
| Front Tires Size | R3 Turf: 23x8.50-12; R3 Radial: 220/55-R12; R4 Industrial: 23x8.50-12 | |||||
Electrical System | ||||||
| Alternator Capacity | 40 amp | |||||
Operator Station | ||||||
| Gearshift Location | Left-hand side | |||||
