The optional Mulch On Demand™ deck provides versatility with a lever-controlled switch between side-discharge and mulching modes. The design accommodates quick transitions, allowing operators to efficiently handle clippings, enhancing both productivity and landscape aesthetics.
This mower is equipped with a 7-Iron PRO side-discharge deck stamped from 7-gauge steel, offering superior durability and performance. The deck design provides a high-quality cut with excellent material processing and discharge capabilities.
Available as an option, Michelin® X® Tweel® Turf airless radial tires eliminate downtime due to flat tires and reduce operating costs. These tires enhance mowing performance by improving flotation and ground contact, ensuring consistent cut quality.
Answer text goes here
Engine | ||||||||||||
| Engine Manufacturer/Model | FX801V | |||||||||||
| Engine Power | Gross at 3,600 rpm: 25.5 hp (19 kW) | Gross at 3,600 rpm 23.5 hp 17.5 kW | Gross at 3,600 rpm 27 hp 20.1 kW | Gross at 3,600 rpm 27 hp 20.1 kW | Gross at 3,600 rpm 30.5 hp 22.7 kW | Gross at 3,600 rpm 30.5 hp 22.7 kW | Gross at 3,600 rpm 31 hp 23.1 kW | Gross at 3,600 rpm 33 hp 24.6 kW | Gross at 3,600 rpm 33 hp 24.6 kW | Gross at 3,600 rpm 35 hp 26.1 kW | Gross at 3,600 rpm 37 hp 27.6 kW | Gross at 3,600 rpm 40 hp 29.8 kW |
| Displacement | 52 cu in. | 44.3 cu in. 726 cc | 52 cu in. 852 cc | 52 cu in. 852 cc | 50.2 cu in. 822 cc | 50.2 cu in. 822 cc | 61 cu in. 999 cc | 60.6 cu in. 993 cc | 60.6 cu in. 993 cc | 61 cu in. 999 cc | 60.6 cu in. 993 cc | 60.6 cu in. 993 cc |
| Displacement | 852 cc | 44.3 cu in. 726 cc | 52 cu in. 852 cc | 52 cu in. 852 cc | 50.2 cu in. 822 cc | 50.2 cu in. 822 cc | 61 cu in. 999 cc | 60.6 cu in. 993 cc | 60.6 cu in. 993 cc | 61 cu in. 999 cc | 60.6 cu in. 993 cc | 60.6 cu in. 993 cc |
| Cylinders | 2 | Two | Two | Two | Two | Two | Two | Two | Two | Two | Two | Two |
| Crankcase Capacity | 2.4 U.S. qt | With filter, 2.1 U.S. qt 2 L | With filter, 2.4 U.S. qt 2.3 L | With filter, 2.4 U.S. qt 2.3 L | With filter, 2.2 U.S. qt 2.1 L | With filter, 2.2 U.S. qt 2.1 L | With filter, 2 U.S. qt 1.9 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L | With filter, 2 U.S. qt 1.9 L | With filter, 2.5 U.S. qt 2.4 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L |
| Crankcase Capacity | 2.3 L | With filter, 2.1 U.S. qt 2 L | With filter, 2.4 U.S. qt 2.3 L | With filter, 2.4 U.S. qt 2.3 L | With filter, 2.2 U.S. qt 2.1 L | With filter, 2.2 U.S. qt 2.1 L | With filter, 2 U.S. qt 1.9 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L | With filter, 2 U.S. qt 1.9 L | With filter, 2.5 U.S. qt 2.4 L | With filter and Oil Guard System, 5 U.S. qt 14.7 L |
| Oil Filter | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable |
| Lubrication | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure | Full pressure |
| Cooling | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports | Forced air, with integrated clean out ports | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports and oil cooler | Forced air, with integrated clean out ports |
| Air Cleaner | Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element | Pre-cleaner Yes Heavy-duty canister type with safety element |
| Pre-Cleaner | Yes | |||||||||||
Fuel System | ||||||||||||
| Fuel Type | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline |
| Fuel Consumption | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr (4.2-7.2 L/hr) | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr 4.2-7.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr 4.2-7.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr 4.2-7.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.3 U.S. gal./hr 4.9 L/hr FastBack PRO rear-discharge: 1.1 U.S. gal./hr 4.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.3 U.S. gal./hr 4.9 L/hr FastBack PRO rear-discharge: 1.1 U.S. gal./hr 4.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr 4.2-7.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.4 U.S. gal./hr 5.3 L/hr FastBack PRO rear-discharge: 1.3 U.S. gal./hr 4.9 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.4 U.S. gal./hr 5.3 L/hr FastBack PRO rear-discharge: 1.3 U.S. gal./hr 4.9 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr 4.2-7.2 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.4 U.S. gal./hr 5.3 L/hr FastBack PRO rear-discharge: 1.3 U.S. gal./hr 4.9 L/hr | Under normal conditions, load, operation, and dependent on loads and operating conditions 7Iron PRO side-discharge: 1.4 U.S. gal./hr 5.3 L/hr FastBack PRO rear-discharge: 1.3 U.S. gal./hr 4.9 L/hr |
| Fuel Tank Capacity | 11.5 U.S. gal. | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L/hr | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L |
| Fuel Tank Capacity | 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L/hr | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L | 11.5 U.S. gal. 43.5 L |
| Fuel Tank Switch/Shut-Off Valve | No | |||||||||||
Electrical System | ||||||||||||
| Charge System | 30 amp | 30 amp | 30 amp | 30 amp | 30 amp | 30 amp | 30 amp | 20 amp | 20 amp | 30 amp | 20 amp | 20 amp |
| Battery Voltage | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V | 12 V |
| Cold Cranking Amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp | 300 amp |
| Hour Meter | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Standard, digital | Standard, digital | Standard, digital | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Standard, digital | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Standard, digital | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics | Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics |
| Operator Presence Starting System | Brake-N-Go (hand) | Brake-N-Go (hand) | Brake-N-Go (hand) | Brake-N-Go (foot) | Brake-N-Go (hand) | Brake-N-Go (foot) | Brake-N-Go (hand) | Brake-N-Go (hand) | Brake-N-Go (foot) | Brake-N-Go (foot) | Brake-N-Go (hand) | Brake-N-Go (foot) |
Drivetrain | ||||||||||||
| Transmission | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic |
| Wheel Motors | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting | Tuff Torq heavy-duty integrated piston wheel motor with cross porting |
| Travel Speed | 10 mph | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h |
| Travel Speed | 16.1 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h | Speed range 0-12 mph 0-19.3 km/h Forward 0-12 mph 0-19.3 km/h Reverse 0-4.5 mph 0-7.2 km/h |
| Speed Range | 0-12 mph mph | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h |
| Speed Range | 0-19.3 km/h km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h | 0-12 mph 0-19.3 km/h |
| Forward Speed | 0-12 mph mph | |||||||||||
| Forward Speed | 0-19.3 km/h km/h | |||||||||||
| Reverse Speed | 0-4.5 mph mph | |||||||||||
| Reverse Speed | 0-7.2 km/h km/h | |||||||||||
| Speed Direction And Control | Twin levers | |||||||||||
| Hydraulic Capacity | 5.9 U.S. qt | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L |
| Hydraulic Capacity | 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L | 5.9 U.S. qt 5.6 L |
| Filter | Internal, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable | Full flow, replaceable |
Buyer's note | ||||||||||||
| Warranty | 36 months or 1200 hours, whichever comes first; First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1500 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1500 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1500 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1500 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1200 hours, whichever comes first First 24 months, no hour limitation | 36 months or 1500 hours, whichever comes first First 24 months, no hour limitation |
Tires | ||||||||||||
| Drive Wheels | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 |
| Load Rating | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR | 4 PR |
Brakes | ||||||||||||
| Dynamic Braking | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers | Twin levers |
| Park Brake | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission | Internal wet disk integrated in the transmission |
| Park Brake Actuation | Hand brake | Hand brake | Hand brake | Foot brake | Hand brake | Foot brake | Hand brake | Hand brake | Foot brake | Foot brake | Hand brake | Foot brake |
PTO | ||||||||||||
| Type | Electro-magnetic, 225 lb-ft (305 Nm) | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline |
| Drive | V-belt | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 | 24x12-12 |
Mower Decks | ||||||||||||
| Mower Deck Size | 54-in. (137-cm) 7Iron™ PRO side-discharge; 60-in. (152-cm) 7Iron™ PRO side-discharge; 60-in. (152-cm) FastBack™ PRO rear-discharge | 48-in. (122-cm) 7Iron™ PRO side-discharge 54-in. (137-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO side-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 54-in. (137-cm) 7Iron™ PRO Mulch On Demand™ 72-in. (183-cm) FastBack™ PRO rear-discharge | 54-in. (137-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) FastBack™ PRO rear-discharge | 54-in. (137-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO side-discharge 54-in. (137-cm) 7Iron™ PRO Mulch On Demand™ 60-in. (152-cm) 7Iron™ PRO Mulch On Demand™ 60-in. (152-cm) FastBack™ PRO rear-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO Mulch On Demand™ 72-in. (183-cm) FastBack™ PRO rear-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO Mulch On Demand™ 60-in. (152-cm) FastBack™ PRO rear-discharge 72-in. (183-cm) FastBack™ PRO rear-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) FastBack™ PRO rear-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) FastBack™ PRO rear-discharge | 60-in. (152-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) 7Iron™ PRO side-discharge 60-in. (152-cm) 7Iron™ PRO Mulch On Demand™ 60-in. (152-cm) FastBack™ PRO rear-discharge 72-in. (183-cm) FastBack™ PRO rear-discharge | 72-in. (183-cm) 7Iron™ PRO side-discharge 72-in. (183-cm) FastBack™ PRO rear-discharge |
| Deck Construction | 7Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel; FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel | 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel |
| Discharge | Side-discharge, Mulch On Demand™, Rear-discharge | |||||||||||
| Height-Of-Cut Range | 1-5.5 in. | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm |
| Height-Of-Cut Range | 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm | Increments 0.25 in. 0.64 cm 1-5.5 in. 2.54-14 cm |
| Height-Of-Cut Increments | 0.25 in. | |||||||||||
| Height-Of-Cut Increments | 0.64 cm | |||||||||||
| Cutting Width | 54/60 in. | 48, 54, 60 in. 122, 137, 152 cm | 54, 60, 72 in. 137, 152, 183 cm | 60, 72 in. 152, 183 cm | 54, 60 in. 137, 152 cm | 60,72 in. 152, 183 cm | 60, 72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 60, 72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 72 in. 183 cm |
| Cutting Width | 137/152 cm | 48, 54, 60 in. 122, 137, 152 cm | 54, 60, 72 in. 137, 152, 183 cm | 60, 72 in. 152, 183 cm | 54, 60 in. 137, 152 cm | 60,72 in. 152, 183 cm | 60, 72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 60, 72 in. 152, 183 cm | 60,72 in. 152, 183 cm | 72 in. 183 cm |
Blades | ||||||||||||
| Length | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size |
| Thickness | 7Iron™ PRO: 0.25 in. (6.4 mm); FastBack™ PRO: 0.31 in. (8 mm) | |||||||||||
| Blade Tip Speed | 7Iron™ PRO: Approximately 18,500 fpm; 60-in. (152-cm) FastBack™: Approximately 16,500 fpm | 7Iron PRO: Approximately 18,500 fpm | 7Iron PRO: Approximately 18,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm 60-in. (152-cm) FastBack: Approximately 16,500 fpm | 7Iron PRO: Approximately 18,500 fpm 60-in. (152-cm) FastBack: Approximately 16,500 fpm | 7Iron PRO: Approximately 18,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm 60-in. (152-cm) FastBack: Approximately 16,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm | 7Iron PRO: Approximately 18,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm 60-in. (152-cm) FastBack: Approximately 16,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm | 7Iron PRO: Approximately 18,500 fpm 72-in. (183-cm) FastBack: Approximately 18,000 fpm |
| Number | 3 | Three | Three | Three | Three | Three | Three | Three | Three | Three | Three | Three |
Wheels | ||||||||||||
| Caster Wheel Type | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free | Flat free |
| Caster Wheels | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 | 13x6.5-6 |
| Front Anti-Scalp Rollers | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right | Left, center, right |
| Rear Anti-Scalp Rollers | 7Iron™ PRO: Left, center, right; FastBack™ PRO: Left, right | 7Iron PRO: Left, center, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right | 7Iron PRO: Left, center, right FastBack PRO: Left, right |
Dimensions | ||||||||||||
| Length | 84 in. (213 cm) | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size | Varies by deck size |
| Width - With Chute Down | 68, 74 in. | |||||||||||
| Width - With Chute Down | 173, 188 cm | |||||||||||
| Width - Rear Discharge | 63.5 in. | |||||||||||
| Width - Rear Discharge | 161.3 cm | |||||||||||
| Height - With ROPS Up | 73 in. | |||||||||||
| Height - With ROPS Up | 185 cm | |||||||||||
| Height - With ROPS Down | 47 in. | |||||||||||
| Height - With ROPS Down | 119 cm | |||||||||||
| Weight | 1299 - 1369 lb. | 1,228 to 1,313 lb 557 to 596 kg | 1,296 to 1,412 lb 588 to 640 kg | 1,315 to 1,423 lb 596 to 645 kg | 1383 to 1454 lb 627 to 660 kg | 1437 to 1529 lb 652 to 694 kg | 1,304 to 1,412 lb 591 to 640 kg | 1415 to 1485 lb 642 to 674 kg | 1452 to 1534 lb 659 to 696 kg | 1,326 to 1,445 lb 601 to 655 kg | 1426 to 1523 lb 647 to 691 kg | 1530 to 1556 lb 694 to 706 kg |
| Weight | 589 - 621 kg | 1,228 to 1,313 lb 557 to 596 kg | 1,296 to 1,412 lb 588 to 640 kg | 1,315 to 1,423 lb 596 to 645 kg | 1383 to 1454 lb 627 to 660 kg | 1437 to 1529 lb 652 to 694 kg | 1,304 to 1,412 lb 591 to 640 kg | 1415 to 1485 lb 642 to 674 kg | 1452 to 1534 lb 659 to 696 kg | 1,326 to 1,445 lb 601 to 655 kg | 1426 to 1523 lb 647 to 691 kg | 1530 to 1556 lb 694 to 706 kg |
Operation | ||||||||||||
| Rollover Protective Structure (ROPS) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Slope Operating Limit | 20 degree (angle) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) | 20 degrees (10 degrees with material collection system installed) |
| Slope Operating Limit - With Material Collection System | 10 degree (angle) | |||||||||||
Additional Information | ||||||||||||
| Date Collected | 2026-08-03T00:00:00 | 1-Aug-24 | 1-Aug-24 | 1-Aug-24 | 01-Oct-2024 | 01-Oct-2024 | 1-Aug-24 | 01-Oct-2024 | 01-Oct-2024 | 1-Aug-24 | 01-Oct-2024 | 01-Oct-2024 |
