The 30 P‑Tier is designed to work efficiently in confined areas while still delivering the digging force and performance crews need for everyday tasks. Its compact footprint and zero‑tail‑swing configuration help reduce the risk of contact with surrounding structures, making it well suited for urban jobsites, residential work, and utilities where space is limited.

Smooth, predictable hydraulic response and intuitive pilot controls help operators work precisely and confidently throughout the day. The 30 P‑Tier’s well‑balanced machine layout supports easy trenching, grading, and material placement, while a comfortable operator station helps reduce fatigue during long workdays.

Factory‑installed auxiliary hydraulics enable the 30 P‑Tier to run a wide range of attachments, expanding the machine’s versatility without adding extra equipment to the jobsite. Durable components, simplified service access, and proven Deere reliability help maximize uptime and keep operating costs in check over the life of the machine.

Answer text goes here
Engine | |||||||||
| Manufacturer | Yanmar | Yanmar | Kubota | Yanmar | Caterpillar | Kubota | Yanmar | Yanmar | |
| Displacement | 100.2 cu in. | 1.64 (100.2) | 1.6 (100) | 1.3 (77) | 1.65 (101) | 1.12 (68.1) | |||
| Displacement | 1.64 L | 1.64 (100.2) | 1.6 (100) | 1.3 (77) | 1.65 (101) | 1.12 (68.1) | |||
| Net power | 2400 rpm | ||||||||
| Net power at net power rpm (ISO 9249) | 23 hp | ||||||||
| Net power at net power rpm (ISO 9249) | 17.4 kW | ||||||||
Powertrain | |||||||||
| Maximum travel speed high/fast | 2.7 mph | ||||||||
| Maximum travel speed high/fast | 4.3 km/h | ||||||||
| Swing speed | 9.1 rpm | 9.1 | 8.4 | 9 | 11 | 10.2 | 9.4 | ||
Hydraulics | |||||||||
| Main pump maximum rated flow | 20.2 gpm | 76.8 (20.2) | 76.8 (20.2) | 88 (23.1) | 105 (28) | 74.8 (19.8) | |||
| Main pump maximum rated flow | 76.8 L/min | 76.8 (20.2) | 76.8 (20.2) | 88 (23.1) | 105 (28) | 74.8 (19.8) | |||
Undercarriage | |||||||||
| Standard track width | 12 in. | ||||||||
| Standard track width | 300 mm | ||||||||
Refill Capacities | |||||||||
| Fuel tank | 11.1 gal. | 42 (11.1) | 53.1 (14) | 52 (14) | 42 (11) | 45 (11.8) | 170 (45) | 36 (9.5) | 44 (11.6) |
| Fuel tank | 42 L | 42 (11.1) | 53.1 (14) | 52 (14) | 42 (11) | 45 (11.8) | 170 (45) | 36 (9.5) | 44 (11.6) |
| Hydraulic tank | 11.4 gal. | 43 (11.4) | 20.4 (5.4) | 47 (12.4) | 114 (30) | 26.5 (7) | 32 (8.5) | ||
| Hydraulic tank | 43 L | 43 (11.4) | 20.4 (5.4) | 47 (12.4) | 114 (30) | 26.5 (7) | 32 (8.5) | ||
Operating weight with standard arm | |||||||||
| Operating weight | 7220 lb. | 3275 (7220) | 3258 (7183) | 3329 (7340) | 3320 (7320) | 3267 (7204) | 3270 (7209) | 3262 (7191) | 3270 (7209) |
| Operating weight | 3275 kg | 3275 (7220) | 3258 (7183) | 3329 (7340) | 3320 (7320) | 3267 (7204) | 3270 (7209) | 3262 (7191) | 3270 (7209) |
Operating dimensions with standard arm | |||||||||
| Maximum digging reach | 16, 1 ft, in. | 4890 (16 ft 1 in) | 5200 (17 ft 1 in) | 4950 (16 ft 3 in) | 4614 (15 ft 2 in) | 4880 (16 ft 0 in) | |||
| Maximum digging reach | 4.89 m | 4890 (16 ft 1 in) | 5200 (17 ft 1 in) | 4950 (16 ft 3 in) | 4614 (15 ft 2 in) | 4880 (16 ft 0 in) | |||
| Maximum digging depth | 9, 2 ft, in. | ||||||||
| Maximum digging depth | 2.79 m | ||||||||
| Maximum dumping height | 9, 11 ft, in. | ||||||||
| Maximum dumping height | 3.03 m | ||||||||
| Transport height | 8, 2 ft, in. | 2480 (8 ft 2 in) | 2429 (7 ft 12 in) | 2443 (8 ft 0 in) | 2510 (8 ft 3 in) | 2500 (8 ft 2 in) | 2524 (8 ft 3 in) | 2460 (8 ft 1 in) | |
| Transport height | 2.48 m | 2480 (8 ft 2 in) | 2429 (7 ft 12 in) | 2443 (8 ft 0 in) | 2510 (8 ft 3 in) | 2500 (8 ft 2 in) | 2524 (8 ft 3 in) | 2460 (8 ft 1 in) | |
| Transport length | 14, 7 ft, in. | 4450 (14 ft 7 in) | 4662 (15 ft 4 in) | 4661 (15 ft 4 in) | 4730 (15 ft 6 in) | 4470 (14 ft 8 in) | 4199 (13 ft 9 in) | 4410 (14 ft 6 in) | |
| Transport length | 4.45 m | 4450 (14 ft 7 in) | 4662 (15 ft 4 in) | 4661 (15 ft 4 in) | 4730 (15 ft 6 in) | 4470 (14 ft 8 in) | 4199 (13 ft 9 in) | 4410 (14 ft 6 in) | |
