The parking mounting system is designed for easy removal and mounting to and from the tractor without tools. To park the loader, simply install parking stands, remove pivot pins from the mast, disconnect the hydraulic hoses, and back out the tractor.

Grease fittings accessible from the loader’s side make maintenance easier.

The quick-change attachment carrier allows for fast, easy removal and mounting of attachments without tools.

Answer text goes here
Tractor | |||
| Model | 1023E/1026R Tractor | BX2660 | BX25 |
| Front Tire | 18x8.5-10 4PR R4 | 18X8.50-10 Turf | |
| Rear Tire | 26x12.00-12 4PR R4 | 26X12.00-12 Turf | |
| Wheelbase | 1450 mm | 2425 mm 95.5 in. | |
| Wheelbase | 57 in. | 2425 mm 95.5 in. | |
| Pump Capacity | 13.2 L/min | 3.7 gpm | |
| Pump Capacity | 3.5 gpm | 3.7 gpm | |
| Rated Pressure | 137 bar | 1778 psi | |
| Rated Pressure | 1987 psi | 1778 psi | |
Loader | |||
| Base Weight | 220.5 kg | ||
| Base Weight | 486 lb. | ||
| Bucket Used | Pin on Materials, 1250 mm 49 in. | 1219.2 mm 48 in. | 1219 mm 48 in. |
| Bucket Weight | 53 kg | ||
| Bucket Weight | 117 lb. | ||
| Lift Capacity At Full Height - Measured At Pivot (U) | 375 kg | ||
| Lift Capacity At Full Height - Measured At Pivot (U) | 825 lb. | ||
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 259 kg | ||
| Lift Capacity at Full Height - Measured at 500 mm Ahead of Pivot | 570 lb. | ||
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 429 kg | ||
| Lift Capacity At 59 in. (1500 mm) - Measured At Pivot | 944 lb. | ||
| Lift Capacity at 59 in (1500 mm) - Measured at 500 mm Ahead of Pivot | 309 kg | ||
| Lift Capacity at 59 in. (1500 mm) - Measured at 500 mm Ahead of Pivot | 608 lb. | ||
| Boom Breakout Force - Measured At Pivot (Y) | 806 kg | ||
| Boom Breakout Force - Measured At Pivot (Y) | 1808 lb. | ||
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 552 kg | ||
| Boom Breakout Force - Measured at 500 mm Ahead of Pivot | 1238 lb. | ||
| At Maximum Height (VV) | 593 kg | ||
| At Maximum Height (VV) | 1330 lb. | ||
| At 59-in. (1500 mm) Lift Height (XX) | 711 kg | ||
| At 59-in. (1500 mm) Lift Height (XX) | 1568 lb. | ||
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 707 kg | ||
| Bucket Rollback Force Capacity At Ground-Level Line (ZZ) | 1559 lb. | ||
| Maximum Lift Height (A) | 1809 mm | 1810 mm 71.3 in. | 1810 mm 71.3 in. |
| Maximum Lift Height (A) | 71.2 in. | 1810 mm 71.3 in. | 1810 mm 71.3 in. |
| At Full Height - Bucket Level (B) | 1653 mm | ||
| At Full Height - Bucket Level (B) | 65.1 in. | ||
| Clearance At Full Height - Bucket Dumped | 1371 mm | ||
| Clearance At Full Height - Bucket Dumped | 54 in. | ||
| Overall Length (I+F) | 2600 mm | ||
| Overall Length (I+F) | 102.4 in. | ||
| Digging Depth (H) | -101 mm | 120 mm 4.7 in. | 120 mm 4.7 in. |
| Digging Depth (H) | -4 in. | 120 mm 4.7 in. | 120 mm 4.7 in. |
| Reach - At Maximum Height (D) | 571 mm | ||
| Reach - At Maximum Height (D) | 22.5 in. | ||
| Reach - At Ground Level - Bucket Level | 1176 mm | ||
| Reach - At Ground Level - Bucket Level | 46.3 in. | ||
| Dump Angle (E) | -40.1 degree (angle) | 29 degree (angle) | 45 degree (angle) |
| Rollback Angle (G) | 31.2 degree (angle) | 29 degree (angle) | |
| Dump Angle, Ground | -114 degree (angle) | ||
| Loader Raise | 4 seconds | ||
| Loader Lower | 2.5 seconds | ||
| Bucket Dump | 5.7 seconds | 45 degree (angle) | 1330 mm 52.4 in. |
| Bucket Rollback | 3.5 seconds | ||
