With up to 100 hp and strong digging capability, the 310 P‑Tier delivers the power and durability needed for demanding excavation, loading, and utility work across a wide range of jobsites.
A durable, open‑center hydraulic system provides smooth control, excellent multifunctioning, and reliable performance—helping operators dig, load, and place material efficiently with a confident “feel.”
Multiple transmission options—including manual and Powershift™—allow customers to tailor the machine to their work style, while intuitive controls support easy direction changes and efficient operation throughout the day.
Answer text goes here
Manufacturer | John Deere |
Model | PowerTech™ EWL 4.5L turbocharged |
Non-Road Emission Standards | EPA Final Tier 4/EU Stage IV |
Cylinders | 4 |
Valves Per Cylinder | 2 |
Displacement | 276 cu in. |
Displacement | 4.52 L |
Bore and Stroke | 4.19 x 5.00 in. |
Bore and Stroke | 106.43 x 127.00 mm |
Rated Speed | 2200 rpm |
Gross Power At Rated Speed | 96 hp |
Gross Power At Rated Speed | 71.58 kW |
Peak Power Speed | 1600 rpm |
Gross Peak Power At Peak Power Speed | 102 hp |
Gross Peak Power At Peak Power Speed | 76.08 kW |
Peak Torque Speed | 1500 rpm |
Gross Peak Torque At Peak Torque Speed | 344 lb-ft |
Gross Peak Torque At Peak Torque Speed | 466.55 Nm |
Net Power At Rated Speed (ISO9249) | 94 hp |
Net Power At Rated Speed (ISO9249) | 70.08 kW |
Net Peak Power At Peak Power Speed (ISO9249) | 74.57 kW |
Net Peak Torque At Peak Torque Speed (ISO9249) | 338 lb-ft |
Net Peak Torque At Peak Torque Speed (ISO9249) | 458.47 Nm |
Net Torque Rise | 51 % |
Oil Specification | JD Torq-Gard or equivalent |
Lubrication | Pressure system with spin-on filter and cooler |
Fuel System | Level 34 electronic fuel system with Denso high pressure common rail |
Air Cleaner | Dual stage dry type with safety element and evacuator valve |
Fan Type | Electronically controlled, variable rate, suction type cooling fan, Standard |
Engine Coolant Rating | -40 °F |
Engine Coolant Rating | -40 ℃ |
Engine Radiator (Fins Per In.) | 10 |
Engine Oil Cooler Type | Oil-to-water |
Hydraulic Cooler Type | Oil-to-air |
Transmission Cooler Type | oil-to-water |
Transmission Type | 4 speed, helical cut gears, full power-shifted transmission with hydraulic reverser standard; Electric clutch cutoff on loader lever |
Number Of Gears Forward | 4 |
Number Of Gears Reverse | 2 |
Shift Control Type | Electric forward-neutral-reverse control lever with neutral start interlock |
Torque Converter Type | Single stage, dual phase with 2.63:1 stall ratio |
Torque Converter | 11 in. |
Torque Converter | 279.4 mm |
Conditions For Measuring Travel Speeds | Power-Shift, Standard Transmission with Tire Size 19.5L-24 Rear Tires |
Gear 1, Forward Maximum Speed | 3.4 mph |
Gear 1, Forward Maximum Speed | 5.47 km/h |
Gear 1, Reverse Maximum Speed | 4.2 mph |
Gear 1, Reverse Maximum Speed | 6.76 km/h |
Gear 2, Forward Maximum Speed | 6.2 mph |
Gear 2, Forward Maximum Speed | 9.98 km/h |
Gear 2, Reverse Maximum Speed | 7.8 mph |
Gear 2, Reverse Maximum Speed | 12.55 km/h |
Gear 3, Forward Maximum Speed | 12.6 mph |
Gear 3, Forward Maximum Speed | 20.29 km/h |
Gear 4, Forward Maximum Speed | 22.7 mph |
Gear 4, Forward Maximum Speed | 36.53 km/h |
Axle Oscillation Stop To Stop, Front Axle | 22 degree (angle) |
Front Axle, Sae J43 Rating | 11000 lb. |
Front Axle, Sae J43 Rating | 4989.52 kg |
Front Axle, Dynamic Rating | 19800 lb. |
Front Axle, Dynamic Rating | 8981.45 kg |
Front Axle, Static Rating | 54000 lb. |
Front Axle, Static Rating | 24493.52 kg |
Front Axle, Ultimate Rating | 91500 lb. |
Front Axle, Ultimate Rating | 41518.58 kg |
Rear Axle, SAE J43 Rating | 13200 lb. |
Rear Axle, SAE J43 Rating | 5987.39 kg |
Rear Axle, Dynamic Rating | 22000 lb. |
Rear Axle, Dynamic Rating | 9979.03 kg |
Rear Axle, Static Rating | 58400 lb. |
Rear Axle, Static Rating | 26496.91 kg |
Rear Axle, Ultimate Rating | 91500 lb. |
Rear Axle, Ultimate Rating | 41518.58 kg |
Maximum Axle Torque | 46100 lb. |
Maximum Axle Torque | 20913.91 kg |
Mechanical Front Wheel Drive Axle Differential Type | Open - standard; automatic, limited-slip traction control – custom or optional |
Rear Axle Differential Type | Foot actuated, hydraulically engaged 100% mechanical lock |
Rear Differential Lock Pressure | 305 psi |
Rear Differential Lock Pressure | 2102.72 kPa |
Steering Type | Hydrostatic Power Steering and Emergency Steering (ISO 5010) |
Steering Pressure | 3625 psi |
Steering Pressure | 24987.5 kPa |
Maximum Steer Angle, Mechanical Front-Wheel Drive (MFWD) Axle | 52 degree (angle) |
Maximum Steer Angle, Non-Powered Front Axle | 55 degree (angle) |
Curb-Turning Radius, With Brakes, With MFWD Axle | 11, 4 ft, in. |
Curb-Turning Radius, With Brakes, With MFWD Axle | 3.45 m |
Curb-Turning Radius, With Brakes, With Non-Powered Front Axle | 11, 3 ft, in. |
Curb-Turning Radius, With Brakes, With Non-Powered Front Axle | 3.43 m |
Curb-Turning Radius, Without Brakes, With MFWD Axle | 13, 0 ft, in. |
Curb-Turning Radius, Without Brakes, With MFWD Axle | 3.96 m |
Curb-Turning Radius, Without Brakes, With Non-Powered Front Axle | 12, 10 ft, in. |
Curb-Turning Radius, Without Brakes, With Non-Powered Front Axle | 3.91 m |
Bucket Clearance Circle, With Brakes, With MFWD Axle | 32, 4 ft, in. |
Bucket Clearance Circle, With Brakes, With MFWD Axle | 9.86 m |
Bucket Clearance Circle, With Brakes, With Non-Powered Front Axle | 32, 2 ft, in. |
Bucket Clearance Circle, With Brakes, With Non-Powered Front Axle | 9.8 m |
Bucket Clearance Circle, Without Brakes, With MFWD Axle | 34, 10 ft, in. |
Bucket Clearance Circle, Without Brakes, With MFWD Axle | 10.62 m |
Bucket Clearance Circle, Without Brakes, With Non-Powered Front Axle | 34, 5 ft, in. |
Bucket Clearance Circle, Without Brakes, With Non-Powered Front Axle | 10.49 m |
Number Of Steering Wheel Turns (Lock To Lock) With MFWD Axle | 2.7 |
Number Of Steering Wheel Turns (Lock To Lock) With Non-Powered Front Axle | 3.2 |
MFWD Axle Final Drives And Gears | Heavy duty, outboard planetary final drives distribute shock loads over 3 gears |
MFWD Axle Total Ratio | 12.574:1 (14.759:1 optional with 12.5/80-18 front tires) |
Rear Axle Final Drives And Gears | Heavy duty, outboard planetary final drives distribute shock loads over 3 gears |
Rear Axle Total Ratio | 19.911:1 |
Brakes | Conform to ISO 3450 |
Service Brakes | Power assisted, hydraulic wet disc, mounted inboard, self adjusting and self equalizing |
Service Brakes Friction Disc Area Per Side | 141900 mmByMm |
Hydraulics System Type | Open center system, single gear pump |
Rated Rpm | 2200 rpm |
Backhoe Pump Flow | 28 gpm |
Backhoe Pump Flow | 105.99 L/min |
Loader Pump Flow | 28 gpm |
Loader Pump Flow | 105.99 L/min |
Backhoe System Relief Pressure | 3625 psi |
Backhoe System Relief Pressure | 24987.5 kPa |
Loader System Relief Pressure | 3200 psi |
Loader System Relief Pressure | 22063 kPa |
Backhoe Controls | 2-lever mechanical standard, pilot control with pattern select and manual and/or electric auxiliary functions optional |
Loader Controls | Single-lever control with electric clutch cutoff switch standard; single-lever control with electric clutch cutoff switch, electrohydraulic (EH) proportional auxiliary roller, MFWD (momentary), and transmission quick-shift optional |
Voltage | 12 V |
Number Of Batteries | 1 |
Battery Capacity (1 Battery) | 950 CCA |
Reserve Capacity (1 Battery) | 175 min. |
Alternator Rating | 145 amp |
Lighting Options | 10 halogen: 4 front, 4 rear, and 2 side docking (32,500 candlepower each); turn signals and flashers: 2 front and 2 rear; stop and taillights; and 2 rear reflectors; factory installed option for 2 LED spot lights and 8 LED flood lights in lieu of the standard halogen light package |
Operator Station Type | Canopy, isolation mounted, ROPS/FOPS, left/right access, with molded roof; optional quarter cab (front glass only) and fully enclosed cab |
Alternator, Low Voltage | Indicator light, Audible |
Service Code Indicator | Indicator light |
Engine Air Filter Restriction | Indicator light, Audible, Digital |
Engine Coolant Temperature | Indicator light, Audible, Gauge |
Engine Oil Pressure | Indicator light, Audible |
Fuel Level | Audible, Gauge, Digital |
Hydraulic Oil Filter Restriction | Audible warning, Digital |
Park Brake On/Off | Indicator light |
Seat Belt Reminder | Indicator light |
Stop Indicator | Indicator light, Audible |
MFWD Active | Indicator light |
Hydraulics Enabled | Indicator light |
Engine Preheat | Indicator light, Digital |
Aftertreatment Temperature High | Indicator light |
Torque Converter Oil Temp | Indicator light, Audible, Gauge, Digital |
Job Timer | Digital |
Hourmeter | Digital |
Engine Rpm | Digital |
System Voltage | Digital |
Machine Information And Configuration | Digital |
Diesel-Exhaust Fluid (DEF) Level | Indicator light, Audible, Digital |
Sight Gauges | Hydraulic Reservoir |
Diagnostics | In-Cab Monitor Information |
Refill Capacity Cooling System (Cab) | 29.1 qt |
Refill Capacity Cooling System (Cab) | 27.54 L |
Refill Capacity Cooling System (Canopy) | 27.2 qt |
Refill Capacity Cooling System (Canopy) | 25.74 L |
Refill Capacity Rear Axle Differential Housing | 19 qt |
Refill Capacity Rear Axle Differential Housing | 17.98 L |
Refill Capacity Engine Oil | 13.7 qt |
Refill Capacity Engine Oil | 12.97 L |
Refill Capacity Torque Converter And Transmission | 16 qt |
Refill Capacity Torque Converter And Transmission | 15.14 L |
Refill Capacity Fuel Tank | 34 gal. |
Refill Capacity Fuel Tank | 128.7 L |
Refill Capacity Diesel-Exhaust Fluid (DEF) Tank | 3.6 gal. |
Refill Capacity Diesel-Exhaust Fluid (DEF) Tank | 13.63 L |
Refill Capacity Hydraulic System | 33.5 gal. |
Refill Capacity Hydraulic System | 126.87 L |
Refill Capacity Hydraulic Reservoir | 11.9 gal. |
Refill Capacity Hydraulic Reservoir | 45.06 L |
Refill Capacity Mechanical Front-Wheel Drive Housing Axle | 6.9 qt |
Refill Capacity Mechanical Front-Wheel Drive Housing Axle | 6.53 L |
Refill Capacity Mechanical Front-Wheel Drive Housing Planetary Each | 1 qt |
Refill Capacity Mechanical Front-Wheel Drive Housing Planetary Each | 0.95 L |
Operator And Standard Equipment With Full Fuel Tank | 16217 lb. |
Standard With Bumper | 14669 lb. |
Standard With Bumper | 6654 kg |
Typical With Cab, Extendible Dipperstick, And 405-Lb Counterweight | 15119 lb. |
Typical With Cab, Extendible Dipperstick, And 204-Kg Counterweight | 6856 kg |
Cab | 580 lb. |
Cab | 263.1 kg |
Mechanical Front-Wheel Drive With Tires | 370 lb. |
Mechanical Front-Wheel Drive With Tires | 167.8 kg |
Extendable Dipperstick | 420 lb. |
Extendable Dipperstick | 190.5 kg |
Front Loader Coupler | 566 lb. |
Front Loader Coupler | 256.7 kg |
Backhoe Bucket Coupler | 130 lb. |
Backhoe Bucket Coupler | 59 kg |
Hydraulic Capacity Minimum Tines | 48 in. |
Hydraulic Capacity Minimum Tines | 1219.2 mm |
At Maximum Height With Minimum Tines | 3772 lb. |
At Maximum Height With Minimum Tines | 1711.4 kg |
At Maximum Reach With Minimum Tines | 5931 lb. |
At Maximum Reach With Minimum Tines | 2690.5 kg |
At Ground Line With Minimum Tines | 7480 lb. |
At Ground Line With Minimum Tines | 3392.3 kg |
Below Ground Line With Minimum Tines | 7.3 in. |
Below Ground Line With Minimum Tines | 185.4 mm |
Rated Capacity Of Minimum Tines | 8598 lb. |
Rated Capacity Of Minimum Tines | 3900 kg |
Hydraulic Capacity Maximum Tines | 60 in. |
Hydraulic Capacity Maximum Tines | 1524 mm |
At Maximum Height With Maximum Tines | 3510 lb. |
At Maximum Height With Maximum Tines | 1592.6 kg |
At Maximum Reach With Maximum Tines | 5578 lb. |
At Maximum Reach With Maximum Tines | 2529.3 kg |
At Ground Line With Maximum Tines | 7061 lb. |
At Ground Line With Maximum Tines | 3203 kg |
Below Ground Line With Maximum Tines | 7.3 in. |
Below Ground Line With Maximum Tines | 185.4 mm |
Rated Capacity Of Maximum Tines | 8598 lb. |
Rated Capacity Of Maximum Tines | 3900 kg |
