When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.
Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.
Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.
Answer text goes here
Machine Configuration | |||||||||||||||||
| Wheel or Track Configuration | Wheel | ||||||||||||||||
| Drive Type | 4WD | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary | Planetary/inboard | Planetary/inboard | Inboard planetary | Inboard planetary | Inboard planetary | |||
Engine | |||||||||||||||||
| Engine Make | John Deere | ||||||||||||||||
| Engine Family | MJDXL09.0319 | MJDXL09.0319 | MJDXL09.0319 | MJDXL09.0333 | MJDXL09.0333 | MJDXL09.0333 | MJDXL09.0333 | MJDXL09.0333 | MJDXL09.0333 | ||||||||
| Emissions Certifications | Final Tier 4 | ||||||||||||||||
| Displacement | 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 6.7 L 411 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. |
| Displacement | 9 L | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 6.7 L 411 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. |
| Aspiration | Single turbocharger, variable geometry turbo | Single turbocharger, variable geometry turbo | Single turbocharger, variable geometry turbo | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Electronical variable geometry turbocharger (VGT), aftercooled | Electronical variable geometry turbocharger (VGT), aftercooled | Variable geometry turbo | Variable geometry turbo | Variable geometry turbo | VGT turbocharged, air-to-air aftercooled | Turbocharged, wastegate turbo | Turbocharged, eVGT |
| Number of Cylinders | 6 | ||||||||||||||||
| Cylinder Liners | Wet-sleeve cylinder liners | ||||||||||||||||
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) | ||||||||||||||||
| Intelligent Power Management (IPM) | Power boost: 29.6 hp / 22.1 kW / 30 PS (hp ISO) | ||||||||||||||||
| Rated Engine Speed | 2100 rpm | ||||||||||||||||
| Rated Engine Power | 325 hp (hp SAE) | ECE-R120: 228 kW 310 hp | ECE-R120: 257 kW 350 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 231 kW 310 hp | ECE-R120: 254 kW 340 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 221 kW 300 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp |
| Rated Engine Power | 243 kW | ECE-R120: 228 kW 310 hp | ECE-R120: 257 kW 350 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 231 kW 310 hp | ECE-R120: 254 kW 340 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 221 kW 300 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp |
| Rated Engine Power | 330 PS (hp ISO) | ECE-R120: 228 kW 310 hp | ECE-R120: 257 kW 350 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 228 kW 310 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 250 kW 340 hp | ECE-R120: 231 kW 310 hp | ECE-R120: 254 kW 340 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 221 kW 300 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp |
| Engine Torque at Rated Speed | 1139 lb-ft | ||||||||||||||||
| Engine Torque at Rated Speed | 1545 Nm | ||||||||||||||||
| Maximum Engine Power | 358 hp (hp SAE) | ECE-R120: 251 kW 341 hp | ECE-R120: 283 kW 385 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 283 kW 380 hp | ECE-R120: 306 kW 410 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 230 kW 313 hp | ECE-R120: 235 kW 320 hp | ECE-R120: 258 kW 351 hp |
| Maximum Engine Power | 267 kW | ECE-R120: 251 kW 341 hp | ECE-R120: 283 kW 385 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 283 kW 380 hp | ECE-R120: 306 kW 410 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 230 kW 313 hp | ECE-R120: 235 kW 320 hp | ECE-R120: 258 kW 351 hp |
| Maximum Engine Power | 363 PS (hp ISO) | ECE-R120: 251 kW 341 hp | ECE-R120: 283 kW 385 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 251 kW 341 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 275 kW 374 hp | ECE-R120: 283 kW 380 hp | ECE-R120: 306 kW 410 hp | ECE R120: 239 kW 326 hp | ECE R120: 261 kW 355 hp | ECE R120: 283 kW 385 hp | ECE-R120: 230 kW 313 hp | ECE-R120: 235 kW 320 hp | ECE-R120: 258 kW 351 hp |
| Maximum Engine Torque | At 1600 rpm: 1545 Nm (1139 lb-ft) | ||||||||||||||||
| Fuel Type | Diesel | ||||||||||||||||
| Torque Rise | 40 % | 40 percent | 40 percent | 40 percent | 40 percent | 40 percent | 40 percent | 40 percent | 40 percent | ||||||||
Transmission | |||||||||||||||||
| Transmission Type | John Deere e23™ 42 km/h (26 mph); Optional: John Deere e23™ Transmission 50 km/h (31 mph), John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph), John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) | Standard: John Deere e23™ 42 km/h 26 mph Optional: John Deere e23 transmission 50 km/h 31 mph John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph) John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) | Standard: John Deer Infinitely Variable transmission (IVT™): 0.05-42 km/h 0.03-26 mph Optional: John Deere IVT: 0.05-50 km/h 0.03- 31 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: 16-speed PowerShift 40 km/h e23 PowerShift with Efficiency Manager 50K, 50 km/h 31 mph John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph John Deere AutoPowr IVT 50K, 0.05-50 km/h 0.03-31 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km 24.9 mph Optional: e23 PowerShift with Efficiency Manager 50K, 50 km/h 31 mph John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph John Deere AutoPowr IVT 50K, 0.05-50 km/h 0.03-31 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph | Standard: 19-speed Powershift: 40 K Optional: 23-speed Powershift: 40 K 19-speed Powershift 50 K CVT: 40 or 50 K | Standard: 19-speed Powershift: 40 K Optional: 18-speed Powershift: 40 K 19-speed Powershift 50 K CVT: 40 or 50 K | Stepless VarioDrive transmission: TA 300 Vario CVT 50 km/h 31 mph | Stepless VarioDrive transmission: TA 300 Vario CVT 50 km/h 31 mph | Stepless VarioDrive transmission: TA 300 Vario CVT 50 km/h 31 mph | Standard: Auto Command™ CVT (40K) Optional: Auto Command™ CVT (50K) | Standard: Ultra Command™ full-powershift (40K) Optional: Ultra Command™ full-powershift (50K) Auto Command™ CVT (40K) Auto Command™ CVT (50K) | Standard: Ultra Command™ full-powershift (40K) Optional: Ultra Command™ full-powershift (50K) Auto Command™ CVT (40K) Auto Command™ CVT (50K) |
| Maximum Speed Forward | 31 mph (50 km/h) | ||||||||||||||||
| Minimum Speed Forward | 0.03 mph (0.050 km/h) | ||||||||||||||||
Rear Power Take-Off (PTO) | |||||||||||||||||
| PTO Category | Independent; Standard: 44.45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 44.45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540E/1000/1000E rpm gearcase; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540/540E/1000 rpm gearcase | ||||||||||||||||
| Rated PTO Power | 260 hp | 193.9 kW 260 hp | 193 kW 260 hp | 191 kW 257 hp | 191 kW 257 hp | 191 kW 257 hp | 211 kW 284 hp | 211 kW 284 hp | 211 kW 284 hp | 198 kW 265 hp | 216 kW 290 hp | 197 kW 264 hp | 216 kW 290 hp | 236 kW 317 hp | 199 kW 270 hp | 153 kW 205 hp | 175 kW 235 hp |
| Rated PTO Power | 193 kW | 193.9 kW 260 hp | 193 kW 260 hp | 191 kW 257 hp | 191 kW 257 hp | 191 kW 257 hp | 211 kW 284 hp | 211 kW 284 hp | 211 kW 284 hp | 198 kW 265 hp | 216 kW 290 hp | 197 kW 264 hp | 216 kW 290 hp | 236 kW 317 hp | 199 kW 270 hp | 153 kW 205 hp | 175 kW 235 hp |
| Rated PTO Power | 264 PS | 193.9 kW 260 hp | 193 kW 260 hp | 191 kW 257 hp | 191 kW 257 hp | 191 kW 257 hp | 211 kW 284 hp | 211 kW 284 hp | 211 kW 284 hp | 198 kW 265 hp | 216 kW 290 hp | 197 kW 264 hp | 216 kW 290 hp | 236 kW 317 hp | 199 kW 270 hp | 153 kW 205 hp | 175 kW 235 hp |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1950 | ||||||||||||||||
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | 1750 | ||||||||||||||||
| Engagement Method | Electric switch with adjustable modulation | ||||||||||||||||
| Number of Splines | 20 | ||||||||||||||||
Front PTO | |||||||||||||||||
| PTO Speed | 1000 | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | |||||||
| Front PTO Rotation | Counter-clockwise | ||||||||||||||||
| Engine rpm (at Rated PTO Speeds) | 1940 rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | |||||||
| Front Number of Splines | 21 | ||||||||||||||||
Front Hitch | |||||||||||||||||
| Front Hitch Category | Category 3N, ground engaging | Category 3N, ground engaging | Category 3N, ground engaging | Category 3N | Category 3N | Optional: 4275 kg 9426 lb | Optional: 4275 kg 9426 lb | Optional | |||||||||
| Lift Capacity Through Full Lift Range at Coupling Points | 6740 lb. | ||||||||||||||||
| Lift Capacity Through Full Lift Range at Coupling Points | 3060 kg | ||||||||||||||||
| Number of Front Selective Control Valves (SCVs) | One with front hitch | One with front hitch | One with front hitch | ISO couplers: two | ISO couplers: two | ISO couplers: two | |||||||||||
| Electric Power | Seven-pin connector | ||||||||||||||||
Rear Hitch | |||||||||||||||||
| Rear Hitch Category (SAE Designation) | Standard: Category 3N/3 with Quik-Coupler; Optional: Category 3/3N with hook ends; Category 4N/3 with Quik-Coupler; Category 4N/3 with hook ends | Standard: Category 3N/3 with Quik-Coupler Optional: Category 3/3N with hook ends Category 4N/3 with Quik-Coupler Category 4N/3 with hook ends | Standard: Category 3N/3 with Quik-Coupler Optional: Category 3/3N with hook ends Category 4N/3 with Quik-Coupler Category 4N/3 with hook ends | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg 15,000 lb | Standard: Category 3/3N Optional: Category 4N/3 | Standard: Category 3/4N | Standard: Category 3/4N: 9750 kg 21,500 lb | Standard: Category 3/4N: 9750 kg 21,500 lb | Standard: Category 3/4N: 9750 kg 21,500 lb | Standard: Category 3/3N: with 109.2 cm (43 in.) links with 10.2 cm (4 in.) axle: 5851 kg 12,900 lb Optional: Category 3/3N with 96.5 cm (38 in.) links, with 10.2 cm (4 in.) axle: 6758 kg 14,900 lb Category 3/3N: with 109.2 cm (43 in.) links, with 11.4 cm (4.5 in.) axle: 7212 kg 15,900 lb Optional: Category 3/3N with 96.5 cm (38 in.) links, with 11.4 cm (4.5 in.) axle: 8119 kg 17,900 lb | Standard: Category 3/3N: with 109.2 cm (43 in.) links with 10.2 cm (4 in.) axle: 5851 kg 12,900 lb Optional: Category 3/3N with 96.5 cm (38 in.) links, with 10.2 cm (4 in.) axle: 6758 kg 14,900 lb Category 3/3N: with 109.2 cm (43 in.) links, with 11.4 cm (4.5 in.) axle: 7212 kg 15,900 lb Optional: Category 3/3N with 96.5 cm (38 in.) links, with 11.4 cm (4.5 in.) axle: 8119 kg 17,900 lb Category 4N/3: with 109.2 cm (43 in.) links, with 11.4 cm (4.5 in.) axle: 7,938 kg (17,500 lb) Category 4N/3: with 96.5 cm (38 in.) links, with 11.4 cm (4.5 in.) axle: 8,845 kg (19,500 lb) | |
| Maximum Lift Capacity Directly at Coupling Points | 22258 | ||||||||||||||||
| Lift Capacity Through Full Lift Range at Coupling Points | 6740 | ||||||||||||||||
| Sensing Type | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | ||||||||
Drawbar | |||||||||||||||||
| Drawbar Category | Category 4 | Standard: Category 4 | Standard: Category 4 | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 4 Optional: Category 4 with heavy-duty support | Standard: Category 3 Optional: Category 4 | Standard: Category 4 Optional: Category 3 | Category 3 | Standard: Category 3 Optional: Category 4 | Standard: Category 3 Optional: Category 4 | |||
| Maximum Vertical Load | Standard: Category 3: 1,837 kg (4,050 lb); Optional: Category 3 with heavy-duty support: 4,536 kg (10,000 lb) | Standard: Category 3: 1,837 kg 4,050 lb Optional: Category 3 with heavy-duty support: 4,536 kg 10,000 lb | Standard: Category 4: 4,990 kg 11,000 lb | Dependent on drawbar position: 1837 to 2700 kg 4050 to 6000 lb Optional: 2,245 kg 4,950 lb 4,990 kg 11,000 lb | Standard: 2245 kg 4950 lb Optional (dependent on drawbar position): 4990 kg 11,000 lb | Standard: 2245 kg 4950 lb Optional (dependent on drawbar position): 4990 kg 11,000 lb | Dependent on drawbar position: 1837 to 2700 kg 4050 to 6000 lb Optional: 2,245 kg 4,950 lb 4,990 kg 11,000 lb | Standard: 2245 kg 4950 lb Optional (dependent on drawbar position): 4990 kg 11,000 lb | Standard: 2245 kg 4950 lb Optional (dependent on drawbar position): 4990 kg 11,000 lb | ||||||||
Hydraulics | |||||||||||||||||
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure-and-flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated | Closed-center, pressure/flow compensated | Closed-center pressure and flow compensated (PFC) | Closed-center pressure and flow compensated (PFC) | Closed-center pressure and flow compensated (PFC) | Closed-center, load sensing | Pressure-flow compensating | Pressure-flow compensating |
| Pump Rated Output | Standard: 63 cc: 162 L/min (43 gpm); Optional: 85 cc: 222.3 L/min (59 gpm) | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Powershift: 166 L/min 44 gpm CVT: 225 L/min 59 gpm Optional: 282 L/min 75 gpm | Powershift: 166 L/min 44 gpm CVT: 225 L/min 59 gpm Optional: 282 L/min 75 gpm | Standard: 165 L 43.6 gpm Optional: 220 L 58 gpm 430 L 113.5 gpm | Standard: 165 L 43.6 gpm Optional: 220 L 58 gpm 430 L 113.5 | Standard: 165 L 43.6 gpm Optional: 220 L 58 gpm 430 L 113.5 gpm | Standard: 165 L/min 43.5 gpm Optional: 220 L/min 58 gpm | Standard: 166 L/min 44 gpm Optional: 282 L/min 75 gpm | Standard: 166 L/min 44 gpm Optional: 282 L/min 75 gpm |
| Number of Rear Selective Control Valves (SCVs) | Standard: Four SCVs; Optional: Three to five ISO couplers: 12.7 mm (1/2 in.); Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 0.5 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: four ISO couplers Optional: ISO couplers 5 and 6 | Standard: four ISO couplers Optional: ISO couplers 5 and 6 | ISO couplers: up to six | ISO couplers: up to six | ISO couplers: up to six | Standard: Four Optional: Up to five electrohydraulic | Standard: Four Optional: Five to six | Standard: Four Optional: Five to six |
| Available Flow at a Single Rear SCV | 35 gpm (132 L/min) | 132 L/min 35 gpm | 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | ||||||||
| Number of Mid Selective Control Valves (SCVs) | 3 | Up to three | |||||||||||||||
| Available Flow at Front SCVs | 33 gpm | 126 L/min 33 gpm | 126 L/min 33 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | ||||||||||
| Available Flow at Front SCVs | 126 L/min | 126 L/min 33 gpm | 126 L/min 33 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | ||||||||||
| SCV Control | Electronic | Standard | Standard | Standard | Optional | ||||||||||||
Front Axle | |||||||||||||||||
| Front Axle Type | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm (60 to 88 in.); Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h (24.9 mph); TLS with front brakes standard with 50 km/h (31 mph) | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm 60 to 88 in. Optional: TLS: Tread range 1524 to 2235 mm TLS with front brakes available with 40 km/h 24.9 mph TLS with front brakes standard with 50 km/h 31 mph | Standard: TLS with front brakes | Standard: ILS Optional: 1500 Series MFWD | 1700 Series MFWD | Standard: ILS Optional: 1500 Series MFWD | 1700 Series MFWD | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended | Independent suspension | Independent suspension | Independent suspension | Standard: Suspended | Optional: Terraglide™ front axle suspension | Optional: Terraglide™ front axle suspension | ||
| Front Axle Differential Lock | 1300 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) | 1300 Series MFWD: Limited slip TLS: Limited slip TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) | Full-locking electrohydraulic (actuated at same time as rear diff lock) | 1500 Series MFWD: Full-locking electrohydraulic ILS: Full-locking electrohydraulic | Full-locking electrohydraulic (actuated at same time as rear diff-lock) | 1500 Series MFWD: Full-locking electrohydraulic ILS: Full-locking electrohydraulic | Full-locking electrohydraulic (actuated at same time as rear diff-lock) | ||||||||||
Rear Axle | |||||||||||||||||
| Rear Axle Type | Standard: Rack-and-pinion or flange axles; Optional: Diameter: 110 x 2550 mm (4.33 x 100.4 in.); Diameter: 110 x 3010 mm (4.33 x 118.5 in.); Diameter: 120 x 2550 mm (4.72 x 100.4 in.); Diameter: 120 x 3010 mm (4.72 x 118.5 in.); Flanged Axle: 335 mm (13.2 in.) | Standard: Rack-and-pinion or flange axles Optional: Diameter: 110 x 2550 mm 4.33 x 100.4 in. Diameter: 110 x 3010 mm 4.33 x 118.5 in. Diameter: 120 x 2550 mm 4.72 x 100.4 in. Diameter: 120 x 3010 mm 4.72 x 118.5 in. Flanged axle: 335 mm (13.2 in.) | Standard: Rack-and-pinion or flange axles Optional: Diameter: 120 x 2550 mm 4.72 x 100.4 in. Diameter: 120 x 3010 mm 4.72 x 118.5 in. Flanged axle: 335 mm mm 13.2 in. | Standard: Rack-and-pinion, double flat, or flange axles Optional: Long, dual taper hub: Diameter: 110 x 3010 mm 4.33 x 118.5 in. Short, double flat axle with single taper hub: Diameter: 120 x 2550 mm 4.72 x 100.4 in. | Flange | Standard: Rack-and-pinion, double flat, or flange axles Optional: Long, dual taper hub: Diameter: 110 x 3010 mm 4.33 x 118.5 in. Short, double flat axle with single taper hub: Diameter: 120 x 2550 mm 4.72 x 100.4 in. | Flange | Standard: Bar axle, diameter: 115 x 3050 mm 4.5 x 120 in. | Standard: Bar axle, diameter: 115 x 3050 mm 4.5 x 120 in. | Standard: Flange | Standard: Flange | Standard: Flange | Standard: Flange Optional: Bar axle | Standard: 102x3,050 mm 4x120 in. Optional: 114x3,050 mm 4.5x120 in. | Standard: 102x3,050 mm 4x120 in. Optional: 114x3,050 mm 4.5x120 in. | ||
| Rear Differential Lock | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | |||||
| Final Drive | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary | Planetary/inboard | Planetary/inboard | Inboard planetary | Inboard planetary | Inboard planetary | |||
Steering & Brakes | |||||||||||||||||
| Steering Type | Hydraulic power-steering with electric pump back-up; Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS™ 2) with electronic backup pump | Standard: Hydraulic power-steering with electric pump backup | Standard: Hydraulic power-steering with electric pump backup | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS™ 2) with electronic backup pump | Standard: Hydraulic power-steering with electric pump backup | Standard: Hydraulic power-steering with electric pump backup | ||||||||
Tires | |||||||||||||||||
| Rear Tires Size | RCI Group 48/49 | ||||||||||||||||
Electrical System | |||||||||||||||||
| Battery Voltage | 12 V | ||||||||||||||||
| Battery Cold Cranking Amps | 1900 CCA | ||||||||||||||||
| Battery Capacity | 2 x 950 CCA | ||||||||||||||||
| Alternator Capacity | Standard: 210 amp, Optional: 250 amp | ||||||||||||||||
| Working Lights | Standard: 18 halogen; Available: 18 light-emitting diode (LED) and two halogen or 22 LED and two halogen | Standard: 18 halogen Available: 18 LED or 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | ||||||||
| Driving Lights | Standard: 65-W halogen; Available: LED | ||||||||||||||||
Operator Station | |||||||||||||||||
| Seat Suspension | Air seat (Standard), ActiveSeat™ II (Optional) | ||||||||||||||||
| Degree of Seat Swivel, Left Hand | 8 degree (angle) | ||||||||||||||||
| Degree of Seat Swivel, Right Hand | 40 degree (angle) | ||||||||||||||||
| Cab Suspension | Adjustable cab suspension (Optional) | Optional: Adjustable cab suspension | Optional: Adjustable cab suspension | Optional: Adjustable cab suspension | Standard: four-post cab suspension | Standard: four-post cab suspension | Optional: Adjustable cab suspension | Standard: four-post cab suspension | Standard: four-post cab suspension | Standard | Standard | Three-point pneumatic | Three-point pneumatic | Three-point pneumatic | Classic: Comfort Ride™ optional SideWinder™ II: Comfort Ride™ optional | Optional: Comfort Ride™ | Optional: Comfort Ride™ |
| Instructional Seat | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | |||||
| Primary Display | G5 - 12.8 in. (32.5 cm) | ||||||||||||||||
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | ||||||||
| Inner Cab Volume | 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | ||||
| Inner Cab Volume | 3.24 m³ | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | ||||
| Cab Glass Area | 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | ||||
| Cab Glass Area | 6.56 m² | 6.56 m2 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | ||||
Technology Integration | |||||||||||||||||
| Guidance | Integrated AutoTrac™ | Integrated AutoTrac™ | Integrated AutoTrac™ | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | AFS AccuGuide™ Ready | AFS AccuGuide™ Ready | VarioGuide | VarioGuide | VarioGuide | Intellisteer™ guidance | Intellisteer™ guidance | Intellisteer™ guidance |
| Connectivity | JDLink™ | ||||||||||||||||
| Remote Diagnostics | ServiceADVISOR™ Remote: available with JDLink hardware and activations; Remote Display Access: available with JDLink hardware and activations | ServiceADVISOR™ Remote: available with JDLink hardware and activations Remote Display Access: available with JDLink hardware and activations | ServiceADVISOR™ remote: available with JDLink hardware and activations Remote Display Access: available with JDLink hardware and activations | JDLink hardware standard | JDLink hardware standard | JDLink hardware standard | JDLink hardware standard | JDLink hardware standard | JDLink hardware standard | ||||||||
Capacities | |||||||||||||||||
| Fuel Tank Capacity | 122 (e23™), 135 (IVT™) gal. | ||||||||||||||||
| Fuel Tank Capacity | 463 (e23™), 513 (IVT™) L | ||||||||||||||||
| Diesel Exhaust Fluid (DEF) Tank Capacity | 6.9 gal. | 26.2 L 6.9 U.S. gal. | 26.2 L 6.9 U.S. gal. | 37.2 L 9.8 U.S. gal. | 31.3 L 8.3 U.S. gal. | 37.2 L 9.8 U.S. gal. | 37.2 L 9.8 U.S. gal. | 31.3 L 8.3 U.S. gal. | 37.2 L 9.8 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. | 70 L 18.5 U.S. gal. | 70 L 18.5 U.S. gal. | 70 L 18.5 U.S. gal. | 96 L 25 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 26.2 L | 26.2 L 6.9 U.S. gal. | 26.2 L 6.9 U.S. gal. | 37.2 L 9.8 U.S. gal. | 31.3 L 8.3 U.S. gal. | 37.2 L 9.8 U.S. gal. | 37.2 L 9.8 U.S. gal. | 31.3 L 8.3 U.S. gal. | 37.2 L 9.8 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. | 70 L 18.5 U.S. gal. | 70 L 18.5 U.S. gal. | 70 L 18.5 U.S. gal. | 96 L 25 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. |
| Cooling System Capacity | 11.8 gal. | ||||||||||||||||
| Cooling System Capacity | 44.5 L | ||||||||||||||||
| Transmission - Hydraulic System | 42.3 gal. | 160 L 42.3 U.S. gal. | 160 L 42.3 U.S. gal. | 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 197 L 52 U.S. gal. | 1930-mm and 2032-mm (76-in. and 80-in.) tread: 250 L 66.1 U.S. gal. 2235-mm and 3048-mm (88-in. and 120-in.) tread: 260.6 L 68.8 U.S. gal. | 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 197 L 52 U.S. gal. | 1930-mm and 2032-mm (76-in. and 80-in.) tread: 250 L 661. U.S. gal. 2235-mm and 3048-mm (88-in. and 120-in.) tread: 260.6 L 68.8 U.S. gal. | ||||||||
| Transmission - Hydraulic System | 160 L | 160 L 42.3 U.S. gal. | 160 L 42.3 U.S. gal. | 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 197 L 52 U.S. gal. | 1930-mm and 2032-mm (76-in. and 80-in.) tread: 250 L 66.1 U.S. gal. 2235-mm and 3048-mm (88-in. and 120-in.) tread: 260.6 L 68.8 U.S. gal. | 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 197 L 52 U.S. gal. | 1930-mm and 2032-mm (76-in. and 80-in.) tread: 250 L 661. U.S. gal. 2235-mm and 3048-mm (88-in. and 120-in.) tread: 260.6 L 68.8 U.S. gal. | ||||||||
| Crankcase Oil Volume | 6.1 gal. | 23 L 6.1 U.S. gal. | 23 L 6.1 gal. | 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L 6.8 U.S. gal. | 25.7 L 6.8 U.S. gal. | 26.6 L 7 U.S. gal. | 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L 6.8 U.S. gal. | 25.7 L 6.8 U.S. gal. | 26.6 L 7 U.S. gal. | ||||||||
| Crankcase Oil Volume | 23 L | 23 L 6.1 U.S. gal. | 23 L 6.1 gal. | 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L 6.8 U.S. gal. | 25.7 L 6.8 U.S. gal. | 26.6 L 7 U.S. gal. | 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L 6.8 U.S. gal. | 25.7 L 6.8 U.S. gal. | 26.6 L 7 U.S. gal. | ||||||||
Dimensions & Weights | |||||||||||||||||
| Wheelbase | 115.2 in. | 2,925 mm 115.2 in. | 2,925 mm 115.2 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | 3235 mm 127.36 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | 3235 mm 127.36 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | 3150 mm 124 in. | 3150 mm 124 in. | 3150 mm 124 in. | 2,995 mm 117.9 in. | Ultra Command™ full-powershift: 3,450 mm 136 in. Auto Command™ CVT: 3,500 mm 138 in. | Ultra Command™ full-powershift: 3,450 mm 136 in. Auto Command™ CVT: 3,500 mm 138 in. | ||
| Wheelbase | 2925 mm | 2,925 mm 115.2 in. | 2,925 mm 115.2 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | 3235 mm 127.36 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | 3235 mm 127.36 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | 3150 mm 124 in. | 3150 mm 124 in. | 3150 mm 124 in. | 2,995 mm 117.9 in. | Ultra Command™ full-powershift: 3,450 mm 136 in. Auto Command™ CVT: 3,500 mm 138 in. | Ultra Command™ full-powershift: 3,450 mm 136 in. Auto Command™ CVT: 3,500 mm 138 in. | ||
| Base Machine Weight | 25133 lb. | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | VT, TLS, 480/80R50 tires: 11,000 kg 24,300 lb | ILS™/e23: 12,864 kg 28,301 lb | e23, 63.5-cm (25-in.) tracks: 12,538 kg 27,584 lb | e23, 457-mm (18-in.) front/rear and 3048-mm (120-in.) tread: 19,591 kg 43,100 lb | ILS™/e23: 12,864 kg 28,301 lb | e23, 63.5-cm (25-in.) tracks: 12,538 kg 27,584 lb | e23, 457-mm (18-in.) front/rear and 3048-mm (120-in.) tread: 19,591 kg 43,100 lb | MFWD: 13,082 kg 26,800 lb | MFWD: 13,458 kg 29,600 lb | Suspended front axle: 10,300 kg 22,707 lb | 10,070 kg 22,200 lb | 10,150 kg 22,377 lb | |||
| Base Machine Weight | 11400 kg | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | VT, TLS, 480/80R50 tires: 11,000 kg 24,300 lb | ILS™/e23: 12,864 kg 28,301 lb | e23, 63.5-cm (25-in.) tracks: 12,538 kg 27,584 lb | e23, 457-mm (18-in.) front/rear and 3048-mm (120-in.) tread: 19,591 kg 43,100 lb | ILS™/e23: 12,864 kg 28,301 lb | e23, 63.5-cm (25-in.) tracks: 12,538 kg 27,584 lb | e23, 457-mm (18-in.) front/rear and 3048-mm (120-in.) tread: 19,591 kg 43,100 lb | MFWD: 13,082 kg 26,800 lb | MFWD: 13,458 kg 29,600 lb | Suspended front axle: 10,300 kg 22,707 lb | 10,070 kg 22,200 lb | 10,150 kg 22,377 lb | |||
| Overall Height | 137.6 in. | ||||||||||||||||
| Overall Height | 3494 mm | ||||||||||||||||
| Overall Length | 232.7 in. | 5,540 mm 218 in. | 5,540 mm 218 in. | 6,636 mm 261.3 in. | 6,636 mm 261.3 in. | With front weights: 6260 mm 246.4 in. | With front weights: 6490 mm 255.5 in. | 5575 mm 219.5 in. | 5575 mm 219.5 in. | 5575 mm 219.5 in. | Ultra Command™ full-powershift: with front weight package and rear linkage: 6,635 mm 261 in. Auto Command™ CVT: with front weight package and rear linkage: 6,685 mm 263 in. | Ultra Command™ full-powershift: with front weight package and rear linkage: 6,635 mm 261 in. Auto Command™ CVT: with front weight package and rear linkage: 6,685 mm 263 in. | |||||
| Overall Length | 5910 mm | 5,540 mm 218 in. | 5,540 mm 218 in. | 6,636 mm 261.3 in. | 6,636 mm 261.3 in. | With front weights: 6260 mm 246.4 in. | With front weights: 6490 mm 255.5 in. | 5575 mm 219.5 in. | 5575 mm 219.5 in. | 5575 mm 219.5 in. | Ultra Command™ full-powershift: with front weight package and rear linkage: 6,635 mm 261 in. Auto Command™ CVT: with front weight package and rear linkage: 6,685 mm 263 in. | Ultra Command™ full-powershift: with front weight package and rear linkage: 6,635 mm 261 in. Auto Command™ CVT: with front weight package and rear linkage: 6,685 mm 263 in. | |||||
| Front Axle Ground Clearance | 26.3 in. | ||||||||||||||||
| Front Axle Ground Clearance | 668 mm | ||||||||||||||||
| Drawbar Ground Clearance | 18.2 in. | ||||||||||||||||
| Drawbar Ground Clearance | 463 mm | ||||||||||||||||
| Maximum Ballast Level | 135 lb. | SAE PTO hp: 61.2 kg 135 lb | SAE PTO hp: 61.2 kg 135 lb | 20,000 kg 44,100 lb | 17,700 kg 39,000 lb | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | 17,700 kg 39,000 lb | 20,000 kg 44,100 lb | ||||||||
| Maximum Ballast Level | 61 kg | SAE PTO hp: 61.2 kg 135 lb | SAE PTO hp: 61.2 kg 135 lb | 20,000 kg 44,100 lb | 17,700 kg 39,000 lb | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | 17,700 kg 39,000 lb | 20,000 kg 44,100 lb | ||||||||
| Maximum Permissible Weight | 39683 lb. | 20,000 kg 44,100 lb | 18,200 kg 40,100 lb | 24,000 kg 53,000 lb | 20,000 kg 44,100 lb | 18,200 kg 40,100 lb | 24,000 kg 53,000 lb | 16,260 kg 35,847 lb | 17,758 kg 39,150 lb | 19,000 kg 42,000 lb | 19,000 kg 42,000 lb | 19,000 kg 42,000 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | 12,580 kg 27,734 lb | 14,420 kg 31,791 lb | ||
| Maximum Permissible Weight | 18000 kg | 20,000 kg 44,100 lb | 18,200 kg 40,100 lb | 24,000 kg 53,000 lb | 20,000 kg 44,100 lb | 18,200 kg 40,100 lb | 24,000 kg 53,000 lb | 16,260 kg 35,847 lb | 17,758 kg 39,150 lb | 19,000 kg 42,000 lb | 19,000 kg 42,000 lb | 19,000 kg 42,000 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | 12,580 kg 27,734 lb | 14,420 kg 31,791 lb | ||
Additional Information | |||||||||||||||||
| Country of Manufacture | USA | USA | USA | USA | USA | USA | USA | USA | USA | United States | United States | Germany | Germany | Germany | United Kingdom | USA | USA |
| Date Collected | 4/3/2025 12:00:00 AM | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 7-Feb-20 | 15-Oct-19 | 24-feb-2020 | 24-Feb-2020 | 24-Feb-2020 | 16-Oct-19 | 14-Oct-19 | 14-Oct-19 |
