When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.
Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.
Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.
Answer text goes here
Machine Configuration | ||||||||||||||
| Wheel or Track Configuration | Wheel | |||||||||||||
| Drive Type | 4WD | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Planetary/inboard | Planetary/inboard | Inboard planetary double reduction (HA 200) | Inboard planetary double reduction (HA 200) | Inboard planetary | ||||
Engine | ||||||||||||||
| Engine Make | John Deere | |||||||||||||
| Engine Family | MJDXL06.8309 | MJDXL06.8309 | MJDXL09.0319 | MJDXL09.0333 | MJDXL09.0333 | |||||||||
| Emissions Certifications | Final Tier 4 | |||||||||||||
| Displacement | 415 cu in. | 6.8 L 415 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. | 6.06 L 369.8 cu in. | 6.06 L 369.8 cu in. | 9.0 L 549 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. |
| Displacement | 6.8 L | 6.8 L 415 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 9.0 L 549 cu in. | 8.7 L 531 cu in. | 8.7 L 531 cu in. | 6.06 L 369.8 cu in. | 6.06 L 369.8 cu in. | 9.0 L 549 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. | 6.7 L 411 cu in. |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series | Single turbocharger, variable geometry turbo | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation | Electronical variable geometry turbocharger (VGT), aftercooled | Electronical variable geometry turbocharger (VGT), aftercooled | Twin turbos with intermediate intercooler and air-to-air aftercooling | Twin turbos with intermediate intercooler and air-to-air aftercooling | Variable geometry turbo | Turbocharged, air-to-air aftercooled | Turbocharged, air-to-air aftercooled | VGT turbocharged, air-to-air aftercooled | VGT turbocharged, air-to-air aftercooled |
| Number of Cylinders | 6 | |||||||||||||
| Cylinder Liners | Wet-sleeve cylinder liners | |||||||||||||
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) | |||||||||||||
| Intelligent Power Management (IPM) | Power boost: 29.6 hp / 22.1 kW / 30 PS (hp ISO) | |||||||||||||
| Rated Engine Speed | 2100 rpm | |||||||||||||
| Rated Engine Power | 266 hp (hp SAE) | ECE-R120: 184 kW 250 hp | ECE-R120: 213 kW 290 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp | ECE-R120: 209 kW 280 hp | ECE-R120: 186 kW 250 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 162 kW 220 hp | ECE-R120: 177 kW 240 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 221 kW 300 hp |
| Rated Engine Power | 199 kW | ECE-R120: 184 kW 250 hp | ECE-R120: 213 kW 290 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp | ECE-R120: 209 kW 280 hp | ECE-R120: 186 kW 250 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 162 kW 220 hp | ECE-R120: 177 kW 240 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 221 kW 300 hp |
| Rated Engine Power | 270 PS (hp ISO) | ECE-R120: 184 kW 250 hp | ECE-R120: 213 kW 290 hp | ECE-R120: 184 kW 250 hp | ECE-R120: 206 kW 280 hp | ECE-R120: 209 kW 280 hp | ECE-R120: 186 kW 250 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 162 kW 220 hp | ECE-R120: 177 kW 240 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 221 kW 300 hp |
| Engine Torque at Rated Speed | 918 lb-ft | |||||||||||||
| Engine Torque at Rated Speed | 1245 Nm | |||||||||||||
| Maximum Engine Power | 293 hp (hp SAE) | ECE-R120: 202 kW 275 hp | ECE-R120: 235 kW 319 hp | ECE-R120: 202 kW 275 hp | ECE-R120: 227 kW 308 hp | ECE-R120: 261 kW 350 hp | ECE-R120: 239 kW 320 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 191 kW 260 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 212 kW 290 hp | ECE-R120: 230 kW 313 hp |
| Maximum Engine Power | 218 kW | ECE-R120: 202 kW 275 hp | ECE-R120: 235 kW 319 hp | ECE-R120: 202 kW 275 hp | ECE-R120: 227 kW 308 hp | ECE-R120: 261 kW 350 hp | ECE-R120: 239 kW 320 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 191 kW 260 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 212 kW 290 hp | ECE-R120: 230 kW 313 hp |
| Maximum Engine Power | 297 PS (hp ISO) | ECE-R120: 202 kW 275 hp | ECE-R120: 235 kW 319 hp | ECE-R120: 202 kW 275 hp | ECE-R120: 227 kW 308 hp | ECE-R120: 261 kW 350 hp | ECE-R120: 239 kW 320 hp | At 2100 rpm per 97/68EC PS: 190.9 kW 256 hp | At 2100 rpm per 97/68EC PS: 205.8 kW 276 hp | ECE R120: 217 kW 296 hp | ECE-R120: 191 kW 260 hp | ECE-R120: 199 kW 270 hp | ECE-R120: 212 kW 290 hp | ECE-R120: 230 kW 313 hp |
| Maximum Engine Torque | At 1600 rpm: 1245 Nm (918 lb-ft) | |||||||||||||
| Fuel Type | Diesel | |||||||||||||
| Torque Rise | 40 % | 40 percent | 40 percent | 40 percent | 40 percent | |||||||||
Transmission | ||||||||||||||
| Transmission Type | John Deere e23™ 42 km/h (26 mph); Optional: John Deere e23™ Transmission 50 km/h (31 mph), John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph), John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) | Standard: John Deere e23™ 42 26 mph Optional: John Deere e23 transmission 50 km/h 31 mph John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph) John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) | Standard: John Deere e23™ 42 km/h 26 mph Optional: John Deere e23 transmission 50 km/h 31 mph John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph) John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: 16-speed PowerShift 40 km/h e23 PowerShift with Efficiency Manager 50K, 50 km/h 31 mph John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph John Deere AutoPowr IVT 50K, 0.05-50 km/h 0.03-31 mph | Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h 24.9 mph Optional: 16-speed PowerShift 40 km/h e23 PowerShift with Efficiency Manager 50K, 50 km/h 31 mph John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph John Deere AutoPowr IVT 50K, 0.05-50 km/h 0.03-31 mph | Standard: 19-speed Powershift: 40 K Optional: 23-speed Powershift: 40 K 19-speed Powershift 50 K CVT: 40 or 50 K | Standard: 19-speed Powershift: 40 K Optional: 23-speed Powershift: 40 K 19-speed Powershift 50 K CVT: 40 or 50 K | ML 220 Vario CVT, 50 km/h 31 mph | ML 220 Vario CVT, 50 km/h 31 mph | Stepless VarioDrive transmission: TA 300 Vario CVT 50 km/h 31 mph | Standard: Classic: Power Command™ full-powershift (40K) SideWinder™ II: Auto Command™ CVT (40K) Optional: Classic: Power Command full-powershift (50K) SideWinder II: Auto Command CVT (50K) | Standard: Auto Command™ CVT (40K) Optional: Auto Command™ CVT (50K) | Standard: Auto Command™ CVT (40K) Optional: Auto Command™ CVT (50K) | Standard: Auto Command™ CVT (40K) Optional: Auto Command™ CVT (50K) |
| Maximum Speed Forward | 31 mph (50 km/h) | |||||||||||||
| Minimum Speed Forward | 0.03 mph (0.050 km/h) | |||||||||||||
Rear Power Take-Off (PTO) | ||||||||||||||
| PTO Category | Independent; Standard: 44.45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 44.45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540E/1000/1000E rpm gearcase; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540/540E/1000 rpm gearcase | |||||||||||||
| Rated PTO Power | 224 hp | 152 kW 205 hp | 180 kW 242 hp | 149 kW 200 hp | 170 kW 228 hp | 175 kW 235 hp | 153 kW 205 hp | At 2100 rpm per SAE: 167.8 kW 225 hp | At 2100 rpm per SAE: 182.7 kW 245 hp | 177 kW 237 hp | 140 kW 190 hp | 154 kW 210 hp | 178 kW 240 hp | 199 kW 270 hp |
| Rated PTO Power | 167 kW | 152 kW 205 hp | 180 kW 242 hp | 149 kW 200 hp | 170 kW 228 hp | 175 kW 235 hp | 153 kW 205 hp | At 2100 rpm per SAE: 167.8 kW 225 hp | At 2100 rpm per SAE: 182.7 kW 245 hp | 177 kW 237 hp | 140 kW 190 hp | 154 kW 210 hp | 178 kW 240 hp | 199 kW 270 hp |
| Rated PTO Power | 227 PS | 152 kW 205 hp | 180 kW 242 hp | 149 kW 200 hp | 170 kW 228 hp | 175 kW 235 hp | 153 kW 205 hp | At 2100 rpm per SAE: 167.8 kW 225 hp | At 2100 rpm per SAE: 182.7 kW 245 hp | 177 kW 237 hp | 140 kW 190 hp | 154 kW 210 hp | 178 kW 240 hp | 199 kW 270 hp |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1950 | |||||||||||||
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | 1750 | |||||||||||||
| Engagement Method | Electric switch with adjustable modulation | |||||||||||||
| Number of Splines | 20 | |||||||||||||
Front PTO | ||||||||||||||
| PTO Speed | 1000 | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 540/1,000 rpm: 1,893/1,950 rpm SideWinder II: 540E/1,000 rpm: 1569/1893 rpm 1,000/1,000E rpm: 1,912/1,583 rpm | 540/1,000 rpm: 1,893/1,950 rpm SideWinder II: 540E/1,000 rpm: 1569/1893 rpm SideWinder II: 1,000/1,000E rpm: 1912/1583 rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | |||||
| Front PTO Rotation | Counter-clockwise | |||||||||||||
| Engine rpm (at Rated PTO Speeds) | 1940 rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpm IVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpm e23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm | 540/1,000 rpm: 1,893/1,950 rpm SideWinder II: 540E/1,000 rpm: 1569/1893 rpm 1,000/1,000E rpm: 1,912/1,583 rpm | 540/1,000 rpm: 1,893/1,950 rpm SideWinder II: 540E/1,000 rpm: 1569/1893 rpm SideWinder II: 1,000/1,000E rpm: 1912/1583 rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | 540/540E/1000/1000E shiftable 1930/1598/1853/1583 rpm | |||||
| Front Number of Splines | 21 | |||||||||||||
Front Hitch | ||||||||||||||
| Front Hitch Category | Category 3N, ground engaging | Category 3N, ground engaging | Category 3N, ground engaging | Category 3N | Category 3N | Optional: 4275 kg 9426 lb | Optional: 4275 kg 9426 lb | Optional Category 2 | Optional Category 2 | Optional | Optional | Optional | Optional | |
| Lift Capacity Through Full Lift Range at Coupling Points | 6945 lb. | |||||||||||||
| Lift Capacity Through Full Lift Range at Coupling Points | 3150 kg | |||||||||||||
| Maximum Lift Capacity at Coupling Points | 11464 lb. | |||||||||||||
| Maximum Lift Capacity at Coupling Points | 5200 kg | |||||||||||||
| Number of Front Selective Control Valves (SCVs) | One with front hitch | One with front hitch | One with front hitch | ISO couplers: two | ISO couplers: two | ISO couplers: two | ||||||||
| Electric Power | Seven-pin connector | |||||||||||||
Rear Hitch | ||||||||||||||
| Rear Hitch Category (SAE Designation) | Standard: Category 3N/3 with Quik-Coupler; Optional: Category 3/3N with hook ends, Category 3N/3 with hook ends | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends Category 3N/3 with hook ends | Standard: Category 3N/3 with Quik-Coupler Optional: Category 3/3N with hook ends Category 3N/3 with hook ends | Standard: Category 3/3N standard lift at 610 mm (24 in.) behind hitch point: 6350 14,000 lb Optional: Category 3/3N at 610 mm (24 in.) behind hitch point: 8391 kg 18,500 lb Category 4N/3 at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb | Standard: Category 3/3N standard lift at 610 mm (24 in.) behind hitch point: 6350 14,000 lb Optional: Category 3/3N at 610 mm (24 in.) behind hitch point: 8391 kg 18,500 lb Category 4N/3 at 610 mm (24 in.) behind hitch point: 9072 kg 20,000 lb | Standard: Category 3/3N Optional: Category 4N/3 | Standard: Category 3/3N | Standard: Category 2/3 Optional: Category 4 | Standard: Category 2/3 Optional: Category 4 | Standard: Category 3/4N: 9750 kg 21,500 lb | ||||
| Maximum Lift Capacity Directly at Coupling Points | 22258 | |||||||||||||
| Lift Capacity Through Full Lift Range at Coupling Points | 6945 | |||||||||||||
| Maximum Lift Capacity at 610-mm Behind Hitch Point | 17,306.3 lb 7,850 kg | |||||||||||||
| Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point | 15,212 lb 6,900 kg | |||||||||||||
| Sensing Type | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | |||||||||
Drawbar | ||||||||||||||
| Drawbar Category | Category 3; Optional: Category 3 with heavy-duty support; Category 4 | Standard: Category 3 Optional: Category 3 with heavy-duty support Category 4 | Standard: Category 3 Optional: Category 3 with heavy-duty support Category 4 | Standard: Category 3 Optional: Category 4 Category 4 with heavy-duty support | Standard: Category 3 Optional: Category 4 Category 4 with heavy-duty support | Standard: Category 3 Optional: Category 4 | Standard: Category 3 Optional: Category 4 | Standard: Category 3 | Standard: Category 3 | Category 3 | Category 3 | |||
| Maximum Vertical Load | Standard: Category 3: 1,837 kg (4,050 lb); Optional: Category 3 with heavy-duty support: 4,536 kg (10,000 lb) | Standard: Category 3: 1837 kg 4050 lb Optional: Category 3 with heavy-duty support: 4536 kg 10,000 lb | Standard: Category 3: 1,837 kg 4,050 lb Optional: Category 3 with heavy-duty support: 4,536 kg 10,000 lb | Dependent on drawbar position: 1837 to 2700 kg 4050 to 6000 lb Optional: 2,245 kg 4,950 lb 4,990 kg 11,000 lb | Dependent on drawbar position: 1837 to 2700 kg 4050 to 6000 lb Optional: 2,245 kg 4,950 lb 4,990 kg 11,000 lb | 2000 kg 4409 lb | 2000 kg 4409 lb | |||||||
Hydraulics | ||||||||||||||
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated system with load sensing | Closed-center, pressure/flow compensated | Closed-center, pressure/flow compensated | Closed center | Closed center | Closed-center pressure and flow compensated (PFC) | Closed-center, load sensing | Closed-center, load sensing | Closed-center, load sensing | Closed-center, load sensing |
| Pump Rated Output | Standard: 63 cc: 162 L/min (43 gpm); Optional: 85 cc: 222.3 L/min (59 gpm) | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm | Powershift: 166 L/min 44 gpm CVT: 225 L/min 59 gpm Optional: 282 L/min 75 gpm | Powershift: 166 L/min 44 gpm CVT: 225 L/min 59 gpm Optional: 282 L/min 75 gpm | Standard: 151.4 L/min 40 gpm Optional: 193 L/min 51 gpm | Standard: 151.4 L/min 40 gpm Optional: 193 L/min 51 gpm | Standard: 165 L 43.6 gpm Optional: 220 L 58 gpm 430 L 113.5 gpm | Standard: Power Command™: 120 L/min 32 gpm Auto Command™: 150 L/min 39.5 gpm Optional: Power Command™: 150 L/min Auto Command: 170 L/min 45 gpm | Standard: 150 L/min 39.5 gpm Optional: 170 L/min 45 gpm | Standard: 165 L/min 43.5 gpm Optional: 220 L/min 58 gpm | Standard: 165 L/min 43.5 gpm Optional: 220 L/min 58 gpm |
| Number of Rear Selective Control Valves (SCVs) | Standard: Four SCVs; Optional: Three to five ISO couplers: 12.7 mm (1/2 in.); Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: 1.3-cm (1/2-in.) ISO couplers: 4 Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available | Standard: four ISO couplers Optional: ISO couplers 5 and 6 | Standard: four ISO couplers Optional: ISO couplers 5 and 6 | Standard: four Optional: eight | Standard: four Optional: eight | ISO couplers: up to six | Standard: Three Optional: Up to five electrohydraulic | Standard: Three Optional: Up to five electrohydraulic | Standard: Four Optional: Up to five electrohydraulic | Standard: Four Optional: Up to five electrohydraulic |
| Available Flow at a Single Rear SCV | 35 gpm (132 L/min) | 132 L/min 35 gpm | 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm | |||||||||
| Number of Mid Selective Control Valves (SCVs) | 3 | Up to three | Up to three | Up to three | Up to three | |||||||||
| Available Flow at Front SCVs | 33 gpm | 126 L/min 33 gpm | 126 L/min 33 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | |||||||||
| Available Flow at Front SCVs | 126 L/min | 126 L/min 33 gpm | 126 L/min 33 gpm | 96 L/min 25 gpm | 96 L/min 25 gpm | |||||||||
| SCV Control | Electronic | Standard | Standard | Standard | Optional | Optional | Optional | Optional | ||||||
Front Axle | ||||||||||||||
| Front Axle Type | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm (60 to 88 in.); Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h (24.9 mph); TLS with front brakes standard with 50 km/h (31 mph) | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm 60 to 88 in. Optional: TLS: Tread range 1524 to 2235 mm TLS with front brakes available with 40 km/h 24.9 mph TLS with front brakes standard with 50 km/h 31 mph | Standard: 1300 Series MFWD: tread range 1524 to 2235 mm 60 to 88 in. Optional: TLS: Tread range 1524 to 2235 mm TLS with front brakes available with 40 km/h 24.9 mph TLS with front brakes standard with 50 km/h 31 mph | Standard: 1300 Series MFWD Optional: 1500 Series MFWD ILS | Standard: 1300 Series MFWD Optional: 1500 Series MFWD ILS | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended | Mechanical front-wheel drive (MFWD) with suspension | Mechanical front-wheel drive (MFWD) with suspension | Independent suspension | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended Supersteer™ | Standard: Mechanical front-wheel drive (MFWD) Optional: Suspended Supersteer™ | Standard: Suspended | Standard: Suspended |
| Front Axle Differential Lock | 1300 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) | 1300 Series MFWD: Limited slip TLS: Limited slip TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) | 1300 Series MFWD: Limited slip TLS: Limited slip TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) | 1300 Series MFWD: Limited Slip 1500 Series MFWD: Full-locking electrohydraulic ILS: Full-locking electrohydraulic | 1300 Series MFWD: Limited Slip 1500 Series MFWD: Full-locking electrohydraulic ILS: Full-locking electrohydraulic | |||||||||
Rear Axle | ||||||||||||||
| Rear Axle Type | Standard: Rack-and-pinion or flange axles; Optional: Diameter: 110 x 2550 mm (4.33 x 100.4 in.); Diameter: 110 x 3010 mm (4.33 x 118.5 in.); Diameter: 120 x 2550 mm (4.72 x 100.4 in.); Diameter: 120 x 3010 mm (4.72 x 118.5 in.); Flanged Axle: 335 mm (13.2 in.) | Standard: Rack-and-pinion or flange axles Optional: Diameter: 110 x 2550 mm 4.33 x 100.4 in. Diameter: 110 x 3010 mm 4.33 x 118.5 in. Diameter: 120 x 2550 mm 4.72 x 100.4 in. Diameter: 120 x 3010 mm 4.72 x 118.5 in. Flanged axle: 335 mm (13.2 in.) | Standard: Rack-and-pinion or flange axles Optional: Diameter: 110 x 2550 mm 4.33 x 100.4 in. Diameter: 110 x 3010 mm 4.33 x 118.5 in. Diameter: 120 x 2550 mm 4.72 x 100.4 in. Diameter: 120 x 3010 mm 4.72 x 118.5 in. Flanged axle: 335 mm (13.2 in.) | Standard: Rack-and-pinion, double flat, or flange axles Optional: Long, single taper hub: Diameter: 110 x 3010 mm 4.33 x 118.5 in. Long, dual taper hub: Diameter: 110 x 3010 mm Long, dual taper hub: Diameter: 120 x 3010 mm 4.72 x 118.5 in. Short, double flat axle with single taper hub: Diameter: 120 x 2550 mm 4.72 x 100.4 in. | Standard: Rack-and-pinion, double flat, or flange axles Optional: Long, dual taper hub: Diameter: 110 x 3010 mm 4.33 x 118.5 in. Short, double flat axle with single taper hub: Diameter: 120 x 2550 mm 4.72 x 100.4 in. | Standard: Bar axle, diameter: 100 x 3050 mm 4.0 x 120 in. Optional: Diameter: 115 x 3050 mm 4.5 x 120 in. | Standard: Bar axle, diameter: 100 x 3050 mm 4.0 x 120 in. Optional: Diameter: 115 x 3050 mm 4.5 x 120 in. | Standard: Flange | Standard: Flange Optional: Bar axle | Standard: Flange Optional: Bar axle | Standard: Flange Optional: Bar axle | Standard: Flange Optional: Bar axle | ||
| Rear Differential Lock | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Full-locking electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | ||||
| Final Drive | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Inboard planetary three pinion | Planetary/inboard | Planetary/inboard | Inboard planetary double reduction (HA 200) | Inboard planetary double reduction (HA 200) | Inboard planetary | ||||
Steering & Brakes | ||||||||||||||
| Steering Type | Hydraulic power-steering with electric pump back-up; Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS™ 2) with electronic backup pump | Standard: Hydraulic power-steering with electric pump back-up Optional: ActiveCommand Steering 2 (ACS™ 2) with electronic backup pump | |||||||||
Tires | ||||||||||||||
| Rear Tires Size | RCI Group 47/48/49 | |||||||||||||
Electrical System | ||||||||||||||
| Battery Voltage | 12 V | |||||||||||||
| Battery Cold Cranking Amps | 1900 CCA | |||||||||||||
| Battery Capacity | 2 x 950 CCA | |||||||||||||
| Alternator Capacity | Standard: 210 amp, Optional: 250 amp | |||||||||||||
| Working Lights | Standard: 18 halogen; Available: 18 light-emitting diode (LED) and two halogen or 22 LED and two halogen | Standard: 18 halogen Available: 18 LED or 22 LED | Standard: 18 halogen Available: 18 LED or 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | Standard: 18 halogen Available: 18 LED 22 LED | |||||||||
| Driving Lights | Standard: 65-W halogen; Available: LED | |||||||||||||
Operator Station | ||||||||||||||
| Seat Suspension | Air seat (Standard), ActiveSeat™ II (Optional) | |||||||||||||
| Degree of Seat Swivel, Left Hand | 8 degree (angle) | |||||||||||||
| Degree of Seat Swivel, Right Hand | 40 degree (angle) | |||||||||||||
| Cab Suspension | Adjustable cab suspension (Optional) | Optional: Adjustable cab suspension | Optional: Adjustable cab suspension | Optional: Adjustable cab suspension | Optional: Adjustable cab suspension | Standard | Standard | Standard: Three-point mechanical Optional: Three-point pneumatic | Standard: Three-point mechanical Optional: Three-point pneumatic | Three-point pneumatic | Classic: Comfort Ride™ optional SideWinder™ II: Comfort Ride™ optional | Classic: Comfort Ride™ optional SideWinder™ II: Comfort Ride™ optional | Classic: Comfort Ride™ optional SideWinder™ II: Comfort Ride™ optional | Classic: Comfort Ride™ optional SideWinder™ II: Comfort Ride™ optional |
| Instructional Seat | Standard | Standard | Standard | Standard | Standard | Standard | ||||||||
| Primary Display | G5 - 12.8 in. (32.5 cm) | |||||||||||||
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna | |||||||||
| Inner Cab Volume | 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | |||||||
| Inner Cab Volume | 3.24 m³ | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.24 m3 114 cu ft | 3.1 m3 109.5 cu ft | 3.1 m3 109.5 cu ft | |||||||
| Cab Glass Area | 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | |||||||
| Cab Glass Area | 6.56 m² | 6.56 m2 70.61 sq ft | 6.56 m2 70.61 sq ft | 6.52 m2 70.18 sq ft | 6.52 m2 70.18 sq ft | 6.4 m2 68.5 sq ft | 6.4 m2 68.5 sq ft | |||||||
Technology Integration | ||||||||||||||
| Guidance | Integrated AutoTrac™ | Integrated AutoTrac™ | Integrated AutoTrac™ | Integrated AutoTrac™ Autonomy Ready (available in select regions) | Integrated AutoTrac™ Autonomy Ready (available in select regions) | AFS AccuGuide™ Ready | AFS AccuGuide™ Ready | VarioGuide | VarioGuide | VarioGuide | Intellisteer™ guidance | Intellisteer™ guidance | Intellisteer™ guidance | Intellisteer™ guidance |
| Connectivity | JDLink™ | |||||||||||||
| Remote Diagnostics | ServiceADVISOR™ Remote: available with JDLink hardware and activations; Remote Display Access: available with JDLink hardware and activations | ServiceADVISOR™ Remote: available with JDLink hardware and activations Remote Display Access: available with JDLink hardware and activations | ServiceADVISOR™ Remote: available with JDLink hardware and activations Remote Display Access: available with JDLink hardware and activations | JDLink hardware standard | JDLink hardware standard | |||||||||
Capacities | ||||||||||||||
| Fuel Tank Capacity | 122 (e23™), 135 (IVT™) gal. | |||||||||||||
| Fuel Tank Capacity | 463 (e23™), 513 (IVT™) L | |||||||||||||
| Diesel Exhaust Fluid (DEF) Tank Capacity | 6.9 gal. | 26.2 L 6.9 U.S. gal. | 26.2 L 6.9 U.S. gal. | 37.2 L 9.8 U.S. gal. | 37.2 L 9.8 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. | 50 L 13 U.S. gal. | 50 L 13 U.S. gal. | 70 L 18.5 U.S. gal. | 48 L 13 U.S. gal. | 48 L 13 U.S. gal. | 96 L 25 U.S. gal. | 96 L 25 U.S. gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 26.2 L | 26.2 L 6.9 U.S. gal. | 26.2 L 6.9 U.S. gal. | 37.2 L 9.8 U.S. gal. | 37.2 L 9.8 U.S. gal. | 99 L 26 U.S. gal. | 99 L 26 U.S. gal. | 50 L 13 U.S. gal. | 50 L 13 U.S. gal. | 70 L 18.5 U.S. gal. | 48 L 13 U.S. gal. | 48 L 13 U.S. gal. | 96 L 25 U.S. gal. | 96 L 25 U.S. gal. |
| Cooling System Capacity | 10.4 gal. | |||||||||||||
| Cooling System Capacity | 39.5 L | |||||||||||||
| Transmission - Hydraulic System | 42.3 gal. | 160 L 42.3 U.S. gal. | 160 L 42.3 U.S. gal. | 1300 MFWD: 180.7 L 47.7 U.S. gal. 1300 MFWD: 184.6 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 1300 MFWD: 180.7 L 37 U.S. gal. 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | |||||||||
| Transmission - Hydraulic System | 160 L | 160 L 42.3 U.S. gal. | 160 L 42.3 U.S. gal. | 1300 MFWD: 180.7 L 47.7 U.S. gal. 1300 MFWD: 184.6 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | 1300 MFWD: 180.7 L 37 U.S. gal. 1500 MFWD: 184.6 L 48.8 U.S. gal. ILS: 207.2 L 54.7 U.S. gal. | |||||||||
| Crankcase Oil Volume | 6.9 gal. | 26 L 6.9 U.S. gal. | 23 L 6.1 U.S. gal. | 1300 MFWD: 25.7 L 6.8 U.S. gal. 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L | 1300 MFWD: 25.7 L 6.8 U.S. gal. 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L | |||||||||
| Crankcase Oil Volume | 26 L | 26 L 6.9 U.S. gal. | 23 L 6.1 U.S. gal. | 1300 MFWD: 25.7 L 6.8 U.S. gal. 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L | 1300 MFWD: 25.7 L 6.8 U.S. gal. 1500 MFWD: 27.6 L 7.3 U.S. gal. ILS: 25.8 L | |||||||||
Dimensions & Weights | ||||||||||||||
| Wheelbase | 115.2 in. | 2925 mm 115.2 in. | 2,925 mm 115.2 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | 2950 mm 116 in. | 2950 mm 116 in. | 3150 mm 124 in. | Standard front axle: 2,884 mm 113.5 in. Suspended front axle: 2,884 mm Supersteer™ front axle: 2,977 mm 117.2 in. | Standard front axle: 2,884 mm 113.5 in. Suspended front axle: 2,884 mm Supersteer™ front axle: 2,977 mm 117.2 in. | 2,995 mm 117.9 in. | 2,995 mm 117.9 in. |
| Wheelbase | 2925 mm | 2925 mm 115.2 in. | 2,925 mm 115.2 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | MFWD: 3,080 mm 121.3 in. ILS: 3,050 mm 120.1 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | Powershift: 3050 mm 120 in. CVT: 3100 mm 122 in. | 2950 mm 116 in. | 2950 mm 116 in. | 3150 mm 124 in. | Standard front axle: 2,884 mm 113.5 in. Suspended front axle: 2,884 mm Supersteer™ front axle: 2,977 mm 117.2 in. | Standard front axle: 2,884 mm 113.5 in. Suspended front axle: 2,884 mm Supersteer™ front axle: 2,977 mm 117.2 in. | 2,995 mm 117.9 in. | 2,995 mm 117.9 in. |
| Base Machine Weight | 25133 lb. | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | MFWD/PowerShift: 11,812 kg 25,986 lb ILS™/e23: 12,864 kg 28,301 lb | MFWD/PowerShift: 11,812 kg 25,986 lb ILS™/e23: 12,864 kg 28,301 lb | MFWD: 13,082 kg 26,800 lb | MFWD: 13082 kg 26,800 lb | Standard front axle: 6950 kg 15,322 lb Suspended front axle: 7300 kg 16,094 lb Supersteer™ front axle: 7100 kg 15,653 lb | Standard front axle: 6950 kg 15,322 lb Suspended front axle: 7300 kg 16,094 lb Supersteer™ front axle: 7100 kg 15,653 lb | Suspended front axle: 10,300 kg 22,707 lb | Suspended front axle: 10,300 kg 22,707 lb | |||
| Base Machine Weight | 11400 kg | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb | MFWD/PowerShift: 11,812 kg 25,986 lb ILS™/e23: 12,864 kg 28,301 lb | MFWD/PowerShift: 11,812 kg 25,986 lb ILS™/e23: 12,864 kg 28,301 lb | MFWD: 13,082 kg 26,800 lb | MFWD: 13082 kg 26,800 lb | Standard front axle: 6950 kg 15,322 lb Suspended front axle: 7300 kg 16,094 lb Supersteer™ front axle: 7100 kg 15,653 lb | Standard front axle: 6950 kg 15,322 lb Suspended front axle: 7300 kg 16,094 lb Supersteer™ front axle: 7100 kg 15,653 lb | Suspended front axle: 10,300 kg 22,707 lb | Suspended front axle: 10,300 kg 22,707 lb | |||
| Overall Height | 137.6 in. | |||||||||||||
| Overall Height | 3494 mm | |||||||||||||
| Overall Length | 232.7 in. | 5540 mm 218 in. | 5,540 mm 218 in. | 6,636 mm 261.3 in. | 6,636 mm 261.3 in. | With front weights: 6260 mm 246.4 in. | With front weights: 6260 mm 246.4 in. | 5275 mm 208 in. | 5275 mm 208 in. | 5575 mm 219.5 in. | ||||
| Overall Length | 5910 mm | 5540 mm 218 in. | 5,540 mm 218 in. | 6,636 mm 261.3 in. | 6,636 mm 261.3 in. | With front weights: 6260 mm 246.4 in. | With front weights: 6260 mm 246.4 in. | 5275 mm 208 in. | 5275 mm 208 in. | 5575 mm 219.5 in. | ||||
| Front Axle Ground Clearance | 26.3 in. | |||||||||||||
| Front Axle Ground Clearance | 668 mm | |||||||||||||
| Drawbar Ground Clearance | 18.2 in. | |||||||||||||
| Drawbar Ground Clearance | 463 mm | |||||||||||||
| Maximum Ballast Level | 145 lb. | SAE PTO hp: 65.8 kg 145 lb | SAE PTO hp: 65.8 kg 145 hp | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | |||||||||
| Maximum Ballast Level | 65 kg | SAE PTO hp: 65.8 kg 145 lb | SAE PTO hp: 65.8 kg 145 hp | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | |||||||||
| Maximum Permissible Weight | 35274 lb. | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | 14,420 kg 31,791 lb | 14,420 kg 31,791 lb | 19,000 kg 42,000 lb | At 50 km/h (31 mph): 13,000 kg 28,660 lb | At 50 km/h (31 mph): 13,000 kg 28,660 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | ||||
| Maximum Permissible Weight | 16000 kg | 20,000 kg 44,100 lb | 20,000 kg 44,100 lb | 14,420 kg 31,791 lb | 14,420 kg 31,791 lb | 19,000 kg 42,000 lb | At 50 km/h (31 mph): 13,000 kg 28,660 lb | At 50 km/h (31 mph): 13,000 kg 28,660 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | At 50 km/h (31 mph): 16,000 kg 35,274 lb | ||||
Additional Information | ||||||||||||||
| Country of Manufacture | USA | USA | USA | USA | USA | United States | United States | Germany | Germany | Germany | United Kingdom | United Kingdom | United Kingdom | United Kingdom |
| Date Collected | 4/3/2025 12:00:00 AM | 28 February 2024 | 28 February 2024 | 28 February 2024 | 28 February 2024 | 7-Feb-20 | 7-Feb-20 | 3-Oct-19 | 3-Oct-19 | 24-Feb-2020 | 16-Oct-19 | 16-Oct-19 | 16-Oct-19 | 16-Oct-19 |
