7 Series Tractors

John Deere 7R 210

Starting at

Key Features

Engine hp: 231 Max / 210 Rated
Fully Integrated Precision Ag Technology
Choice of e23™ Powershift or Infinitely Variable Transmission (IVT™)
Adjustable Cab Suspension Provides a Smoother, More Comfortable Ride

Run Big Acres with Confidence

When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.

Green tractor pulling a large baler across a grassy farm field, with wide tires and a glass cab, set against a flat rural landscape with distant hills and a clear blue sky

Turn Every Pass into Better Decisions

Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.

Person working at a desk using a keyboard and mouse while viewing a large monitor displaying a detailed map interface; a laptop and desk lamp sit nearby in a bright workspace

Stay Comfortable and In Control All Day

Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.

Green tractor driving down an empty paved road with a yellow centerline, with large tires and detailed front end shown against a clear blue sky, with dry, rocky hills and sparse vegetation in the background

Machine Configuration

Wheel or Track Configuration

Wheel

Engine

Engine Make	John Deere
Engine Family	MJDXL06.8309
Emissions Certifications	Final Tier 4
Displacement	415 cu in.
Displacement	6.8 L
Aspiration	Single turbocharger, variable geometry turbo
Number of Cylinders	6
Cylinder Liners	Wet-sleeve cylinder liners
Aftertreatment Type	Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)
Intelligent Power Management (IPM)	Power boost: 29.6 hp / 22.1 kW / 30 PS (hp ISO)
Rated Engine Speed	2100 rpm
Rated Engine Power	207 hp (hp SAE)
Rated Engine Power	154 kW
Rated Engine Power	210 PS (hp ISO)
Engine Torque at Rated Speed	725 lb-ft
Engine Torque at Rated Speed	983 Nm
Maximum Engine Power	228 hp (hp SAE)
Maximum Engine Power	170 kW
Maximum Engine Power	231 PS (hp ISO)
Maximum Engine Torque	At 1600 rpm: 983 Nm (725 lb-ft)
Fuel Type	Diesel
Torque Rise	40 %

Transmission

Transmission Type	John Deere e23™ 42 km/h (26 mph); Optional: John Deere e23™ Transmission 50 km/h (31 mph), John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph), John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph)
Maximum Speed Forward	31 mph (50 km/h)
Minimum Speed Forward	0.03 mph (0.050 km/h)

Rear Power Take-Off (PTO)

PTO Category	Independent; Standard: 44.45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 44.45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540E/1000/1000E rpm gearcase; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540/540E/1000 rpm gearcase
Rated PTO Power	170 hp
Rated PTO Power	126 kW
Rated PTO Power	172 PS
Engine rpm at Rated PTO Speeds (540/1.000)	1950
Engine rpm at Rated PTO Speeds (540E/1000/1.000E)	1750
Engagement Method	Electric switch with adjustable modulation
Number of Splines	20

Front PTO

PTO Speed	1000
Front PTO Rotation	Counter-clockwise
Engine rpm (at Rated PTO Speeds)	1940 rpm
Front Number of Splines	21

Front Hitch

Front Hitch Category	Category 3N, ground engaging
Lift Capacity Through Full Lift Range at Coupling Points	6740 lb.
Lift Capacity Through Full Lift Range at Coupling Points	3060 kg
Number of Front Selective Control Valves (SCVs)	One with front hitch
Electric Power	Seven-pin connector

Rear Hitch

Rear Hitch Category (SAE Designation)	Standard: Category 3/3N with Quik-Coupler; Optional: Category 3/3N with hook ends
Maximum Lift Capacity Directly at Coupling Points	Standard (Category 3): 5443 kg (12,000 lb); Optional (Category 3N): 6894 kg (15,200 lb); Standard (Category 3 with hook ends): 5443 kg, Optional (Category 3 with hook ends): 6894 kg (15,000 lb)
Sensing Type	Electrohydraulic

Drawbar

Drawbar Category	Category 3; Optional: Category 3 with heavy-duty support; Category 4
Maximum Vertical Load	Standard: Category 3: 1,837 kg (4,050 lb); Optional: Category 3 with heavy-duty support: 4,536 kg (10,000 lb)

Hydraulics

Hydraulic System Type	Closed-center, pressure/flow compensated system with load sensing
Pump Rated Output	Standard: 63 cc: 162 L/min (43 gpm); Optional: 85 cc: 222.3 L/min (59 gpm)
Number of Rear Selective Control Valves (SCVs)	Standard: Four SCVs; Optional: Three to five ISO couplers: 12.7 mm (1/2 in.); Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler)
Available Flow at a Single Rear SCV	35 gpm (132 L/min)
Available Flow at Front SCVs	33 gpm
Available Flow at Front SCVs	126 L/min
SCV Control	Electronic

Front Axle

Front Axle Type	Standard: 1150 Series MFWD: tread range 1524 to 2235 mm (60 to 88 in.); Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h (24.9 mph); TLS with front brakes standard with 50 km/h (31 mph)
Front Axle Differential Lock	1150 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock)

Rear Axle

Rear Axle Type	Standard: Rack-and-pinion or flange axles; Optional: Diameter: 100 x 3010 mm (3.94 x 118.5 in.); Diameter: 100 x 2808 mm (3.94 x 110.5 in.); Diameter: 100 x 2550 mm (3.94 x 100.4 in.); Flanged Axle: 335 mm (13.2 in.)
Rear Differential Lock	Full-locking electrohydraulic
Final Drive	Inboard planetary three pinion

Steering & Brakes

Steering Type

Hydraulic power-steering with electric pump back-up; Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump

Tires

Rear Tires Size

RCI Group 47/48

Electrical System

Battery Voltage	12 V
Battery Cold Cranking Amps	1900 CCA
Battery Capacity	2 x 950 CCA
Alternator Capacity	Standard: 210 amp, Optional: 250 amp
Working Lights	Standard: 18 halogen; Available: 18 light-emitting diode (LED) and two halogen or 22 LED and two halogen
Driving Lights	Standard: 65-W halogen; Available: LED

Operator Station

Seat Suspension	Air seat (Standard), ActiveSeat™ II (Optional)
Degree of Seat Swivel, Left Hand	25 degree (angle)
Degree of Seat Swivel, Right Hand	40 degree (angle)
Cab Suspension	Adjustable cab suspension (Optional)
Instructional Seat	Standard
Primary Display	G5 - 12.8 in. (32.5 cm)
Radio	AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna
Inner Cab Volume	114 cu ft
Inner Cab Volume	3.24 m³
Cab Glass Area	70.61 sq ft
Cab Glass Area	6.56 m²

Technology Integration

Guidance	Integrated AutoTrac™
Connectivity	JDLink™
Remote Diagnostics	ServiceADVISOR™ Remote: available with JDLink hardware and activations; Remote Display Access: available with JDLink hardware and activations

Capacities

Fuel Tank Capacity	122 (e23™), 135 (IVT™) gal.
Fuel Tank Capacity	463 (e23™), 513 (IVT™) L
Diesel Exhaust Fluid (DEF) Tank Capacity	6.9 gal.
Diesel Exhaust Fluid (DEF) Tank Capacity	26.2 L
Cooling System Capacity	10.4 gal.
Cooling System Capacity	39.5 L
Transmission - Hydraulic System	42.3 gal.
Transmission - Hydraulic System	160 L
Crankcase Oil Volume	6.9 gal.
Crankcase Oil Volume	26 L

Dimensions & Weights

Wheelbase	115.2 in.
Wheelbase	2925 mm
Base Machine Weight	23000 lb.
Base Machine Weight	10000 kg
Overall Length	217 in.
Overall Length	5520 mm
Drawbar Ground Clearance	14.2 in.
Drawbar Ground Clearance	360 mm
Maximum Ballast Level	145 lb.
Maximum Ballast Level	65 kg

Additional Information

Country of Manufacture	USA
Date Collected	4/3/2025 12:00:00 AM
