Enjoy a spacious cab that provides all day comfort with ergonomic controls, excellent visibility, and a sealed environment. An optional convertible Category II or IV filtration system protects operators from dust, aerosols, and vapors while maintaining fresh airflow.
Integrated JDLink™ connectivity provides near real-time machine tracking, maintenance alerts, and utilization insights. This connected capability helps operators manage uptime, service planning, and fleet coordination and support across their operation.
The PowrReverser™ transmission enables efficient task handling, like mowing, spraying, and crate moving, with quick directional changes using a left-hand reverser. Users can boost productivity by upgrading from a 12F/12R to a 24F/12R transmission, save fuel with 540E PTO for light tasks, and achieve slow speeds for planting by adding a creeper gear.
Answer text goes here
Engine | |||||||||||||||
| Engine Make | John Deere PowerTech™ 4045 PWS | ||||||||||||||
| Emissions Certifications | Final Tier 4 / Stage 5 | ||||||||||||||
| Aspiration | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged and air-to-air aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged/air-to-air aftercooled | Turbocharged/air-to-air aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged |
| Cylinder Liners | Wet sleeved | ||||||||||||||
| Aftertreatment Type | DOC/DPF/SCR | ||||||||||||||
| Rated Engine Power | 105 hp | ||||||||||||||
| Rated Engine Power | 77 kW | ||||||||||||||
| Rated Engine Power | 105 PS | ||||||||||||||
| Maximum Engine Power | 106 hp | ||||||||||||||
| Maximum Engine Power | 79 kW | ||||||||||||||
| Maximum Engine Power | 107 PS | ||||||||||||||
| Maximum Engine Torque | 350 Nm / 258 lb-ft | ||||||||||||||
Transmission | |||||||||||||||
| Transmission Type | Standard: PowrReverser™ 12F/12R; Optional: PowrReverser™ 24F/12R | SyncShuttle™ 9F/3R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ 24F/12R | Standard: PowrReverser™ 16F/16R Optional: PowrReverser Hi-Lo 32F/16R | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ 24F/12R | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Powr8™ 32F/16R with creeper | OOS: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper |
| Creeper | Optional | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Optional | Not available | Optional | Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper |
| Reverser | Yes | No | SyncShuttle™: No PowrReverser™: Yes | SyncShuttle™: No PowrReverser™: Yes | Yes | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Left hand, electrohydraulic | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Yes |
| Clutch | Wet | Dry | SyncShuttle™: Dry PowrReverser™: Wet | SyncShuttle™: Dry PowrReverser™: Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet |
Rear Power Take-Off (PTO) | |||||||||||||||
| PTO Category | 540/540E | ||||||||||||||
| Engagement Method | Electrohydraulic | ||||||||||||||
Rear Hitch | |||||||||||||||
| Rear Hitch Category (SAE Designation) | Category 2N; convertible to 1 | ||||||||||||||
| Sensing Type | Top link | Top link | Top link | Top link | Top link | Lower link | Top link | Lower link | Lower link | Lower link | Top link | Lower link | Top link | Lower link | Top link |
| Draft Control Sensing | Electrohydraulic | ||||||||||||||
Drawbar | |||||||||||||||
| Maximum Vertical Load | Field use (fully extended): 650 kg / 1433 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Field use (fully extended): 650 kg 1433 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Field use (fully extended): 650 kg 1433 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg |
Hydraulics | |||||||||||||||
| Hydraulic System Type | Open center | Open center | Open Center | Open center | Open center | Open center | Open center | Open center | Open center | Open center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Open center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Open center | Pressure-and-flow compensated (PFC) system |
| Pump Rated Output | 94 L/min / 24.9 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | 66.2 L/min 17.5 gpm | 94 L/min 24.7 gpm | 94 L/min 24.9 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | 94 L/min 24.7 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | 97 L/min 25.6 gpm | 117 L/min 31 gpm |
| Available Flow at a Single Rear SCV | 68.8 L/min / 18.2 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 43.4 L/min 11.5 gpm | 70 L/min 18.4 gpm | 68.8 L/min 18.2 gpm | 70 L/min 18.4 gpm | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | 70 L/min 18.4 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 L/min | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 gpm | 73 L/min 19.3 gpm | 100 L/min 26.4 gpm |
| SCV Control | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic |
Front Axle | |||||||||||||||
| Front Axle Type | Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Standard: Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Standard: Mechanical Front Wheel Drive (MFWD) | Standard: Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) |
Rear Axle | |||||||||||||||
| Rear Axle Type | Flange | Flange | Flange | Flange | Flange | Flange | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Standard: Flange Optional: Rack-and-pinion (Bar) | High-Crop Flange Drop Axle | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange |
| Differential Controls | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Electrohydraulic | Mechanical (pedal) | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic |
| Final Drive | Planetary | Planetary | Planetary | Planetary | Planetary | Inboard planetary | Planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary |
Steering & Brakes | |||||||||||||||
| Primary Brakes | Hydraulic wet disc | ||||||||||||||
Tires | |||||||||||||||
| Front Tires Size | 9.5-16 in. BIAS | ||||||||||||||
| Rear Tires Size | 14.9-24 in. 8PR R1 Bias | ||||||||||||||
Electrical System | |||||||||||||||
| Alternator Capacity | 110 amp | ||||||||||||||
| Working Lights | LED | Halogen | Standard: Halogen Premium Cab: LED | Standard: Halogen Premium Cab: LED | Standard: LED | Standard: Halogen Optional: LED | Standard: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED |
| Driving Lights | LED | ||||||||||||||
Operator Station | |||||||||||||||
| Gearshift Location | Floor, on the side | ||||||||||||||
| Seat Suspension | Air ride; Optional: Mechanical | ||||||||||||||
| Instructional Seat | Not Available | Not Available | Optional | Optional | Not Available | Optional | Not Available | Optional | Optional | Optional | Not Available | Optional | Not Available | Optional | Not Available |
| Primary Display | Simple automotive-style instrument cluster | ||||||||||||||
| Radio | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | |
Technology Integration | |||||||||||||||
| Guidance | Optional: AutoTrac™ Universal Ready | Optional: AutoTrac™ Universal Ready | Optional: AutoTrac™ Universal Ready | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | Optional: AutoTrac™ with AutoTrac Basic | |||||
| Secondary Display | G5 Universal | ||||||||||||||
| Receiver | SF7500 | ||||||||||||||
| Connectivity | JDLink™ Modem | ||||||||||||||
| ISOBUS Ready | No | No | No | No | No | No | No | Optional with PowrQuad™ PLUS/Powr8™ models | Optional with PowrQuad™ PLUS/Powr8™ models | No | Optional for cab models | Optional with PowrQuad™ PLUS/Powr8™ models | Optional for cab models | Optional | Optional for cab models |
Capacities | |||||||||||||||
| Fuel Tank Capacity | 28.53 gal. | ||||||||||||||
| Fuel Tank Capacity | 108 L | ||||||||||||||
Additional Information | |||||||||||||||
| Country of Manufacture | Saltillo, Mexico | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Saltillo, Mexico | Pune, India | Saltillo, Mexico | Pune, India | Pune, India | Pune, India | Saltillo, Mexico | Pune, India | Saltillo, Mexico | Pune, India | Saltillo, Mexico |
