The PowrReverser™ transmission enables efficient task handling, like mowing, spraying, and crate moving, with quick directional changes using a left-hand reverser. Users can boost productivity by upgrading from a 12F/12R to a 24F/12R transmission, save fuel with 540E PTO for light tasks, and achieve slow speeds for planting by adding a creeper gear.
Integrated JDLink™ connectivity provides near real-time machine tracking, maintenance alerts, and utilization insights. This connected capability helps operators manage uptime, service planning, and fleet coordination and support across their operation.
Operate with agility using conveniently placed levers and a rollover protection structure (ROPS) that now requires less force to maneuver. When using mid- or front-mount implements, you can lock the ROPS in place for added stability.
Answer text goes here
Engine | |||||||||||||||||||
| Engine Make | John Deere PowerTech™ 3029 EWR | ||||||||||||||||||
| Emissions Certifications | Final Tier 4 | ||||||||||||||||||
| Aspiration | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Wastegate Turbocharger with intercooler and eventually cooled Exhaust Gas | Turbocharged | Turbocharged and air-to-air aftercooled | Turbocharged | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged/Air-to-Air Aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged | Turbocharged/air-to-air aftercooled | Turbocharged |
| Cylinder Liners | Wet sleeved | ||||||||||||||||||
| Aftertreatment Type | DOC/EGR | ||||||||||||||||||
| Rated Engine Power | 75 hp | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 95.8 kW 130 hp | At 2200 rpm: 99.7 kW 130 hp |
| Rated Engine Power | 55 kW | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 95.8 kW 130 hp | At 2200 rpm: 99.7 kW 130 hp |
| Rated Engine Power | 75 PS | At 2100 rpm: 37.4 kW 50 hp | At 2100 rpm: 45 kW 60 hp | At 2100 rpm: 50.4 kW 67 hp | 56 kW 75 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | At 2200 rpm: 55.1 kW 75 hp | 67.1 kW 90 hp | 67.1 kW 90 hp | At 2200 rpm: 70.0 kW 95 hp | 74.6 kW 100 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 77.4 kW 105 hp | At 2200 rpm: 88.5 kW 120 hp | At 2200 rpm: 92 kW 120 hp | At 2200 rpm: 95.8 kW 130 hp | At 2200 rpm: 99.7 kW 130 hp |
| Maximum Engine Power | 75 hp | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.9 kW 133.9 hp | 99.7 kW 135.5 hp |
| Maximum Engine Power | 55 kW | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.9 kW 133.9 hp | 99.7 kW 135.5 hp |
| Maximum Engine Power | 75 PS | 37.4 kW 50 hp | 45 kW 60 hp | 50.4 kW 67.6 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 54.4 kW 73 hp | 55.1 kW 75 hp | with IPM: 71 kW 97 hp | with IPM: 71 kW 97 hp | 73.0 kW 97.8 hp | with IPM: 77 105 hp | 80.6 kW 108 hp | 80.6 kW 108.0 hp | 80.6 kW 109.5 hp | 92.1 kW 123.5 hp | 92 kW 125 hp | 99.9 kW 133.9 hp | 99.7 kW 135.5 hp |
| Maximum Engine Torque | 250 Nm / 184 lb-ft | ||||||||||||||||||
Transmission | |||||||||||||||||||
| Transmission Type | SyncShuttle™ 9F/3R; Optional: PowrReverser™ 12F/12R | SyncShuttle™ 9F/3R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | Standard: SyncShuttle™ 9F/3R Optional: PowrReverser™ 12F/12R | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser Hi-Lo 32F/16R | 24F/12R PowrReverser, EH Hi-Lo | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | 24F/12R PowrReverser, EH Hi-Lo | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | Standard: PowrReverser™ 16F/16R Optional: PowrReverser™ Hi-Lo 32F/16R PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Powr8™ 32F/16R with creeper | OOS: Standard: PowrReverser™ 16F/16R Optional: PowrQuad™ PLUS 16F/16R Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper | Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Powr8™ 32F/16R with creeper | OOS: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper |
| Creeper | Kit available for SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Kit available for OOS SyncShuttle™ 9F/3R transmission | Yes | Yes | Yes | Not available | Yes | Yes | Powr8™ 32F/16R with creeper | Yes | Powr8™ 32F/16R with creeper | PowrReverser™ 16F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper | Powr8™ 32F/16R with creeper | Cab: Powr8™ 32F/16R with creeper |
| Reverser | SyncShuttle™: No; PowrReverser™: Yes | No | SyncShuttle™: No PowrReverser™: Yes | SyncShuttle™: No PowrReverser™: Yes | Yes | Yes | Yes | Left hand, electrohydraulic | Yes | Yes | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Yes | Left hand, electrohydraulic | Yes |
| Clutch | SyncShuttle™: Dry; PowrReverser™: Wet | Dry | SyncShuttle™: Dry PowrReverser™: Wet | SyncShuttle™: Dry PowrReverser™: Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet | Wet |
Rear Power Take-Off (PTO) | |||||||||||||||||||
| PTO Category | SyncShuttle™: Independent 540; PowrReverser™: Independent 540/540E | ||||||||||||||||||
| Engagement Method | SyncShuttle™: Mechanical (lever); PowrReverser™: Electrohydraulic | ||||||||||||||||||
Rear Hitch | |||||||||||||||||||
| Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 1/Category 2 | Category 1/Category 2 | Category 1/Category 1N | Category 2; convertible to 1 | Category 1/Category 2 | Category 1/Category 1N | Category 2; convertible to 1 | Category 1/Category 2 | Category 2; convertible to 1 | Category 2; convertible to 1 | Category 2 | Category 2; convertible to 1 | Category 2 | Category 2; convertible to 1 | Category 2 |
| Sensing Type | Top link | Top link | Top link | Top link | Top Link Draft Sensing | Top Link Draft Sensing | Top Link Draft Sensing | Lower link | Top Link Draft Sensing | Top Link Draft Sensing | Lower link | Top Link Draft Sensing | Lower link | Lower Link | Top link | Lower link | Top link | Lower link | Top link |
| Draft Control Sensing | Mechanical | ||||||||||||||||||
Drawbar | |||||||||||||||||||
| Maximum Vertical Load | Road/field use (short position): 1120 kg (2470 lb); Field use (fully extended): 760 kg (1675 lb) | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg | ||||||
Hydraulics | |||||||||||||||||||
| Hydraulic System Type | Open Center | Open center | Open Center | Open center | Open Center | Open Center | Open Center | Open center | Open Center | Open Center | Open center | Open Center | Open center | Open Center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Open center | OOS: Standard: Open center Optional: Pressure-and-flow compensated (PFC) system Cab: Pressure-and-flow compensated (PFC) system | Open center | Pressure-and-flow compensated (PFC) system |
| Pump Rated Output | 68.8 L/min (18.2 gpm) | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | 68.8 L/min 18.2 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | 94 L/min 24.7 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | 94 L/min 24.7 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | PowrReverser™: 94 L/min 24.7 gpm PowrQuad™ PLUS/Powr8™: 97 L/min 25.6 gpm | OOS: Standard: 94 L/min 24.7 gpm Optional: 117 L/min 31 gpm Cab: 117 L/min 31 gpm | 97 L/min 25.6 gpm | 117 L/min 31 gpm |
| Available Flow at a Single Rear SCV | 43.1 L/min (11.4 gpm) | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 43.1 L/min 11.4 gpm | 41.6 L/min 11 gpm | 66.2 L/min 17.6 gpm | 41.6 L/min 11 gpm | 70 L/min 18.4 gpm | 41.6 L/min 11 gpm | 41.6 L/min 11 gpm | 70 L/min 18.4 gpm | 41.6 L/min 11 gpm | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | 70 L/min 18.4 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 L/min | PowrReverser™: 70 L/min 18.4 gpm PowrQuad™ PLUS/Powr8™: 73 L/min 19.3 gpm | OOS: Standard: 70 L/min 18.4 gpm Optional: 100 L/min 26.4 gpm Cab: 100 L/min 26.4 gpm | 73 L/min 19.3 gpm | 100 L/min 26.4 gpm |
| SCV Control | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic | Mechanical | OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic |
Front Axle | |||||||||||||||||||
| Front Axle Type | Two-Wheel Drive (2WD); Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Standard: Two-Wheel Drive (2WD) Optional: Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Carraro Drivetech | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) | Carraro Drivetech | Standard: Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) | Mechanical Front Wheel Drive (MFWD) |
Rear Axle | |||||||||||||||||||
| Rear Axle Type | Flange | Flange | Flange | Flange | Carraro Drivetech | Carraro Drivetech | Carraro Drivetech | Flange | Carraro Drivetech | Carraro Drivetech | Standard: Flange Optional: Rack-and-pinion (Bar) | Carraro Drivetech | Standard: Flange Optional: Rack-and-pinion (Bar) | High-Crop Flange Drop Axle | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange | Standard: Flange Optional: Rack-and-pinion (Bar) | Flange |
| Differential Controls | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Mechanical (pedal) | Multi disk oil cooled design | Multi disk oil cooled design | Multi disk oil cooled design | Electrohydraulic | Multi disk oil cooled design | Multi disk oil cooled design | Electrohydraulic | Multi disk oil cooled design | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic | Electrohydraulic |
| Final Drive | Planetary | Planetary | Planetary | Planetary | Three point inboard planetary drives | Three point inboard planetary drives | Three point inboard planetary drives | Inboard planetary | Three point inboard planetary drives | Three point inboard planetary drives | Inboard planetary | Three point inboard planetary drives | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary | Inboard planetary |
Steering & Brakes | |||||||||||||||||||
| Primary Brakes | Hydraulic wet disc | ||||||||||||||||||
Tires | |||||||||||||||||||
| Rear Tires Size | 14.9-28 R1 Bias | ||||||||||||||||||
Electrical System | |||||||||||||||||||
| Alternator Capacity | 70 amp | ||||||||||||||||||
| Working Lights | Halogen | Halogen | Standard: Halogen Premium Cab: LED | Standard: Halogen Premium Cab: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED | Standard: Halogen Optional: LED |
| Driving Lights | Halogen | ||||||||||||||||||
Operator Station | |||||||||||||||||||
| ROPS Type | Foldable, 2-post | ||||||||||||||||||
| Gearshift Location | Floor, on the side | ||||||||||||||||||
| Seat Suspension | Mechanical | ||||||||||||||||||
| Instructional Seat | Optional | Not Available | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Not Available | Optional | Not Available | ||||||
| Primary Display | Simple automotive-style instrument cluster | ||||||||||||||||||
| Radio | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | |||||||
Technology Integration | |||||||||||||||||||
| ISOBUS Ready | No | No | No | No | No | No | No | No | No | No | Optional with PowrQuad™ PLUS/Powr8™ models | No | Optional with PowrQuad™ PLUS/Powr8™ models | No | Optional for cab models | Optional with PowrQuad™ PLUS/Powr8™ models | Optional for cab models | Optional | Optional for cab models |
Capacities | |||||||||||||||||||
| Fuel Tank Capacity | 19 gal. | ||||||||||||||||||
| Fuel Tank Capacity | 72.5 L | ||||||||||||||||||
Additional Information | |||||||||||||||||||
| Country of Manufacture | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Sub assembly in Pune, India, Final assembly in Augusta, GA | Rovigo, Italy | Rovigo, Italy | Rovigo, Italy | Pune, India | Rovigo, Italy | Rovigo, Italy | Pune, India | Rovigo, Italy | Pune, India | Pune, India | Saltillo, Mexico | Pune, India | Saltillo, Mexico | Pune, India | Saltillo, Mexico |
| Date Collected | 2023-Jan-06 | 6-Jan-2023 | 6-Jan-2023 | 31-May-2022 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 | 6-Jan-2023 |
