John Deere
2010DE
Scrapers

John Deere 2010DE

Starting at

Adjustable Cast Router Bits

Cast router bits offer a lifespan 25% greater than previous models with wear indicators and embedded numbers, based on test data, and customer validation. The double-hole design allows for extended use by simply lowering the bit for continued operation. One cast-router bit can be used on both scraper sides.

Close-up of a yellow metal machine component with bolts and reinforced edges, showing embossed markings on the side surface
High-Strength Standard Blades

Crafted from high-carbon steel, these 406-mm long blades effectively cut through stubborn soils. They feature a unique double-edge design, doubling blade life when rotated. Available in three widths, they optimize precision leveling and penetration in compacted soils.

Computer-generated graphic of three rectangular orange blades with bolt holes in spaced intervals and 6, 12, 18, and 16-in. measurements labeled on two sides
Comprehensive Tire Options

The scraper offers substantial tire options, including the two-tire model with premium rock-lug radial tires. These provide exceptional load-bearing capacity and durability, enhancing flotation in heavy conditions. Various configurations are available to optimize performance in differing ground conditions.

Rear view of a yellow ejector scraper with two large treaded tires, a central control panel, and a red triangular slow‑moving‑vehicle emblem
Question text goes here

Answer text goes here

Capacity
Struck Capacity

13.6 cu yd

Struck Capacity

10.4 m³

Heaped Capacity

20 cu yd

Heaped Capacity

15.3 m³

Dimensions
Bowl Length

9.17 ft

Bowl Length

2.79 m

Bowl Width

10.5 ft

Bowl Width

3.2 m

Overall Height

7.58 ft

Overall Height

2.31 m

Weight
Approximate Shipping Weight

23100 lb.

Approximate Shipping Weight

10480 kg

Scraper Weight Distribution
Tongue

25 %

Wheels

75 %

Tires
Number Of Tires Per Scraper

4

Tire Size - Standard

20.5 X 25

Tire Size - Option 1

20.5 X 25 Premium Radial

Horsepower Recommendations
Minimum Horsepower

360 hp

Minimum Horsepower

268.5 kW

Maximum Horsepower

575+ hp

Maximum Horsepower

428.9+ kW

Blades and Router
Two Rows Of Blade Bolts

Standard

6-in. Bolt-Hole Spacing

Standard

Straight Blade Configuration

Standard

Drop Center Configuration

Optional

Teeth Configuration

Optional

Adjustable Router Bits

Standard

Hydraulics
Size Of Lines And Hoses

0.75 in.

Size Of Lines And Hoses

1.91 cm

Tandem Lines

Standard

Minimum Flow Required

25 gpm

Minimum Flow Required

94.6 L/min

Minimum Pressure Required

2900 psi

Minimum Pressure Required

199.9 bar

Precision Leveling
GPS/Laser Adaptable

Yes

Loading Type
Direct Loading

Yes

Top Loading

Yes

Push Loading

Yes

Autoload

Yes

Hitches and Drawbars
Hitch Type

Yoke

Special Tractor Drawbar Required

Yes

Warranty
Full Warranty

Standard (1 year)

Extended Warranty

No longer available

Additional Equipment
Yoke-Type Drawbars

Optional

Quick-Attach Drawbars

Optional

Drawbar Hitch Adapters

Optional

Scraper-To-Scraper Quick-Attach

Optional

Rear Bumper

Optional

Laser Receiver Bracket

Optional

High-Speed Leveling Skid Pads

Yes
