John Deere
TC MACHINE PRECISION UPGRADES
Mounted Planters

John Deere MP516

Starting at

Uniform Placement, Built Into the Tool

With features like dual knife openers and engineered placement consistency, John Deere air drills help keep seed and fertilizer placement steady across the machine—so your crop starts more evenly and you can feel good about what you put in the ground, acre after acre.

Agricultural tractor pulling a large green tillage implement across a harvested field of dry corn stubble under a cloudy sky, with flat farmland stretching to the horizon
Place Seed and Fertilizer With Confidence, Not Hope

Air drilling is about repeatability. John Deere air drills are built for consistent placement and the kind of even start you can see at emergence—helping protect yield potential when timing is tight and you need every pass to count the first time.

Large green agricultural tractor pulling a wide tillage implement across a harvested field of golden corn stubble, with long parallel rows stretching into the distance under a dramatic, overcast sky
Know It’s Flowing - So You Can Keep Rolling

You shouldn’t have to stop to wonder if product is making it to the ground. RelativeFlow™ blockage monitoring helps you spot problems from the cab and address them early—so you avoid thin streaks, protect the stand, and keep momentum when the window is short.

Tractor with dual tracks pulling a large green air seeder and planter across a wide, flat field of evenly spaced crop rows, viewed from above under a clear sky with a distant horizon.
Question text goes here

Answer text goes here

Rows and Row Spacing
Number Of Rows

16

Row Spacing

30 in.

Row Spacing

76.2 cm

Frame
Frame Fold Configuration

Vertical fold

Frame Flexibility - Up

10 degree (angle)

Frame Flexibility - Down

7 degree (angle)

Lift System
Type

Semi-integral only

Tires
Base

12.5L-15SL 20 ply implement: 303 kPa 3.0 bar 44 psi; 7.60-15 8 ply implement: 359 kPa 3.6 bar 52 psi; 7.6-15 6 ply - traction: 276 kPa 2.8 bar 40 psi

Row Units
Type

ExactEmerge™ row units

Opener

Tru-Vee Double Disk

Row Unit Seed Hoppers

Not available

Row Unit Down Force

Individual Row Hydraulic Downforce (IRHD)

Seed Meters
Base Seed Meter

Vacuum

Central Commodity System (CCS)

Yes

CCS Seed Capacity

55 bu

CCS Seed Capacity

1938 L

Drive System
Base

Electric drive: 56 V

Seed Monitor System
Base

SeedStar™ 5

Dimensions
Transport Width (Without Markers)

17.92-22.17 ft

Transport Width (Without Markers)

5.5-6.8 m

Transport Height

5.17-13.17 ft

Transport Height

1.6-4.01 m

Transport Underframe Clearance

13.2 ft

Transport Underframe Clearance

4 m

Additional Information
Recommended Tractor Horsepower

8030, 8R, 8RX, 8030T and 8RT Series Tractor (power take-off [PTO] power of 216 kW [290 hp] or more); 3-point lift capacity of greater than 7300 kg (16,100 lb) minimum; Three or four selective control valves (SCVs) for power beyond, load sense, and case drain hydraulic connections are required, depending on machine options; SCV 1 – wing downforce/gull wing (when equipped), SCV 2 – fold/unfold, SCV 3 – CCS, SCV 4 – vacuum; Power beyond – Individual Row Hydraulic Downforce (IRHD), ExactRate™ fertilizer, or PDF compressor with load sense; Load sense – IRHD, ExactRate fertilizer, or PDF compressor with load sense; Case drain – vacuum or PDF compressor with load sense; Independent-Link Suspension (ILS™) or 1500 mechanical front-wheel drive (MFWD) tractor front axle required; Rear duals and full set of front weight

Recommended Tractor Hydraulics

Hydraulic oil required to operate the planter: 227 L/min (60 gpm); Hydraulic system standby pressure: 15,513 kPa (155 bar) (2250 psi); Hydraulic system working pressure: 20,684 kPa (207 bar) (3000 psi); Hydraulic system burst pressure: 82,737 kPa (827 bar) (12,000 psi)
