Rows and Row Spacing |
| Number Of Rows | 47 | |
| Row Spacing | 15 in. | |
| Row Spacing | 38.1 cm | |
Frame |
| Frame Fold Configuration | 3-section front-fold | |
| Frame Tube Size | 7x7 in. | |
| Frame Tube Size | 17.8x17.8 cm | |
| Fold-And-Go From Tractor | Base | |
| Frame Flexibility - Up | 15 degree (angle) | |
| Frame Flexibility - Down | 15 degree (angle) | |
Hitch |
| Base | Drawbar | |
Lift System |
| Type | Electrohydraulic series rephasing cylinders with center sec. drop axle | |
| Number Of Cylinders | 5 | |
Tires |
| Base | (4) 16.5x16.1, (4) 31-13.5x15 | |
| Quantity | 8 | |
Row Units |
| Type | ExactEmerge™ row units or MaxEmerge™ 5e row units or MaxEmerge™ 5 row units | |
| Depth Gauging | (2) semi-pneumatic wheels: 11.4x40.6 cm 4.5x16 in. | |
| Adjustment | T-handle depth: 0.635-10.2 cm 0.25-4 in. with increments of 0.635 cm 0.25 in. | |
| Walking Wheels | Optional | |
| Row Unit Seed Hoppers | Mini hoppers | |
| Seed Hopper Capacity | 0.063 bu | |
| Seed Hopper Capacity | 2.24 L | |
| Seed Hopper Material | Plastic | |
| Row Unit Down Force | Base equipment | |
| Pneumatic Down Force | Base, Infinitely adjustable to 181.4 kg 400 lb | |
| Scrapers, Opener Blade | Optional | |
| Plastic Rotary Opener Blades | Optional | |
| Steel Straight Opener Blades | Optional | |
| Heavy-Duty Opener Blades | Optional | |
| Seed Tube Sensors | Base equipment | |
Seed Meters |
| Base Seed Meter | Vacuum | |
| Central Commodity System (CCS) | Base equipment | |
| CCS Seed Capacity | 130 bu | |
| CCS Seed Capacity | 4581 L | |
Drive System |
| Base | Three-motor hydraulic variable rate drive | |
| Counter Shaft | Hex: 2.22 cm 0.875 in. | |
| Drill Shaft | Hex: 2.22 cm 0.875 in. | |
| Transmission Combinations | Infinite | |
Markers |
| Type | 3-section front-fold | |
| Control | Base: Independent | |
| Marker Disk | Base: Notched with depth gauging band: 40.6 cm 16 in. | |
| Less Marker Option | Optional | |
Closing System |
| Rubber Tire Closing System | Base equipment | |
| Rubber Tire Closing System - Wheel | (2) rubber tires with nylon wheels: 2.54x30.5 cm 1x12 in. | |
| Rubber Tire Closing System - Position | In-line or staggered | |
| Rubber Tire Closing System - Adjustment | T-handle | |
| Rubber Tire Closing System - Down Force | 5-position | |
| Rubber Tire Closing System - Alignment | Adjustable | |
| Cast Iron Closing System | Optional | |
| Cast Iron Closing System - Wheel | (2) cast iron wheels: 2.54x30.5 cm 1x12 in. | |
| Cast Iron Closing System - Position | In-line or staggered | |
| Cast Iron Closing System - Adjustment | T-handle | |
Liquid Insecticide System |
| Tank Capacity | 420 gal. | |
| Tank Capacity | 1590 L | |
Seed Monitor System |
| Base | SeedStar™ electronic system | |
Tillage Attachments |
| Unit-Mounted Coulter | Optional | |
Dimensions |
| Transport Width (With Markers) | 17.5 ft | |
| Transport Width (With Markers) | 5.4 m | |
| Transport Length | 41 ft | |
| Transport Length | 12.5 m | |
| Transport Height | 10 ft | |
| Transport Height | 3 m | |
| Transport Weight | 29800 lb. | |
| Transport Weight | 13517 kg | |
| Transport Underframe Clearance | 22 ft | |
| Transport Underframe Clearance | 55.9 m | |
Ag Management Solutions |
| Map-Based Seeding | Yes | |
| Field Documentation | Yes | |
| Parallel Tracking | Yes | |
Additional Information |
| Warranty Length | 1 year | |
