Every pound counts. Precision metering, section control, and curve compensation help reduce skips, overlap, and guesswork - so you can trust what you’re placing, protect your investment, and feel confident you didn’t miss acres when the day gets long and the field gets awkward.
Some operations measure success in acres per day, not stops per hour. The C‑Series lineup now expands to the new XL carts - C1100T and C1450T - built for long run time and high productivity when your window is tight and your acres are anything but small.
When the weather finally breaks, you don’t want to spend it refilling. John Deere air carts are built to keep the drill moving with more acres per fill and better visibility to what’s left - so you can push through the good conditions, not waste them waiting on the tender truck.
Answer text goes here
Cart Capacity | |||||||||||
| Total | 550 bu | 12,333.68 L 350 bu | 12,333.68 L 350 bu | 14,095.63 L 400 bu | 14,095.63 L 400 bu | 17,619.5 L 500 bu | 17,619.5 L 500 bu | 19,381.5 L 550 bu | 22,905.4 L 650 bu | 22,905.4 L 650 bu | 22,953.21 L 850 bu |
| Total | 19381.5 L | 12,333.68 L 350 bu | 12,333.68 L 350 bu | 14,095.63 L 400 bu | 14,095.63 L 400 bu | 17,619.5 L 500 bu | 17,619.5 L 500 bu | 19,381.5 L 550 bu | 22,905.4 L 650 bu | 22,905.4 L 650 bu | 22,953.21 L 850 bu |
| Number of Tanks | 4 | Two | Two | Three | Three | Three | Three | Four | Four | Four | Four |
| Tank Splits | 50, 90, 190, 220 bu | 5638.25 L 160 bu 6695.4 L 190 bu | 5638.25 L 160 bu 6695.4 L 190 bu | 1762 L 50 bu 5638.25 L 160 bu 6695.4 L 190 bu | 1762 L 50 bu 5638.25 L 160 bu 6695.4 L 190 bu | 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 1762 L 50 bu 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 1762 L 50 bu 4581.1 L 130 bu 7400.2 L 210 bu 9162.2 L 260 bu | 1762 L 50 bu 4581.1 L 130 bu 7400.2 L 210 bu 9162.2 L 260 bu | 1762 L 50 bu 4581.1 L 130 bu 9162.2 L 260 bu 14,448 L 410 bu |
| Tank Splits | 1762, 3171.5, 6695.4, 7752.6 L | 5638.25 L 160 bu 6695.4 L 190 bu | 5638.25 L 160 bu 6695.4 L 190 bu | 1762 L 50 bu 5638.25 L 160 bu 6695.4 L 190 bu | 1762 L 50 bu 5638.25 L 160 bu 6695.4 L 190 bu | 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 1762 L 50 bu 3171.5 L 90 bu 6695.4 L 190 bu 7752.6 L 220 bu | 1762 L 50 bu 4581.1 L 130 bu 7400.2 L 210 bu 9162.2 L 260 bu | 1762 L 50 bu 4581.1 L 130 bu 7400.2 L 210 bu 9162.2 L 260 bu | 1762 L 50 bu 4581.1 L 130 bu 9162.2 L 260 bu 14,448 L 410 bu |
| Liquid Capable Middle Tank | 982.7 gal. | 3720 L 982.7 gal. | 3720 L 982.7 gal. | 3720 L 982.7 gal. | 4800 L 1268 gal. | 4800 L 1268 gal. | |||||
| Liquid Capable Middle Tank | 3720 L | 3720 L 982.7 gal. | 3720 L 982.7 gal. | 3720 L 982.7 gal. | 4800 L 1268 gal. | 4800 L 1268 gal. | |||||
Conveyance | |||||||||||
| Conveyor Belt Width | 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 48.3 cm 19 in. | 48.3 cm 19 in. | 40.6 cm 16 in. |
| Conveyor Belt Width | 40.6 cm | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 40.6 cm 16 in. | 48.3 cm 19 in. | 48.3 cm 19 in. | 40.6 cm 16 in. |
| Conveyor Tube Diameter | 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 30.5 cm 12 in. | 30.5 cm 12 in. | 30.5 cm 12 in. |
| Conveyor Tube Diameter | 25.4 cm | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 30.5 cm 12 in. | 30.5 cm 12 in. | 30.5 cm 12 in. |
| Conveyor Capacity (Wheat) | 66 buMin | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 3523.9 L/min 100 bu/min | 3523.9 L/min 100 bu/min | 3523.9 L/min 100 bu/min |
| Conveyor Capacity (Wheat) | 2325.8 L/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 2325.8 L/min 66 bu/min | 3523.9 L/min 100 bu/min | 3523.9 L/min 100 bu/min | 3523.9 L/min 100 bu/min |
| Auger Diameter | 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | |||
| Auger Diameter | 25.4 cm | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | 25.4 cm 10 in. | |||
| Auger Capacity (Wheat) | 49 buMin | 1726.7 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.7 L/min 49 bu/min | 1726.7 L/min 49 bu/min | 1726.7 L/min 49 bu/min | |||
| Auger Capacity (Wheat) | 1726.7 L/min | 1726.7 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.72 L/min 49 bu/min | 1726.7 L/min 49 bu/min | 1726.7 L/min 49 bu/min | 1726.7 L/min 49 bu/min | |||
Air System | |||||||||||
| Blower Options | Standard capacity or high capacity | Standard capacity | Standard capacity | Standard capacity | Standard capacity | Standard capacity or high capacity | Standard capacity or high capacity | Standard capacity or high capacity | Standard capacity or high capacity | Standard capacity or high capacity | High capacity |
| Number of Blowers | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual | Single or dual |
| Max Meter Delivery Rate per Blower - High Capacity Blower | 410 lb/acre | ||||||||||
| Max Meter Delivery Rate per Blower - High Capacity Blower | 459.55 kgPerHa | ||||||||||
| Max Meter Delivery Rate Per Blower - Standard Capacity Blower | 345 lb/acre | ||||||||||
| Max Meter Delivery Rate per Blower - Standard Capacity Blower | 386.7 kgPerHa | ||||||||||
| Drive | Hydraulic, per blower: up to 98.4 L/min (26 gpm) | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm | Hydraulic, per blower: up to 98.4 L/min 26 gpm |
| Product Delivery Hoses | 2.5 or 3 in. in. | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 7.6 cm 3 in. |
| Product Delivery Hoses | 6.35 or 7.6 cm cm | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 cm 2.5 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 6.35 or 7.6 cm 2.5 or 3 in. | 7.6 cm 3 in. |
Metering | |||||||||||
| Number of Meters | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 6 or 8 per tank | 8 per tank |
| Meter Housing Material | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
| Type | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary | Individual motor control per primary |
| Metering Drive | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V | Electric: 56 V |
Brakes | |||||||||||
| Brake Type | Optional: hydraulic disc | ||||||||||
Dimensions | |||||||||||
| Height (Transport) | 13.17 ft | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. |
| Height (Transport) | 4 m | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. |
| Height (Field) | 13.75 ft | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. |
| Height (Field) | 4.2 m | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4 m 13 ft 2 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. | 4.05 m 13 ft 4 in. |
| Length Overall | 28.58 ft | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.68 m 31 ft 9 in. | 8.72 m 28 ft 7 in. | 9.68 m 31 ft 9 in. | 12 m 39 ft 5 in. | 11.86 m 38 ft 11 in. | 13.58 m 44 ft 7 in. |
| Length Overall | 8.72 m | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.68 m 31 ft 9 in. | 8.72 m 28 ft 7 in. | 9.68 m 31 ft 9 in. | 12 m 39 ft 5 in. | 11.86 m 38 ft 11 in. | 13.58 m 44 ft 7 in. |
| Length (Hitch Pin to Axle) | 21.17 ft | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.68 m 31 ft 9 in. | 8.72 m 28 ft 7 in. | 9.68 m 31 ft 9 in. | 12 m 39 ft 5 in. | 11.86 m 38 ft 11 in. | 13.58 m 44 ft 7 in. |
| Length (Hitch Pin to Axle) | 6.45 m | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.47 m 31 ft 1 in. | 8.27 m 27 ft 1 in. | 9.68 m 31 ft 9 in. | 8.72 m 28 ft 7 in. | 9.68 m 31 ft 9 in. | 12 m 39 ft 5 in. | 11.86 m 38 ft 11 in. | 13.58 m 44 ft 7 in. |
| Width With Base Equipment Tires | 17.5 ft | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 6.16 m 20 ft 2 in. | 5.38 m 17 ft 8 in. | 6.16 m 20 ft 2 in. |
| Width With Base Equipment Tires | 5.34 m | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 6.16 m 20 ft 2 in. | 5.38 m 17 ft 8 in. | 6.16 m 20 ft 2 in. |
| Width With High Flotation Tires | 18.83 ft | ||||||||||
| Width With High Flotation Tires | 5.75 m | ||||||||||
| Width With 3M Tire Option | 12.83 ft | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.9 m 12 ft 10 in. | 3.9 m 12 ft 10 in. | 3.9 m 12 ft 10 in. | 3.72 m 12 ft 3 in. | ||
| Width With 3M Tire Option | 3.9 m | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.75 m 12 ft 4 in. | 3.9 m 12 ft 10 in. | 3.9 m 12 ft 10 in. | 3.9 m 12 ft 10 in. | 3.72 m 12 ft 3 in. | ||
| Ground Clearance (Empty) | 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 58.4 cm 23 in. | Empty: 58.4 cm 23 in. | Empty: 58.4 cm 23 in. |
| Ground Clearance (Empty) | 68.8 cm | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 68.8 cm 27 in. | Empty: 58.4 cm 23 in. | Empty: 58.4 cm 23 in. | Empty: 58.4 cm 23 in. |
Shipping Weight | |||||||||||
| Base Equipment | 24178 lb. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 6.16 m 20 ft 2 in. | 5.38 m 17 ft 8 in. | 6.16 m 20 ft 2 in. |
| Base Equipment | 10967 kg | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 4.2 m 13 ft 9 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 5.34 m 17 ft 6 in. | 6.16 m 20 ft 2 in. | 5.38 m 17 ft 8 in. | 6.16 m 20 ft 2 in. |
| Shipping Weight - High Flotation Option | 26793 lb. | 7397 kg 16,308 lb | 9066 kg 19,987 lb | 7924 kg 17,469 lb | 9593 kg 21,149 lb | 9760 kg 21,516 lb | 11,465 kg 25,276 lb | 10,447 kg 23,031 lb | 14,932 kg 31,176 lb | 16,594 kg 34,839 lb | 16,937 kg 37,340 lb |
| Shipping Weight - High Flotation Option | 12115 kg | 7397 kg 16,308 lb | 9066 kg 19,987 lb | 7924 kg 17,469 lb | 9593 kg 21,149 lb | 9760 kg 21,516 lb | 11,465 kg 25,276 lb | 10,447 kg 23,031 lb | 14,932 kg 31,176 lb | 16,594 kg 34,839 lb | 16,937 kg 37,340 lb |
| 3M Wheel Tread Option | 22382 lb. | 6137 kg 13,530 lb | 7217 kg 15,911 lb | 6664 kg 14,692 lb | 7774 kg 17,073 lb | 8348 kg 18,403 lb | 9464 kg 20,865 lb | 9035 kg 19,918 lb | 13,017 kg 27,404 lb | ||
| 3M Wheel Tread Option | 10152 kg | 6137 kg 13,530 lb | 7217 kg 15,911 lb | 6664 kg 14,692 lb | 7774 kg 17,073 lb | 8348 kg 18,403 lb | 9464 kg 20,865 lb | 9035 kg 19,918 lb | 13,017 kg 27,404 lb | ||
Tires | |||||||||||
| Front Tires- Base Equipment | 21.5L-16.1 I-3T 8PR (Duals) | ||||||||||
| Front Tires- High Flotation Option | 650/50R22.5 885 I-3 163D (Duals) | ||||||||||
| Front Tires- 3M Wheel Tread Option | 650/50R22.5 885 I-3 163D (Singles) | ||||||||||
| Rear Tires- Base Equipment | 650/85R38 173B R-1W FS (Duals) | ||||||||||
| Rear Tires- High Flotation Option | 800/70R38 (Duals) | ||||||||||
| Rear Tires- 3M Wheel Tread Option | VF900/60R38 193A8 R1W CFO (Singles) | ||||||||||
Additional Information | |||||||||||
| Date Collected | 2024-02-28 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 | 28-Feb-2024 |
