A heavy-duty driveline with overrunning clutch is standard equipment. All mowers are equipped with a shielded, pullback-collar, telescoping power take-off (PTO) driveline.

The mower's cutterbar is safeguarded against severe impacts. Should an obstacle be hit, the drive shaft shears, protecting internal components. Disc quills, which can be easily removed, improve serviceability and reduce maintenance costs with each featuring two replaceable knives.

A heavy-duty cutterbar efficiently handles tough cutting conditions. Its rotary discs operate on a fully enclosed multi-V-belt drive system, promoting smooth and reliable operation while enhancing belt life with automatic tensioning.

Answer text goes here
Mower | |||||||
| Number Of Disks | 8 | 4 | 8 | 8 | 8 | 8 | 8 |
| Number Of Knives | 16 | 16 | 24 | 16 | 16 | 16 | 16 |
| Width Of Cut | 10.17 ft | 3.2 m 10, 6 ft, in. | 3.2 m 10, 5 ft, in. | 3.14 m 10, 4 ft, in. | 3.15 m 10, 4 ft, in. | 3.46 m 11, 4 ft, in. | 3.2 m 10, 6 ft, in. |
| Width Of Cut | 3.11 m | 3.2 m 10, 6 ft, in. | 3.2 m 10, 5 ft, in. | 3.14 m 10, 4 ft, in. | 3.15 m 10, 4 ft, in. | 3.46 m 11, 4 ft, in. | 3.2 m 10, 6 ft, in. |
| Weight | 1570 lb. | 683 kg 1503 lb | 645 kg 1422 lb | 684 kg 1510 lb | 1186 kg 2610 lb | 695 kg 1532 lb | 626 kg 1380 lb |
| Weight | 712 kg | 683 kg 1503 lb | 645 kg 1422 lb | 684 kg 1510 lb | 1186 kg 2610 lb | 695 kg 1532 lb | 626 kg 1380 lb |
| Disk Speed | 2986 rpm | 3000 rpm | 2835 rpm | 2850 rpm | |||
| Cutting Arc | +35 to -30 degree (angle) | -35 to +35 degree (angle) | 0-6 | +18 to -28 degree (angle) | |||
| Lift System | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic |
| Minimum PTO Power | 55 hp | ||||||
| Minimum PTO Power | 41 kW | ||||||
| PTO Speed | 540 rpm | 540 | 540 | 540 | 540 | 1000 | 540 |
