A heavy-duty driveline with overrunning clutch is standard equipment. All mowers are equipped with a shielded, pullback-collar, telescoping power take-off (PTO) driveline.

The mower's cutterbar is safeguarded against severe impacts. Should an obstacle be hit, the drive shaft shears, protecting internal components. Disc quills, which can be easily removed, improve serviceability and reduce maintenance costs with each featuring two replaceable knives.

A heavy-duty cutterbar efficiently handles tough cutting conditions. Its rotary discs operate on a fully enclosed multi-V-belt drive system, promoting smooth and reliable operation while enhancing belt life with automatic tensioning.

Answer text goes here
Mower | |||||||||
| Number Of Disks | 6 | 6 | 6 | 4 | 6 | 6 | 6 | 6 | 6 |
| Number Of Knives | 12 | 12 | 12 | 8 | 18 | 12 | 12 | 12 | |
| Width Of Cut | 7.92 ft | 2.4 m 7, 10 ft, in. | 2.41 m 7, 11 ft, in. | 2.4 m 7, 11 ft, in. | 2.4 m 7, 9 ft, in. | 2.42 m 7, 11 ft, in. | 3 m 9, 10 ft, in. | 2.62 m 8, 7 ft, in. | 2.4 m 7.8 ft |
| Width Of Cut | 2.4 m | 2.4 m 7, 10 ft, in. | 2.41 m 7, 11 ft, in. | 2.4 m 7, 11 ft, in. | 2.4 m 7, 9 ft, in. | 2.42 m 7, 11 ft, in. | 3 m 9, 10 ft, in. | 2.62 m 8, 7 ft, in. | 2.4 m 7.8 ft |
| Weight | 1350 lb. | 662 kg 1460 lb | 489 kg 1077 lb | 520 kg 1146 lb | 450 kg 992 lb | 436 kg 963 lb | 724 kg 1596 lb | 585 kg 1290 lb | |
| Weight | 612 kg | 662 kg 1460 lb | 489 kg 1077 lb | 520 kg 1146 lb | 450 kg 992 lb | 436 kg 963 lb | 724 kg 1596 lb | 585 kg 1290 lb | |
| Disk Speed | 2986 rpm | 3000 rpm | 3154 rpm | 3000 rpm | 3000 rpm | ||||
| Cutting Arc | +35 to -25 degree (angle) | +18 to -32 degree (angle) | +18 to -30 degree (angle) | -45 to +45 degree (angle) | |||||
| Lift System | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | Hydraulic | |
| Minimum PTO Power | 45 hp | ||||||||
| Minimum PTO Power | 34 kW | ||||||||
| PTO Speed | 540 rpm | 540 | 540 | 540 | 540 | 540 | 540 | 540 | |
