Studio image with a front view of a BP15 Belt Pickup Platform Header Grain Harvesting
No items found.
new
John Deere
BP 15
Belt Pickup

John Deere BP15

Starting at

Helping You Harvest with Confidence

Changing harvest conditions can be overwhelming. John Deere automation takes the pressure off by optimizing combine settings, guiding precise turns, and managing unloads on the go—protecting yield, reducing grain loss, delivering clean samples, and keeping you focused on feeding the machine, and less on adjusting, steering, or unloading.

Close-up image of a tractor decal
Make Every Minute of the Harvest Window Count

John Deere delivers harvesting solutions matched to your operation, with a full portfolio of combines and front end equipment to hit your harvest window. Automation like Machine Sync, Auto Unload, and Predictive Ground Speed boost productivity, while integrated technology, parts, and Precision Upgrades help your combine adapt to changing crops and conditions—season after season.

Green combine harvester cutting through a mature field of dry grain with a wide header, leaving short stubble behind, as dust rises lightly under a pale sky with a distant, flat horizon
Analyze Key Insights for Better Decisions Next Year

Harvest data becomes next season’s advantage. Yield maps, grain quality, and machine analytics in John Deere Operations Center help refine seed placement, fertility plans, and hybrid selections. Combined with precision upgrades and automation, insights turn into consistent execution—setting the stage for better results next year.

A hand and arm reaches from the right side of the shot to touch a display in an X9 1100 combine's operator station
Question text goes here

Answer text goes here

Header
Transport Widths

5.35 m

Transport Widths

17.5 in.

Pickup Belts
Width Of Belts

1.13 m

Width Of Belts

3.7 ft

Number Of Belts Per Pickup

4

Total Picking Width

4.55 m

Total Picking Width

14.9 ft

Number Of Rollers

2

Cutting Width

14.9 ft

Cutting Width

4.55 m

Pickup Fingers
Type

Plastic

Number Of Fingers Per Belt

84

Auger
Float Range

2.25 in.

Float Range

57 mm

Auger Diameter

26 in.

Auger Diameter

66 cm

Auger Fingers

Steel with breakaway notch; Diameter: 0.625 in. (15.9 mm)

Number Of Auger Fingers

19 STS, maximum 22

Auger Finger Pattern

In-line, retracting

Finger Reach

152 mm

Finger Reach

6 in.

Operating Speed

216 rpm

Tires
Adjustment

Toolless

Pressure

103.4 kPa

Pressure

1 bar

Pressure

15 psi

Crop Deflector
Crop Deflector

Factory installed

Weight
Approximate Shipping Weight (Includes Shipping Skids)

3630 lb.

Approximate Shipping Weight (Includes Shipping Skids)

1647 kg

Additional Information
Date Collected

2020-06-15
