A deep-cutting chamber ensures efficient shredding and a clean cut. With a fast blade-tip speed, the cutter achieves fine shredding of grass, weeds, and brush.

The patented Double-Decker design fortifies the cutter's frame and reduces top deck rust. This innovative structure features internal stiffeners and replaceable bolt-on skid shoes.

The heavy-duty gearcase, featuring a non-seize self-adjusting slip-clutch driveline, boasts a continuous horsepower rating of 150 hp (112 kW) and a peak of 210 hp (157 kW). It includes cast-metal components with tapered roller bearings, forged gears for enhanced durability, and a factory preset, four-plate slip clutch that never needs adjusting, making it especially valuable for brush operations.

Answer text goes here
Cutting Width | 84 in. |
Cutting Width | 213.4 cm |
Cutting Height | 2-9 in. |
Cutting Height | 5-22.9 cm |
Cutting Capacity | 4 in. |
Cutting Capacity | 10.16 cm |
Cutting Chamber Depth | 11.8 in. |
Cutting Chamber Depth | 30 cm |
Tractor PTO HP Minimum | 45 hp |
Tractor PTO HP Minimum | 34 kW |
Tractor PTO | 540 rpm |
Hitch Type | Lift-type |
Hitch Category | 2, 3N |
Transport Width | 89 in. |
Transport Width | 226.1 cm |
Deck Shape | Domed |
Deck Type | Double decker |
Upper Deck Thickness | 0.118 in. |
Upper Deck Thickness | 3 mm |
Upper Deck Thickness | 11 gauge |
Lower Deck Thickness | 0.138 in. |
Lower Deck Thickness | 3.5 mm |
Lower Deck Thickness | 10 gauge |
Side Skirt Thickness | 0.25 in. |
Side Skirt Thickness | 6 mm |
Side Skirt Thickness | 3 gauge |
Approximate Weight | 1378 lb. |
Approximate Weight | 625 kg |
Main Driveline Protection | Non-seize, slip-clutch driveline |
Number | 1 |
Center Horsepower Rating - Continuous | 150 hp |
Center Horsepower Rating - Continuous | 112 kW |
Center Horsepower Rating - Peak | 205 hp |
Center Horsepower Rating - Peak | 152 kW |
Thickness | 0.5 in. |
Thickness | 13 mm |
Width | 4 in. |
Width | 102 mm |
Blade Tip Speed - 540 RPM | 15586 fpm |
Blade Tip Speed - 540 RPM | 4751 m/min |
Material Flow System | Integrated |
Holder Type | Round stump jumper (single suction) for protection of blades and carrier against obstruction damage |
Type | Laminated |
Front Shielding | Chain |
Rear Shielding | Chain |
