Constructed for durability, the hood is 0.2 in. (0.48 cm) thick to resist damage. The end plates provide structural integrity. A full-length torque tube helps prevent twisting on uneven ground for stable performance.

The mower comes with heat-treated side-slicer knives for tough conditions. Optional smooth-cut knives, ideal for grassy conditions, add versatility. Each knife type is designed for durability and efficiency, with resharpening options for prolonged life.

All John Deere flail mowers feature a rugged, heavy-duty gearbox with a continuous 65 hp (48.5 kW) rating and an intermittent 90 hp (67 kW) rating. Another feature included is a five-year, unlimited-hour warranty.

Answer text goes here
Machine | |||
| Cutting Width | 4.875 ft | ||
| Cutting Width | 1.5 m | ||
| Centered | Centered | ||
| Cutting Height | 0.5-5 in. | ||
| Cutting Height | 13-127 mm | ||
| Hood Thickness | 0.19 in. | ||
| Hood Thickness | 4.8 mm | ||
Blades | |||
| Number Of Blades | 108 (54 pairs) | ||
| Blade Type | Heat-treated reversible side-slice (optional smooth-cut cupped knives) | ||
Rotor | |||
| Rotor Speed | 1850 rpm | 2,236 rpm | |
| Rotor Diameter | 4.5 in. | ||
| Rotor Diameter | 114 mm | ||
Drives | |||
| Power Take-Off (PTO) | 540 rpm | ||
| Gearcase (Continuous Rating) | 65 hp | ||
| Gearcase (Continuous Rating) | 34 kW | ||
| Belts | Heavy-duty HC section | ||
| Gauge Roller | 5.5 in. | ||
| Gauge Roller | 140 mm | ||
Tractor HP Required | |||
| Minimum Tractor Horsepower Required | 30 hp | ||
| Minimum Tractor Horsepower Required | 22 kW | ||
| Maximum Tractor Horsepower Required | 75 hp | ||
| Maximum Tractor Horsepower Required | 56 kW | ||
3-Point Hitch | |||
| Quick-Coupler Compatible | Yes (Category 1 only) | ||
Dimensions | |||
| Overall Width | 5.75 ft | 1.7 m 70 in. | |
| Overall Width | 1.8 m | 1.7 m 70 in. | |
| Overall Height | 3.25 ft | ||
| Overall Height | 0.99 m | ||
| Overall Length | 3.33 ft | 1 m 40 in. | |
| Overall Length | 1 m | 1 m 40 in. | |
Weight | |||
| Approximate Weight | 794 lb. | ||
| Approximate Weight | 360 kg | ||
