John Deere
204SP
Hagie Sprayers

John Deere 204SP

Starting at

Turn Application Data Into Confident Decisions

Application doesn’t end at the field - it continues with the insights you gain. John Deere Operations Center connects your machines and data, giving you near real-time visibility into job progress, performance, and outcomes. With clear records and actionable insights, you can verify results, make informed adjustments, and continuously improve your application strategy for stronger performance season after season.

Wide view of a green agricultural sprayer driving through a large, neatly planted field, with long rows of crops stretching into the distance under a clear blue sky
Stay Ahead of the Application Window

Application timing can make or break yield potential, but unpredictable weather and tight windows make it difficult to execute at the right moment. John Deere application solutions help you stay prepared and ready, with integrated technology and equipment that streamline setup, reduce delays, and keep you moving - so you can apply when conditions are right and protect crop performance across every acre.

Large green agricultural sprayer with wide extended booms applying liquid across a dense, leafy crop field, with fine mist spraying onto the plants under an overcast sky.
Make Every Drop and Pass Count

Achieving consistent results across every acre requires precision you can trust. John Deere application equipment and technology deliver uniform coverage, accurate placement, and reliable rate control - helping ensure every pass is productive. By reducing overlap, minimizing waste, and maximizing efficiency, you can cover more acres per day while protecting inputs and maintaining high-quality application results.

Two people standing in a green crop field look at a smartphone together, while a large green agricultural sprayer with yellow wheels is parked nearby under a partly cloudy sky
Question text goes here

Answer text goes here

Engine
Peak Rated Engine Power

173 hp

Peak Rated Engine Power

129 kW

Emissions

Final Tier 4 (FT4)/Stage V

Number Of Cylinders

4

Displacement

275 cu in.

Displacement

4.5 L

Alternator

120 amp

Fuel Tank Capacity

90 gal.

Fuel Tank Capacity

340.7 L

Diesel Exhaust Fluid (DEF) Tank Capacity

5.7 gal.

Diesel Exhaust Fluid (DEF) Tank Capacity

21.6 L

Cab
Glass

58.7 sq ft

Glass

5.45 m²

Seat

Air suspension

Instructional Seat

Standard

Windshield Wiper

Single blade

Detasseling toolbar
Toolbar Outriggers - 12-Row

134 in.

Toolbar Outriggers - 12-Row

340.4 cm

Row Configurations

12

Detasseling Control System

Tasseltrol

Cutter Height Range

28.5 to 101.5 in / 72.4 to 257.8 cm

Puller Height Range

24.8 to 97.8 in / 62.9 to 248.4 cm

Quad Puller Operating Speed

450 rpm

Cutter Operating Speed

2800 rpm

Detasseling configuration options
Option 1

Quad puller - 12 Row 6 Lift

Option 2

Cutter - 12 Row 6 Lift

Drivetrain
Type

Hydrostatic

Drive

Full-time four-wheel drive (4WD)

Shifting

Dual speed range

Hydraulic Reservoir Capacity

17.25 gal.

Hydraulic Reservoir Capacity

65.3 L

Detasseling Speed Range

0 to 13 mph

Detasseling Speed Range

0 to 20.9 km/h

Detasseling Speed Range - Low Range

0 to 10 mph

Detassling Speed Range - Low Range

0 to 16.1 km/h

Detasseling Speed Range - High Range

0 to 13 mph

Detasseling Speed Range - High Range

0 to 20.9 km/h

Maximum Transport Speed

13 mph

Maximum Transport Speed

20.9 km/h

Chassis
Dry Compatible

No

Suspension

Independent air-ride

Crop Clearance With Standard Tires

77 in.

Crop Clearance With Standard Tires

195.6 cm

Front Tires

Titan® 12.4 x 38

Rear Tires

Titan 12.4 x 38

Hydraulic Tread Adjust

Manual only

Wheel Tread Spacing

100 to 120 in.

Wheel Tread Spacing

254 to 304.8 cm

Wheelbase

121 in.

Wheelbase

307.3 cm

Turning Radius

18 ft

Turning Radius

5.5 m

Parking Brake

Integrated in final drives

Primary Brakes

Drive system dynamic braking

Ladder Raise/Lower

Fixed ladder

Approximate Dry Weight

15357 lb.

Approximate Dry Weight

6965.8 kg

Additional Information
Date Collected

2023-08-23
